Service Manual

FOR

PL-ELS 2100/2100

EVAPORATIVE

LIGHT-SCATTERING

DETECTOR

Version 2.0 June 2006

Polymer Laboratories Ltd Now a part of Varian, Inc. Essex Road, Church Stretton, Shropshire SY6 6AX,

Tel +44 (0)1694 723581, Fax +44 (0)1694 722171, Service Tel +44 (0)1694 724333

Polymer Laboratories Varian Inc, Amherst Fields Research Park, 160 Old Farm Road, Amherst, MA

01002, USA

Tel: +1 413 253 9554, Fax +1 413 253 2476

Polymer Laboratories BV, Herculesweg 8, 4339 PL Middleburg, The Netherlands

Tel +31 (0)11 8671500, Fax +31 (0)11 8623193

Polymer Laboratories GmbH, PEKA Park T5 001 Otto-Hesse Stra€e 19 D 64293 Darmstadt,

Germany Tel +49 (0)6151 860690, Fax +49 (0)6151 860670

Polymer Laboratories SARL, GVIO Parc de Marseille Sud, Impasse du Paradou, B•timent D5, BP 159

13276 Marseille, France. Tel + 33 (0)491 176400, Fax + 33 (0)491 176401

Document Revision History (6/26931)

Revision #Date Section

Changed

Changes Approval

Draft 12th July 2005 All Originated

Version 1

release

11th August 2005 Title page Document number

French address

SJOD

6/26931B

Version 2.0

28th March 2006 Title page,

Introduction,

Safety,

Installation,

Cleaning &

Decontamina

tion.

Company names &

addresses, Safety

pages to front,

updated safety info &

insta llation details,

added cleaning &

decontamination,

misc updates

throughout

JCP / PEC

6/26931B

Version 2.0

19th May 2006 All Addition of PL-ELS

2100/2100 Ice

evaporator removal,

power supply and

general formatting

SMB/JCP

DO NOT ISSUE THIS PAGE

CONTENTS

INTRODUCTION............................................................................................................................ 1

SAFETY........................................................................................................................................... 2

INSTALLATION............................................................................................................................. 3

Site Pre paration Che ck List………………………......................................................................... 3

Unpacking the de tector………………………………..................................................................... 4

Packing list…………………………………………......................................................................... 4

Powe r Connections……………………………………………......................................................... 4

Gas Connection………………………………………………. ......................................................... 4

Fluid Connection……………………………………………............................................................ 5

Extraction…………………………………………………….. ......................................................... 5

Data Connection………………………………………….. .............................................................. 5

Analogue Signal Connector………………………………............................................................. 5

Serial RS232 Connector……………………………………........................................................... 6

Control I/O Connector…………………………………………...................................................... 6

Installing the Detector……………………………………….. ......................................................... 7

Storing the Instrume nt…………………………………….............................................................. 8

OPTIMISING DETECTOR PERFORMANCE............................................................................... 9

Ge ne ral Conside rations…………………………………................................................................. 9

Optimisation Parame te rs…………………………… ..................................................................... 9

Gas Flow………………………………………….. ....................................................................... 9

Evaporator Temperature…………………………………. ............................................................. 9

Nebuliser Temperature………………………………….. .............................................................10

Optimisation Proce dure ………………………………………………............................................ 10

OVERVIEW OF DETECTOR’S OPERATION MODES.............................................................. 11

Standby Mode……………………………………………… .......................................................... 11

Run Mode…………………………………………........................................................................ 11

TROUBLESHOOTING................................................................................................................. 12

Instrument Error Codes…………………………………. ............................................................ 12

Ge ne ral Proble ms…………………………………………. ........................................................... 13

REPAIRING THE PL-ELS 2100/2100 Ice ..................................................................................... 14

Overvie w of Main Asse mbly………………………………........................................................... 14

Removing The Front Panel……………………………….............................................................15

Overvie w of Ne bulise r Asse mbly………………………. .............................................................. 17

Replacing the Nebuliser………………………………..................................................................18

Replacing The Nebuliser Heater Assembly……….......................................................................20

Replacing The Nebuliser Chamber………………........................................................................22

Replacing The Solvent Leak Assembly………………..................................................................24

Replacing The Vapour Sensors……………………………...........................................................25

Replacing The Fan Assembly……………………........................................................................28

Overvie w of PL-ELS 2100 Evaporator Assembly…………………………………………………..30

Removing And Cleaning The Evaporator Cartridge (Diffuser)......................................................31

