Polygroup TG70M3ABAD01 Manuale utente

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

TREE ASSEMBLY INSTRUCTIONS

3. Each tree section is numbered with a sticker. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top.Start with the bottom section and remove protective cap before inserting into the assembled

stand.Make sure the pole is firmly inserted and secured into the stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all wires are free of branch hinges.

7. Connect the light strings as per the color labels indicated in Fig. B and insert green label adapter into the wall outlet.Your entire tree

should now be lit. If some bulbs do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Replace bulbs

promptly in order to maintain the performance and life expectancy of your pre-lit tree.

MODEL #: TG70M3ABAD01

*Electrical Rating For The Tree

(For Indoor Use Only)

Input: 120V, 60Hz, 0.38A

Output: 29V DC 0.621A

Fig. B - Tree and Light Assembly

NEED HELP?

DO NOT RETURN TO STORE. PLEASE VISIT US AT:

www.polygroupstore.com OR 1-888-919-0070

Insert Green

Label Extension

Cord into Adapter

Section 1

Section 2

Tree top

Foot Pedal

on/off Switch

Adapter

To Be Plugged

Into Wall

Outlet

Fig. A - Tree Stand Assembly

Click

Pull apart the legs of the stand so that they

are snapped into an x-shape, place the tree

stand on a level surface.

To close the stand, press the metal button

and fold the legs together.

Congratulations on purchasing your new tree from Polygroup®!

This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!

Carefully follow the instructions below on how to quickly and easily set up your new tree.

Align both arrows

in a straight line

before sliding

down to insert

Open the

cap cover

Do Not Tamper

Internal Parts

Control box

Simply press the selector button to select from the following light functions:

(1) CLEAR-MULTI: FADING (2) CLEAR: FADING

(3) CLEAR-MULTI: ALTERNATING (4) CLEAR: STEADY

(5) CLEAR-MULTI: SLOW FADING (6) MULTI: STEADY

(7) MULTI: FADING (8) COMBINATION

DUAL COLOR LIGHT CONTROLLER & REMOTE CONTROL

Remote

Control Light

Controller

Selector Button

Insulation Tab

REMOTE CONTROL INSTRUCTIONS

1. Remove the insulation tab of the remote control.

2. Press either selector button and wait for a second to enjoy light effects in the following sequence (see DUAL COLOR LIGHT

CONTROLLER & REMOTE CONTROL).

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected according to the color labels indicated in Fig.B and the adapter is plugged

into the wall outlet. Refer to assembly guide for instructions. (If the tree comes with a foot pedal, try stepping on the on/off button).

2. Check for loose connection between light string plugs and extension cords.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges.

Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure

using the retainer washer. (See Fig. D)

TROUBLESHOOTING TIPS

Fig. D

Top view Side view

Fig. C

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from the pole and fan out one

to the right, one to the left and one at the center of the main stem. (See Fig. C)

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform look. Shift branches to fill

any gaps.Your Christmas tree is now complete and ready to be decorated.

1. Unplug adapter from the wall outlet first and then remove all ornaments and decorations.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to remove from section

below and fold all branches toward the pole.

3. Continue by gently lifting straight up each section(s) from the section below and fold all

branches toward the pole until the bottom section is removed from the tree stand. Cover

the protective cap on the poles to avoid damaging the internal parts. (See Fig. D)

4. Carefully place all tree sections into shipping box and tape it shut.

5.When not in use, please store your tree in a cool, dry place away from sunlight.

Exposing your tree to excessive heat or humidity may damage your tree.

STORAGE INSTRUCTIONS

Fig. D

2. Replace the used battery with a new CR2032 button cell battery (not included). Make sure that the battery is installed with the

correct polarity (+ and -).

3. Retighten the screw to close and secure the battery cover.

Cover

Battery

CR2032

BATTERY REPLACEMENT

1. Loosen the screw of the battery cover with a screwdriver (not included).

WARNING

1. Dispose used battery properly. observe local regulations regarding disposal of hazardous waste.

2. Ensure the batteries are installed correctly with regard to polarity (+ and -).

3. This product is powered by a lithium battery. Due to their small size, lithium batteries can easily be swallowed by children.

Ingestion of such batteries has been known to cause death.

4. Do not expose light set to moisture.

5. Remove batteries when not used for an extended period of time, or when depleted.

6. Clean the battery contacts prior to battery installation.

7. The external flexible cable or cord of this luminaire cannot be replaced; If the cord is damaged, the luminaire shall be destroyed.

8. Dispose of used batteries properly, and local laws and regulations regarding the disposal of hazardous waste.

9. Use only CR2032 batteries for the remote controller.

10. Do not dispose of batteries in fire. Batteries may explode or leak.

11. This is a lithium battery which if swallowed has been known to cause death.

12. Small parts, keep batteries out of reach of children.

Each tree includes hinge pins/washers, and for pre-lit trees spare bulbs are also included.

If extra parts are needed, please contact our customer service center.

SPARE PARTS

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070

or visit our website at www.polygroupstore.com.One of our customer service representatives will be happy to assist you.

CUSTOMER SERVICE FOR CHRISTMAS TREES

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

Customer Name:

Address(No P.O. Boxes):

City & State:

Zip Code:

Day Phone:

Date Purchased:

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

CAUTION:

To reduce the risk of fire and electric shock:

a) Use only the power supply that was provided with this product.Using a different adapter will damage the lights and may cause

fire, or electrical shock hazards.

b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal.

c) Do not mount or support strings in a manner that can cut or damage wire insulation.
