Pocketbook SURFpad 4 L Manuale utente
User Manual
PocketBook SURFpad 4 L
2
Contents
SAFETY PRECAUTIONS 4
APPEARANCE 6
TECHNICAL SPECIFICATIONS 7
GETTING STARTED 8
Charging The Battery 8
Unlock Your Device 9
Home Screen 9
Display Views 10
Finger Gestures 11
Using the On-screen Keyboard 12
Menus 12
Establishing Wi-Fi 13
Inserting Micro SD Card 13
Mobile Networks Connection 14
SOFTWARE 16
Manage Data 16
Application Launching 17
Creating Folders on the Home Screen 18
Application Removing 19
List of Opened Applications 19
Preinstalled Applications 20
PBI Packages Support 22
Listen to the Music 23
Gallery 24
MX Player 24
Camera 25
Browser 25
Email 26
SETTINGS 27
Language & Input 28
Sound Settings 30
Display Settings 31
3
Storage 32
Connecting Devices to Your Tablet 32
Unmounting External Memory and Devices 32
Location and Security 33
Date & Time 33
Restore Your Tablet to Factory Settings 34
Battery Charge State 35
Wi-Fi Connection 36
Connecting to Wi-Fi Network with
Automatically Obtained IP-address 36
Connection to Wi-Fi Network with
Manual Conguring Network Settings 37
Advanced Options 38
Turn off Wi-Fi 38
Bluetooth 38
Transferring Data 39
Scheduled Power On and Off 39
Printing 40
Information about Apps 40
FIRMWARE UPDATE 41
COMPLIANCE WITH INTERNATIONAL STANDARDS 44
CUSTOMER SUPPORT 47
4
Safety Precautions
Before start working with the Device, please, read this section carefully. Follow-
ing these instructions will help you ensure your safety and extend service life of
the Device.
Storage, Carriage and Usage Conditions
Device operating temperature range is 0°C to +40°C, so don’t expose the Device
to excessively high or low temperatures. Never leave cables near heat sources.
Heated cables or their insulation may become deformed or damaged, which
could lead to fire or electric shock.
Try to avoid next impacts:
•direct sunlight
•direct flame or smoke (cigarette, lighter, open fire etc.)
•exposure to liquids or damp (do not use the Device in the rain, in the street
at higher humidity, near bodies of water etc.)
•penetration of liquids or moisture
•exposure to strong electromagnetic fields, electrostatic charges and artificial
sources of UV electromagnetic radiation
•excessive mechanical pressure on the screen, connectors and keys of the
Device.
Do not leave the Device for a long time in poorly ventilated environment, e.g.
in a car or in closed tight boxes/packaging.
Neither drop nor try to bend the Device. Protect the screen from objects that
may scratch or damage it. To ensure adequate protection of the screen, we
recommend storing the Device in a protective and/or hard cover.
Keep away from children.
Maintenance
Do not disassemble or modify the Device.
Do not use the Device with a damaged battery, charger (broken case, poor
contact, broken feed cable) or SD card. If the battery is damaged (cracked case,
leakage of electrolyte, off-shape etc.) it should be replaced by the authorized
SAFETY PRECAUTIONS
5
personnel. Usage of home-made or modified batteries may cause an explo-
sion and/or damage the Device. Do not use organic or inorganic solvents (e.g.
benzoyl etc.) to clean the screen/case. Use a soft cloth to remove dust from the
Device’s surface. Apply a few drops of distilled water to remove dirt.
Up to five faulty pixels are acceptable in the screen and do not constitute a
warrantable defect of the screen.
When the product guarantee term is out of expiration, please contact the near-
est authorized service to diagnose whether the Device can be used safely.
For detailed information about service centers in your region please visit the official
website of PocketBook International: http://www.pocketbook-int.com/support/.
RF Safety
The Device receives and transmits radio frequencies and may interfere with
radio communications and other electronic equipment. If you use personal
medical Devices (e.g. a pacemaker or hearing aid) please contact your doctor
or the manufacturer to learn whether or not such medical devices are protected
against external RF signals.