Replacing The Evaporator Heater Assembly (Evaporation Tube) ..................................................33

Replacing The Mass Flow Controller‚‚‚‚‚........................................................................35

Replacing The Gas Inlet Plug Assembly‚‚‚‚‚‚ ...............................................................36

Replacing The Gas Inlet Valve‚‚‚‚‚‚‚‚‚ ..................................................................37

Overvie w of PL-ELS 2100 Ice Evaporator Assembly.................................................................. 38

Removing And Cleaning The PL-ELS 2100 Ice Evaporator Cartridge (Diffuser) ...........................39

Replacing The PL-ELS 2100 Ice Evaporator Heater Assembly .....................................................41

Removing The Photodetector (PMT) Assembly‚........................................................................46

Replacing The LED Light Source Assembly‚‚‚.....................................................................48

Cleaning The Optical Lens Assembly‚‚‚‚‚.. .....................................................................50

Replacing The Optical Light Trap‚‚‚‚‚‚‚.. ...................................................................52

Replacing The Optical Heater‚‚‚‚‚‚‚‚........................................................................54

Removing & Cleaning The Prism Assembly‚‚.........................................................................55

Ele ctronics………………………………………….. ..................................................................... 57

Replacing The Main Control PCB………………… ....................................................................57

Replacing The PL-ELS 2100 Power Supply………. ....................................................................59

Replacing The PL-ELS 2100 Ice Power Supply….. .....................................................................60

Firmware ……………………………………………….................................................................. 64

Device Identifier…………………………………….....................................................................64

Upgrading Firmware………………………………......................................................................65

Programming Device Identity……………………........................................................................70

IDENTIFYING PARTS AND MATERIALS ................................................................................. 74

INSTRUMENT SPECIFICATIONS.............................................................................................. 75

CLEANING & DECONTAMINATION PROCEDURES .............................................................. 76

Cleaning…………………………………………… .....................................................................76

Decontamination…………………………………....................................................................... 76

Version 2.0 1

6_26931B ELS2100_2100 Ice Se rvice Manual_vsn2.0_master.doc

INTRODUCTION

The combined PL-ELS 2100/2100 Ice Service Manual is designed for use by personnel who

have had training and are experienced in servicing this type of equipment. Whilst the PL-ELS

2100/2100 Ice has been designed for easy repair, there are potential hazards associated with

servicing this instrument. We strongly recommend that our service engineers perform all

servicing

It is understood that the purchaser must assume all risk in the use of this manual for the purpose

of performing service upon the instrument it covers. There are no user-serviceable parts in the

PL-ELS 2100/2100 Ice.

Polymer Laboratories strongly recommends the use of original Polymer Laboratories spare parts

only, otherwise we do not guarantee any specification or liability

It is strongly recommended that the operator read the entire manual carefully before attempting to

service the instrument. In addition, be sure to observe all signs and pictographs that are specifica lly

defined as follows:

WARNING:

The “warning sign” denotes a hazard. It calls attention to a

procedure, practice which, if not correctly done or adhered

to, could result in severe injury or damage or destruction of

the instrument. Please do not proceed beyond a warning

sign until the indicated conditions are fully understood and

met.

ATTENTION:

The “attention sign” denotes relevant information. Read this

information first before proceeding, it will be helpful or

necessary to complete the task.

NOTE:

The “note sign” denotes additional information.

It provides the user with advice and suggestions to facilitate

the operation of the instrument

Version 2.0 2

6_26931B ELS2100_2100 Ice Se rvice Manual_vsn2.0_master.doc

SAFETY

The following procedures require opening the main cove r of the detector.

Always ensure that the detector is disconnected from the mains power when

the side panel is opened. The PL-ELS 2100/2100 Ice has a safety bar at the

powe r input socket that prevents the detector’s side panel being opened whe n

the powe r cable is still connected.

WARNIN

To disconnect the detector from the mains supply line, unplug the power

cord. When working with solvents please observe appropriate safety

procedures (for example, safety goggles, gloves and protective clothing),

especially when toxic or hazardous solvents are used.

NOTE AUTION

Electronic boards and components are sensitive to electronic discharge

(ESD). In order to prevent damage always use ESD protection whe n

handling electronic boards and components.

WARNING

The LED light source is a Class 1 LED product. Te mporary discomfort may

result from directly viewing the light produced by this source. Do not look

into the beam.

