ASSEMBLY INSTRUCTIONS MADE IN CHINA

MODEL #: TG90P6059D02

• Before you start to assemble your tree, choose an appropriate location near a wall outlet.

• Assemble the tree stand and place on a level surface. (See Fig. B)

Congratulations on purchasing your new tree from Polygroup®!

Carefully follow the instructions below on how to quickly and easily set up your new tree.

TREE ASSEMBLY INSTRUCTIONS

Section 1

Section 3

Section 2

Each tree section is numbered

with a tag. Please identify all

sections before assembling.

Insert Section 1 into the tree stand.

SET UP INSTRUCTIONS WITH QUICK FOLDTM

A. Locate “Pull Here” tab and corresponding

Cinch Handle

B. Hold Cinch Clip firmly with one hand and

press down on clip

C. With Cinch Clip depressed, pull clip away from

tree until all branches are released.

Section 1

Cinch

Handle

Tree stand Tree stand

Cinch Clip

Fig. A - Tree and Light Assembly

Do Not Tamper

Internal Parts

Open the

protective

cover

Do Not Tamper

Internal Parts

Open the

protective

cover

Quick Set®

Connections

Quick Set®

Connections

Do Not Tamper

Internal Parts

Open the

protective

cover

Quick Set®

Connections

Quick FoldTM Cinch

*Electrical Rating For The Tree

(For Indoor Use Only)

Input:120VAC, 60Hz, 0.38A Max.

Output: 29V DC 0.9A

Adaptor

To Be Plugged

Into Wall

Outlet

Control box Insert Green

Label Extension

Cord into Adaptor

1. Pull apart the legs of the stand so that

they are snapped into an x-shape, place the

tree stand on a level surface.

2. When inserting the bottom section of the tree

into the assembled stand, insert and turn the

eyebolts into the stand and tighten until the

tree pole is firmly secured.

To close the stand, remove the eyebolts, press

the metal button and fold the legs together.

Fig. A - Tree Stand Assembly Eye Bolt

Click

Eye Bolt

ASSEMBLY INSTRUCTIONS MADE IN CHINA

Top view Side view

Fig. C

• Just plug the adaptor (connecting with the tree power cord) into the wall outlet (See Fig. A), your

entire tree should now be lit.If some bulbs do not light or flickers, search for any loose plugs and/or

broken, loose or missing bulbs. Replace bulbs promptly in order to maintain the performance and life

expectancy of your pre-lit tree.

• Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from

the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)

• After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform

look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.

4 5 6

Remove the protective cap of Section 1

and add Section 2.

Release all branches using the same

procedures described in step 3.

Remove the protective cap of Section

2 and add Section 3.

Section 1 Section 1

Section 3

Section 2

Section 1

Section 2

Section 1

Section 2

Section 3

Section 2

4 5 6

1 32

STORAGE INSTRUCTIONS WITH QUICK FOLDTM

• Unplug extension cord from the wall outlet first and then remove all ornaments and decorations.

• When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to

excessive heat or humidity may damage your tree.

Detach tree top and store it

in box.

Fold the lower layer of Section 2

like step 2.

Detach Section 2 and put it into

the box.

Cover the protective cap of tree

bottom Section 1, then follow step 2

to fold tree.

Detach section1 from the tree stand

and place into box. Then fold up tree

stand by unlock the disc and then

store in box.

A. Cover the protective cap of the Section 2.

B. Hold Cinch Handle with one hand.

C. Hold Cinch Clip firmly with other hand and press down on clip.

D. Pull handle toward you while pushing away cinch clip

until the upper branches of tree middles Section 2 are

folded completely.

Tree stand Tree stand

Tree stand

C D

ASSEMBLY INSTRUCTIONS MADE IN CHINA

TROUBLE SHOOTING TIPS

SPARE PARTS

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected and power cord is plugged into the wall

outlet. (If the tree comes with a foot pedal, try stepping on the on/off button).

2.Turning the poles gently to make sure pole to pole are connected into place.

3. Check for loose connection between light string plugs and extension cords.

4. Please check for loose, broken or missing light bulbs and replace as needed.

1. Extra hinge pins are included for repairing the hinges. Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure using the retainer washer.(See Fig. D)

Each tree includes hinge pins/washers, and for pre-lit

trees spare bulbs are also included. If extra

parts are needed, please contact our customer service

center.

Loose Hinge Pin

Fig.D

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact

us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service

representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX. TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

HOW TO USE THE DUAL COLOR LIGHT CONTROLLER :

Press the selector button on the “Dual Color Light Controller” to

select among: (1) CLEAR-MULTI FADING;

(2) CLEAR-MULTI FLASHING; (3) CLEAR-MULTI ALTERNATING;

(4) STEADY CLEAR; (5) FLASHING CLEAR; (6) STEADY MULTI;

(7) FLASHING MULTI; (8) COMBINATION. Light

Controller

Selector

Button

WARNING

1. Use only power adaptor supplied with this product, using a different adaptor will damage the lights

and cause fire, electrical shock hazards.

2. FOR INDOOR USE ONLY.
