Poly G40-T Manuale

Poly G40-T

Get Started

Before you begin, make sure that you have the following:

Meeting room credentials (See Microsoft Teams Rooms.)

USB keyboard and mouse

Display HDMI cable(s)

Phillips #1 screwdriver and athead screwdriver

Unpack the Poly GC8, Lenovo® ThinkSmart™ Edition Tiny PC, mounting kit, 10 m USB-A to USB-C cable, and Poly Studio from their boxes.

25 m USB-A to USB-C cable

40 m USB-A to USB-C cable

Optional

SETUP SHEET

See the Regulatory Notices for all regulatory and safety guidance prior to configuration.

Avant de procéder à la configuration, veuillez consulter les Avis de réglementation, afin de prendre connaissance des recommandations en matière de sécurité et de réglementation.

For support, go to Poly Support.

For Warranty information, see the Polycom Product Warranty Guide.3725-30785-040B

support.polycom.com/video

USB

HDMI

(not supplied)

HDMI

(not supplied)

10 m USB 3.1

Content

Sharing

HDMI

USB-C

USB-A

HDMI

Mini

Display 1

Display 2

Poly Studio

Poly GC8

Model P024

(Optional) Mount the Lenovo PC using the mounting kit. Refer to the Poly G10 Series, Poly G40 Series, and Poly G80 Series PC Mounting Kit Setup Sheet.

Remove the bottom panel from the Poly GC8: loosen the screw with a Phillips #1 screwdriver, turn the GC8 faceup, press the rubber circles on each side, and slide the panel o.

Remove the cable guard from the Poly GC8 using a athead screwdriver.

Using the supplied USB-A to USB-C cable, connect the Lenovo PC

(USB-A) to Poly GC8 (USB-C) and connect the Lenovo PC to Ethernet.

Connect Poly Studio and display (using an HDMI cable) to the Lenovo PC.

(Optional) Connect a second display to the Lenovo PC.

(Optional) Connect an additional PC/laptop for content sharing to

Poly GC8 (using an HDMI/HDMI Mini cable).

Replace the cable guard in the Poly GC8 and replace the bottom panel

and tighten the screw.

Ethernet

3.5 mm Audio Out

USB-C

HDMI Mini

USB-A

Power

Screw

Press Press

Slide

Lenovo

ThinkSmart

Edition Tiny PC

This product cannot be connected directly to the telecommunications circuits (or public wireless LANs) of any telecommunication carriers (e.g., mobile communications carriers, fixed communications carriers,

or internet providers). In the case of connecting this product to the Internet, be sure to connect it via a router.

Connect the keyboard and mouse to the Lenovo PC.

Plug in and power on the Poly GC8 and then plug in and power on the other components.

The Lenovo PC may reboot more than once as it downloads and installs updates. Do not shut down the Lenovo PC during this process.

Complete the Windows Out-of-Box Setup using your keyboard and mouse.

The Lenovo PC may reboot more than once as it downloads and installs updates. Do not shut down the Lenovo PC during this process. When complete, the

Microsoft Teams Rooms Setup screen appears on the GC8.

Follow the on-screen prompts to complete your conguration. For detailed instructions, see Microsoft Teams Rooms.

When complete, the Lenovo PC reboots one more time.

Accessibility Features

For information on software accessibility features, see Accessibility support for Microsoft Teams.

The Poly GC8 provides a 3.5 mm audio out jack so that people who are hard of hearing can use third-party assistive technology peripherals.

nc. and any use of the mark by Plantronics, Inc. is under license. All other trademarks are the property of their respective owners.