Make sure that only fuses with the required rated current and of the

specified type (super-fast, fast, time delay etc) are used for replacement. The

use of repaired fuses and the short-circuiting of fuse-holde rs must be

avoided.

Any adjustme nt, maintenance, and repair of the opened instrument unde r

voltage should be avoided as much as possible. When inevitable, this should

only be carried out by a skilled person who is aware of the hazards involved.

Use of a mains isolating transforme r is recommended.

Read and understand the PL-ELS 2100/2100 Ice user manual before

undertaking any service ope rations on this instrume nt.

Version 2.0 3

6_26931B ELS2100_2100 Ice Se rvice Manual_vsn2.0_master.doc

INSTALLATION

Site Preparation Check List

Environmental Conditions

Temperature 15ƒ to 35ƒC (59 to 86ƒF)

At constant temperature

Avoid positioning in direct sunlight

Humidity 10-80%

Power

USA and Japan 115V (AC) „10%

50/60 Hz, 2A max, with a protective earth connection.

Europe 230V (AC) „10%

50/60 Hz, 2A max, with a protective earth connection.

Gas Supply

Gas: Nitrogen (98% purity or better and filtered to 0.2…m)

Notes:

 Air can only be used for non flammable solvents

 The mass flow controller is not calibrated for use

with gases other than Air or Nitrogen

 For operation with other inert gases contact

Polymer Laboratories for advice.

Gas flow: up to 3.25 SLM @ 60 psi @ 25ƒC

Pressure operating range: 60 † 100 psi (4-6.7 bar)

Maximum Pressure: 100 psi (6.7 bar)

Extraction Requirements

During normal operation the carrier solvent is evaporated as it passes

through the instrument and must be extracted safely at the rear of the

unit.

The exhaust from the instrument (13mm ID PVC tubing) must be extracted to a fume hood or

similar solvent disposal unit. If the extraction tube provided with the instrument is to be extended

it is recommended that the diameter of the extension is increased to at least 50mm (2) diameter

tubing so the extraction quality is not inhibited.

Version 2.0 4

6_26931B ELS2100_2100 Ice Se rvice Manual_vsn2.0_master.doc

Unpacking the detector

Care has been taken to ensure that the instrument is received in proper condition. The packing

and protection are designed for normal hazards of road, rail or air transit. Any damage to the

container or instrument should be reported immediately to your local distributor, or to Polymer

Laboratories. It is recommended that the shipping container be kept, if possible, for reshipment

or return to a service centre.

Examine the shipping carton for visible signs of exterior damage. Unpack the instrument and

examine for transit damage. Check that all items on the packing list are included.

Notify your local distributor or Polymer Laboratories of any damage or missing items.

Packing list

 PL-ELS 2100/2100 Ice detector

 Manual for PL-ELS 2100/2100 Ice detector

 Mains Lead (110-120V, 60Hz or 230V, 50Hz)‡

 15 pin D male connector for Aux I/O connection

 Detector output cable

 Gas Inlet tube (2m)

 Exhaust hose (PVC†2.0m)

 Waste hose (Tygon SE200†7cm)

 Solvent waste container (500ml)

 Valco Nut and ferrule (1/16”)

Powe r Connections

 Before connecting the power cable, ensure the instrument voltage rating matches your

local power supply.

 Use only a supply with protective grounding.

 The correct fuses should be installed.

 For 115V (AC) or 230V (AC) use two 250V H 2A T fuses

THIS UNIT IS DOUBLE -FUSED.

RISK OF FIR E, REPLACE FUSES AS MARKED!

If the voltage rating and fuses are correct for your power source, connect the power cable

Gas Connection

The instrument should be supplied with clean, dry nitrogen gas at a minimum head pressure of

60psi. A 4mm push-in connector is provided at the rear of the instrument for a convenient

connection to the gas source.

Version 2.0 5

6_26931B ELS2100_2100 Ice Se rvice Manual_vsn2.0_master.doc

To prevent against unnecessary gas usage, an automatic but controlled gas shut off valve is

integrated into the gas inlet manifold1. This will only allow gas to pass into the instrument when

the instrument is operating. Should the instrument default to a standby mode the gas valve will

close after 15 minutes.

THE GAS INLET VALVE WILL BE CLOSED WHEN THE

INSTRUMENT IS FIRST POWERED ON AND WILL ONLY OPEN

ONCE THE INSTRUMENT IS SET TO RUN MODE

Fluid Connection

The eluent from the chromatography system is connected to the front of the instrument via the

low dead volume Valco bulkhead connector provided.