Do not use wireless communication in places where it is prohibited, e.g. onboard
a plane and in hospitals – this may affect airborne avionics or medical equipment.
Utilization
Incorrect disposal of this Device may have adverse impacts on the environment
and public health. To prevent such consequences follow the device-specific
disposal requirements. Recycling of these materials helps preserve natural re-
sources. For more information regarding recycling issues please contact local
municipal authorities, your domestic waste collection service, store where you
purchased the Device, or the authorized service center.
Disposal of electric and electronic components (the Directive is applicable to
the EU and other European countries where separate waste disposal systems
exist). In other countries dispose batteries accordingly to local laws.
Do not destroy the battery by burning it to avoid the danger of explosion!
6
Appearance
1. Rear camera
2. Headphone jack
3. Micro SD slot
4. Speaker
5. Front camera
6. On/Off button
7. Volume +
8. Volume -
9. Micro SIM card tray
10. Microphone
11. Micro-USB
7
Technical Specifications
Display 9.7” touch screen 2048 × 1536
Processor Octa-Core ARM Cortex A7, 1.7 GHz
(MT8392)
RAM 2GB
Internal Storage 16 GB *
Platform Android™ 4.4
Input/Output Ports 1×micro USB 2.0, 3.5 mm audio jack,
microphone, micro SIM card
Card reader microSD (SDXC/SDHC) up to 64GB
Communications Wi-Fi (IEEE 802.11 a/b/g/n), 3G, GPS,
Bluetooth 4.0, FM radio
Camera Rear — 8 Megapixels,
Front — 2 Megapixels
Audio Speaker, microphone
Accelerometer Yes
Battery Li-Polymer, 8000 mAh **
Dimensions 238.4 × 167.9 × 8 mm
Weight 520 g
Text Formats epub, fb2, txt, doc, rtf, html, chm, tcr, pdf,
pml
Image Formats JPEG, PNG, BMP, GIF
Audio Formats MP3, WMA, AAC
Video Formats
MKV, AVI, MP4, FLV, WEBM, 3GP, MOV,
MPG, WMV, divX, Xvid, mpeg-4 SP,
mpeg-4, ASF, VC1, H264, H263, wmv 9,
MPEG-1, MPEG-2
* The actual available internal storage size may vary depending on the soft-
ware configuration of your device
** Battery life and values mentioned above might vary depending on usage
mode, connectivity and settings
8
Getting Started
CHARGING THE BATTERY
The battery of your Device is not fully charged as you unpack it, so you
need to charge it. When charging for the first time, we recommend
charging the device for 8 to 12 hours when off. Full charging will
subsequently take 5 to 6 hours. It’s strongly recommended to keep the
Device off during the first charge, otherwise power consumption could
be more, than charging, especially when you charge it from PC. Follow
next steps to charge the battery:
1. Make sure the Device is off. In opposite case, press On/Off button
for a few seconds and select Power Off in menu appeared. The Device
will shut down.
2. Connect your Device to power supply or computer using the mi-
croUSB cable included in package.
• Connect a USB cable to the jack of the Device:
ATTENTION! Incorrect connection of the USB cable can seriously damage the
Device. Damages of the Device, caused by incorrect connection, aren’t covered by
warranty.
• While the USB cable is connected, the Device should be near to
PC/charger.
NOTE It’s recommended to charge the battery using the charging device. In case if
you charge the battery from PC, it’s better to keep the Device off, because power
consumption could be more, than charging.
USB cable
GETTING STARTED
9
UNLOCK YOUR DEVICE
Tap and drag the lock out of the circle to one of icons to unlock your
Device.
HOME SCREEN
Notification
area Search in Google
Back - return to the
previous screen Return to
Home Screen
Last opened
applications
Open a list of
applications
and widgets
Applications
Pull it,
to open
Google
search
GETTING STARTED
10
DISPLAY VIEWS
The screen orientation is changed automatically when you hold the De-
vice horizontally to vertically, and vice versa. To enable/disable screen
auto-rotation, go to Settings > Device > Display.
Landscape view
Portrait view
