PORODO PD-GAIFTGR-WH Manuale utente
Gimbal
With AI Face tracking Gesture Recognition
With Remote Controller
SKU:PD-GAIFTGR-WH
Table of Content
wÆìÐĉĴðÆðÐœďåqďīďÌď:ðĉÅăȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ1
:ÐĴĴðĊæwĴīĴÐÌȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ3
1ȘAĊĮĴăăðĊæĴìÐwĉīĴĨìďĊÐȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ3
2ȘqďœÐīķĴĴďĊȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ3
3ȘA:ÐĮĴķīÐtÐÆďæĊðĴðďĊȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ4
wĨÐÆðťÆĴðďĊȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ5
wÆìÐĉĴðÆðÐœďåĴìÐtÐĉďĴÐȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȭ5
wĴÐĨĮĴďĨðīðĊæĴìÐīÐĉďĴÐÆďĊĴīďăăÐīȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ7
1ȘqðīðĊæĴìÐīÐĉďĴÐÆďĊĴīďăăÐīĴďĴìÐ:ðĉÅăȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ7
2ȘqðīðĊæĴìÐīÐĉďĴÐÆďĊĴīďăăÐīĴďĴìÐĮĉīĴĨìďĊÐȿȿȿȿȿȿȿȿȿȿ7
īīĊĴřȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ8
ķĴðďĊȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ8
wĴďīæÐĊÌTðĊĴÐĊĊÆÐȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ8
ďĊĴÆĴĮȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿȿ9
Schematic View of Porodo Gimbal
A: Smartphone Holder
B: Bluetooth Indicator
C: Battery Level Indicator
D: Camera
E: Tracking Indicator
F: Power Button
G: Gesture Indicator
B: Bluetooth Indicator
1ȘwăďœăřŦĮìðĊæăðæìĴȚăķÐĴďďĴìðĮĊďĴÆďĊĊÐÆĴÐÌȘ
2Ș9ĮĴŦĮìðĊæăðæìĴȚăķÐĴďďĴìðĮĮĴðăăÆďĊĊÐÆĴðĊæȘ
3. Indicator light is solid (on): Bluetooth is connected.
Note:The Bluetooth indicator is paired with the remote in case the remote is
connecte to the Gimbal.
C: Battery Level Indicator
1Ș}ìÐťīĮĴO'#ăðæìĴðĮŦĮìðĊæȚ%1 to %3.
2Ș}ìÐĮÐÆďĊÌO'#ăðæìĴðĮŦĮìðĊæȚ%4 to %50.
3Ș}ìÐĴìðīÌO'#ăðæìĴðĮŦĮìðĊæȚ%51 to %99.
4. All Three lights are ON: %100.
E: Tracking Indicator
1. Light is ON: The tracking feature is activated and the face is recognized.
2Ș OðæìĴ ðĮ Įăďœăř ŦĮìðĊæȚ }ìÐ ĴīÆāðĊæ åÐĴķīÐ ðĮ ÆĴðŒĴÐÌ ĊÌ UZ åÆÐ ðĮ
recognized.
3. Light is OFF: The tracking feature is deactivated.
01
M
L
K
J
I
H
H: Switch for rotation of holder from landscape to portrait position and vice
versa.
I: Tilt Angle Adjustment
J: Input/ Output : Type-C USB port
K: Base Clip
L: Base Screw (Thread: 1/4")
M: Base
Note: To remove the device from the base, press the base clip and rotate the
Gimbal.
02
Getting Started
1.Installing the Smartphone
2.Power Button
Use the power button to turn the device ON/OFF.
The function of the power button includes as follows:
1. Long pressing the power button: Turns the Gimbal
ON.
2.Double pressing the power button: Activates/
Deactivates
the face tracking feature.
3.Triple pressing the power button: Activates/Deactivates
the face gesture recognition feature.
4.Pressing the power button continuously: The Gimbal
rotates clockwise.
Note:The face tracking and gesture recognition
features are enabled upon powering on the Gimbal.
03
Install the smartphone securely,
as illustrated by the picture. It
might be necessary to remove
the phone casing beforehand.
3.AI Gesture Recognition
To turn ON the face tracking feature:
Perform an "OK" gesture before the camera.
To turn OFF the face tracking feature: Make
the "Palm" gesture before the camera.
Tips:
1. To start tracking no Bluetooth connection or installation of App is required.
2. The optimal distance for gesture recognition is 0.5 to 2.5 m distance from
the camera.
3. The optimal distance for face tracking is 0.5 to 3.5 m distance from the
camera.
4. The tracking feature can be used during photography, video recording, live
broadcasting, and performing video calls.
04
wĨÐÆðťÆĴðďĊ
Net Weight 269 gr
Material ABS+PC
Dimensions (Gimbal) 58.5×58.8×188 mm
Dimension (Base) 100 mm
Payload 500 gr
Battery capacity 4000 mAh
Charging input Type-C cable (5V/2A)
Diagonal: 180 mm
Width: 5 to 90 mm
Thickness: 9.5 mm
Compatible smartphone
range
Device Bluetooth name "Z9_XXXX"
Schematic View of the Remote
A
B
C
D
E
F
G
H
I
05
A: Bluetooth/Power Indicator
Red light: Change the battery.
Flashing blue light: The remote is not connected to the Gimbal.
Flashing twice in blue light: The Remote is paired with the Gimbal.
Solid blue light: The remote is successfully connected to the Gimbal.
Note: The remote is connected to the Gimbal via Bluetooth connection.
B: Left Key
(1) Single press: The Gimbal rotates 3° clockwise.
(2) Pressing continuously: The Gimbal rotates continuously in a clockwise
direction.
C: Power Button
D: Down Key (Not included in this model)
E: Function Button
(1) Double press: Activates/Deactivates face tracking feature.
(2) Triple press: Activates/Deactivates gesture recognition feature.
F: Up Key (Not included in this model)
G: Right Key
(1) Single press: The Gimbal rotates 3° counterclockwise.
(2) Pressing continuously: The Gimbal rotates continuously in a counterclockwise
direction.
H: Zoom Button (Not included in this model)
I: Shutter Button
Notes:
1. The 'Down Key', 'Up Key', and 'Zoom Button' are not included in this model.
2. The 'Shutter Button' functions if the remote is connected to smartphone via
Bluetooth.
3. To enable a continuous rotation of the Gimbal, press the Left Key and Right
Key at the same time for 3 seconds.
06
Steps to pairing the remote
1. Pairing the remote to the Gimbal
With the assumption that both the remote and Gimbal are powered off,
proceed with the following steps:
1.1 Start the remote and the Gimbal at the same time.
1.2 Keep pressing the power button for 5seconds until the Bluetooth indicator
light is solid and blue-colored.
2. Pairing the remote to the smartphone
Enable Bluetooth on your smartphone. Look for "Z9_XXXX" and connect. By
pairing the smartphone to the remote, the user will be able to control and
navigate the camera features of the camera.
07
Caution
1. Ensure nothing hinders the motor's movement while the Gimbal is being
used.
2ȘŒďðÌÆďĊĴÆĴœðĴìĮÐœĴÐīďīĊřÆďīīďĮðŒÐŦķðÌĮȘ
3. Disassembly of the detachable Gimbal accessories is allowed according to
the user manual.
4. Continuous motor operation over a long duration may cause the motor to
overheat.
5. Dropping or striking the Gimbal is strictly prohibited as it may lead to
damage and malfunctioning.
Storage and Maintenance
1. Keep the product out of reach of children and pets.
2. Do not place the product near any heat sources, and avoid leaving it in a
vehicle on a hot day.
3. Store the product in a dry area to prevent damage.
4. Avoid overcharging or completely discharging the battery, as it could result
in damage.
5. Do not operate the product in extremely high or low temperatures.
Warranty
qīďÌķÆĴĮĴìĴřďķÅķřÌðīÐÆĴăřåīďĉďķīqďīďÌďœÐÅĮðĴÐďīĮìďĨÆďĉÐœðĴìɁ
24ȭĉďĊĴìɁœīīĊĴřȘɁ
When you buy Porodo products from any of our approved sellers, you only get
Ɂ12ȭĉďĊĴìɁœīīĊĴřȘAåřďķœĊĴĴďÐŘĴÐĊÌĴìðĮœīīĊĴřșæďĴďďķīœÐÅĮðĴÐĴɁ
ìĴĴĨĮȚȥȥĨďīďÌďȘĊÐĴȥœīīĊĴřɁĊÌťăăďķĴĴìÐåďīĉœðĴìřďķīðĊåďīĉĴðďĊȘ
08