USE ONLY VALCO FITTINGS

The liquid inlet port is connected directly to the nebuliser by a short length (190mm) of capillary

tube giving a delay volume from port to nebuliser tip of ~5…l.

Extraction

The PL-ELS 2100/2100 Ice is provided with tubing for venting the exhaust gases and vapors,

and so does not need to be placed in a fume cupboard. Instead, the exhaust hose provided must

be attached to the rear of the unit and vented to a fume hood or other disposal unit. Ensure the

exhaust hose has an upward slope from the PL-ELS 2100/2100 Ice so that any condensed solvent

is collected in the waste bottle at the front of the unit and to prevent it accumulating in the

tubing.

THE EXHAUST MUST BE EXTRACTED TO A SUITABLE FUME

EXTRACTION SYSTEM

Data Connection

Analogue Signal Connector

The PL-ELS 2100/2100 Ice is fitted with an analogue output (0-1V) to allow connection with a

data acquisition interface.

1Only with instruments with Firmware V1.2.1 & Serial #004-162 or later

Version 2.0 6

6_26931B ELS2100_2100 Ice Se rvice Manual_vsn2.0_master.doc

Serial RS232 Connector

The PL-ELS 2100/2100 Ice is fitted with a standard RS232 (DTE-DCE) 3-wire serial interface.

The serial RS232 connector provides a 24bit (10Hz) digital output for connection to a

chromatographic acquisition device.

The PL-ELS 2100/2100 Ice ca n be controlled from a PC using the RS232 interface and the PL-

ELS 2100/2100 Ice graphical control software from Polymer Laboratories Ltd. Refer to the

control software on-line manual for operating instructions. If controlling the instrument from a

PC then a serial port or USB port is required. If the USB port is used a serial to USB adapter is

also required (0860-0620).

Control I/O connector

The PL-ELS 2100/2100 Ice can be connected to auxiliary equipment to pause or stop the

operation of a pump or autosampler if the PL-ELS 2100/2100 Ice reports an error condition.

The PL-ELS 2100/2100 Ice is equipped with 2 contact closures, which are normally open and 2

TTL logic interfaces; one active low and one active high.

The PL-ELS 2100/2100 Ice can be auto-zeroed remotely.

Table 1.1: Control I/O connector

I/O Description Pin No.

Outputs User contact closure †normally

open

4 & 12

Pump stop contact closure †

normally open

3 & 10

TTL Active low 2 & ground

TTL Active high 9 & ground

Ground (to case) 1, 5, 6 ,11

Inputs Remote A/Z 7 & ground [firmware version

1.0.15. Units with serial # 004-161 and

before will also require a wiring

modification on the main PCB]

The instrument is supplied with a connector for the I/O socket in order to make appropriate

connections; however, a cable can be purchased for this from Polymer Laboratories (Part # 0860-

0055).

PUMP STOP FACILITY MUST BE EMPLOYED IF INSTRUMENT IS

TO BE LEFT UNATTENDED, OR IF UNITS ARE STACKED

Altri manuali per PL-ELS 2100

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Polymer Laboratories Sensore di sicurezza

Polymer Laboratories

Polymer Laboratories PL-ELS 2100 Manuale utente

Manuali Sensore di sicurezza popolari di altre marche

THORLABS

THORLABS PDA10JT Manuale utente

Waeco

Waeco UV-DETECT Manuale utente

Intermatic

Intermatic IOS-DSIMF Manuale utente

urmet domus

urmet domus 1083 Manuale utente

Siemens

Siemens AZL66 Series Manuale utente

BTI

BTI Profiline Multi Finder Manuale utente

Challenger

Challenger SL01 Manuale utente

DMP Electronics

DMP Electronics 1122INT Manuale utente

Rielta

Rielta Ladoga MK-RK Manuale utente

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuale utente

Bosch

Bosch DS835 Manuale utente

DBI SALA

DBI SALA EZ Stop Manuale dell'operatore

Lamptime

Lamptime ST05C Manuale utente

Ubiquiti

Ubiquiti MFI-MSC Manuale utente

Subsite

Subsite 910R Istruzioni per l'installazione

Satel

Satel OPAL Pro Manuale utente

Aleph

Aleph XC-1XTEU Manuale utente

Pima

Pima LARIS QUAD Manuale utente
