Polygroup Evergreen Classics TG70CH119P00 Manuale utente

TREE ASSEMBLY INSTRUCTIONS

Fig. B - Tree and Light Assembly

Congratulations on purchasing your new tree from Polygroup®!

This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!

Carefully follow the instructions below on how to quickly and easily set up your new tree:

1. Choose a level surface near a wall outlet.

2. Assemble the tree stand (See Fig. A).

MODEL #: TG70CH119P00,TG76P4A52P07,TG90CH119P00

3. Identify all tree sections (See Fig. B) by the sticker on them, and start assembling from bottom to top.

4. Open the protective cap of pole, and insert the pole into the stand. Allow all branches fall down into place. Check to make sure

that all wires are free from branch hinges.

5. Shape the tree section one branch at a time. Start with the tips closest to the pole and move outwards. Fan all the tips out in

alternating directions, and slightly upsweep them for a natural look (See Fig. C).

Top view Side view

Fig. C

*Electrical Rating For The Tree

(For Indoor Use Only)

Input: AC 120V, 60Hz, 0.83A

Output: DC 24V 2A

Controller: 24V 2A

Tree Top

Section 2

Section 1

Plug Adapter

Into Wall

Outlet

Insert Green

Label Extension

Cord into Adapter

Fig. A - Tree Stand Assembly

Click

Pull apart the legs of the stand so that they

are snapped into an x-shape, place the tree

stand on a level surface.

To close the stand, press the metal button

and fold the legs together.

Align both arrows in

a straight line before

sliding down to insert

Open the

cap cover

Do Not Tamper

Internal Parts

NEED HELP?

DO NOT RETURN TO STORE. PLEASE VISIT US AT:

www.polygroupstore.com OR +1 (888) 919-0070

This tree includes hinge pins/washers.

If extra parts are needed, please contact our customer service center.

SPARE PARTS

STORAGE INSTRUCTIONS

TROUBLESHOOTING TIPS

1. Unplug from power source, and detach plug from adapter. Remove all ornaments and decorations.

2. Disassemble the tree from top to bottom. Gently lift pole straight up to remove from the lower

section, and fold all branches toward the pole.

3. Close the protective caps on the poles to avoid damaging the internal parts (See Fig. D).

4. Place the disassembled tree into the shipping box and tape it shut.

5. Store your tree in a cool, dry place away from sunlight.Exposure to excessive heat or humidity

may damage your tree.

If Tree Does Not Illuminate / Some Bulbs Do Not Light or Flicker

1. Please check to make sure that all plugs are properly connected and adapter is plugged into the wall outlet.

2.Turn the poles gently to make sure pole to pole sections are connected properly

3. Check for loose connection between light string plugs and extension cords.

1. Place the branch into the hinge bracket (See Fig. E).

2. Insert a new hinge pin all through the holes of bracket,

and secure with a washer (See Fig. E - close up).

Loose Hinge Pin

Fig. E

6. Repeat Step 4 and 5 for the upper tree section(s) until tree top is installed and shaped.

7. Connect plug with adapter, and plug it in to the wall outlet as indicated in Fig. B.

8. Step back and view your tree. Shift branches to fill any gaps.Your Christmas tree is now ready to be decorated.

CAUTION:

To reduce the risk of fire and electric shock:

a) Use only the power supply that was provided with this product.Using a different adapter will damage the lights and may cause

fire, or electrical shock hazards.

b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal.

c) Do not mount or support strings in a manner that can cut or damage wire insulation.

Fig. D

IMPORTANT SAFETY INSTRUCTIONS

When using electrical products, basic precautions should always be followed including the following:

1. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

2. Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use.

When products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting (GFCI) outlet.

If one is not provided, contact a qualified electrician for proper installation.

3. This seasonal use product is not intended for permanent installation or use.

4. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat.

5. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.

6. Do not let lamps rest on the supply cord or on any wire.

7. Unplug the product when leaving the house, or when retiring for the night, (or if left unattended).

8. This is an electric product, not a toy! To avoid risk of fire, burns, personal injury and electric shock it should not be

played with or placed where small children can reach it.

9. Do not use this product for other than its intended use.

10. Do not hang ornaments or other objects from cord, wire, or light string.

11. Do not close doors or windows on the product or extension cords as this may damage the wire insulation.

12. Do not cover the product with cloth, paper or any material not part of the product when in use.

13. Read and follow all instructions that are on the product or provided with the product.

14. SAVE THESE INSTRUCTIONS.

REMOTE CONTROL INSTRUCTIONS

Multi Color Steady Glow

Color Wheel

Faster Light Effect For

Preset Motion

Slower Light Effect For

Preset Motion

Customizable color selection

In case the light motion effects keep switching to the next one every 30 seconds

and continues to cycle, this means the Demo mode is on.

To cancel the Demo mode, simply press and hold the (Brightness Down) button

and the (Slower Speed) button together for 10 seconds.

NOTE:

ON/OFF

Warm White Steady Glow

Brightness Up

Next Preset Motion Effect

Brightness Down

Tap to display all lights in

multi color steady glow

Tap to display all lights in

warm white steady glow

1. Slide open the battery cover.

2. Replace with a new CR2032 button cell battery with

correct polarities (+/-) as indicated.

3. Slide the battery cover closed.

Battery Replacement

Remove insulation

tab before use.

Battery Cover

WARNING

1. Small parts, keep away from children.

2. Do not expose the product to moisture.

3. Remove batteries when not used for an extended period of time,

or when depleted.

4. Dispose of used batteries properly, and local laws and

regulations regarding the disposal of hazardous waste.

5. Use only CR2032 batteries for the remote controller.

6. Clean the battery contact surfaces gently prior to battery installation.

7. Do not dispose of batteries in fire. Batteries may explode or leak.

8. This product is powered by a lithium battery. Due to their small size,

lithium batteries can easily be swallowed by children. Ingestion of

such batteries has been known to cause death.

9. This is a lithium battery which if swallowed has been known to cause death.

WARNING: This product may potentially trigger seizures for people with photosensitive epilepsy when using the motion

effect light modes.

Previous Preset Motion Effect

Tap or to select from the

10 preset motion effects:

• Fading

• Multicolor Ball

• Color-Changing

• Collision

• Fireworks

• Falling Rings

• Twinkle

• 3-Ring Motion

• Rainbow Shower

• Rainbow

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at +1 (888) 919-0070

or visit our website at www.polygroupstore.com. One of our customer service representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:
