Porter-Cable C5512 Manuale utente

C5512

www.deltaportercable.com

INSTRUCTIVO DE OPERACIÓN, CENTROS

DE SERVICIO Y PÓLIZA DE GARANTÍA.

LÉASE ESTE INSTRUCTIVO

ANTES DE USAR EL PRODUCTO.

Français : Page 29

Español: Página 59

Air Compressor

Compresor de aire

Compresseur d’air

Instruction manual

Manuel d'instructions

Manual de instrucciones

2- ENG

SAFETY GUIDELINES - DEFINITIONS

This manual contains information that is important for you to know and understand.

This information relates to protecting YOUR SAFETY and PREVENTING

EQUIPMENT PROBLEMS. To help you recognize this information, we use the

symbols below. Please read the manual and pay attention to these symbols.

Indicates an imminently

hazardous situation which, if not

avoided, will result in death or serious

injury.

Indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury.

Indicates a potentially

hazardous situation which, if not

avoided, could result in death or

serious injury.

Indicates a practice

not related to personal injury which,

if not avoided, may result in property

damage.

IMPORTANT SAFETY INSTRUCTIONS

This product contains chemicals known to the State of California

to cause cancer, and birth defects or other reproductive harm. Wash hands after

handling.

Some dust contains chemicals known to the State of California

to cause cancer, birth defects or other reproductive harm such as asbestos and

lead in lead based paint.

To reduce the risk of injury, read the instruction manual.

SAVE THESE INSTRUCTIONS

HAZARD

RISK OF EXPLOSION OR FIRE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Itisnormalforelectrical

contacts within the motor and

pressure switch to spark.

• Alwaysoperatethecompressor

in a well ventilated area free

of combustible materials,

gasoline, or solvent vapors.

• Ifelectricalsparksfrom

compressor come into contact

with flammable vapors, they may

ignite, causing fire or explosion.

• Ifsprayingflammablematerials,

locate compressor at least

20' (6.1 m) away from spray

area. An additional length of

air hose may be required.

• Storeflammablematerials

in a secure location away

from compressor.

3- ENG

• Restrictinganyofthecom-

pressor ventilation openings

will cause serious overheat-

ing and could cause fire.

• Neverplaceobjectsagainst

or on top of compressor.

• Operatecompressorinanopen

area at least 12" (30.5 cm) away

from any wall or obstruction that

would restrict the flow of fresh

air to the ventilation openings.

• Operatecompressorina

clean, dry well ventilated area.

Do not operate unit in any

confined area. Store indoors.

• Unattendedoperationofthisprod-

uct could result in personal injury

or property damage. To reduce the

risk of fire, do not allow the com-

pressor to operate unattended.

• Alwaysremaininattendancewith

the product when it is operating.

• Alwaysturnoffandunplug

unit when not in use.

HAZARD

RISK TO BREATHING (ASPHYXIATION)

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairdirectlyfrom

your compressor is not safe for

breathing. The air stream may

contain carbon monoxide, toxic

vapors, or solid particles from the air

tank. Breathing these contaminants

can cause serious injury or death.

• Neveruseairobtaineddirectly

from the compressor to supply

air for human consumption. The

compressor is not equipped with

suitable filters and in-line safety

equipment for human consumption.

• Exposuretochemicalsindust

created by power sanding,

sawing, grinding, drilling,

and other construction

activities may be harmful.

• Sprayedmaterialssuchaspaint,

paint solvents, paint remover,

insecticides, weed killers, may

contain harmful vapors and poisons.

• Workinanareawithgoodcross

ventilation. Read and follow

the safety instructions provided

on the label or safety data

sheets for the materials you are

spraying. Always use certified

safety equipment: NIOSH/OSHA

respiratory protection or properly

fitting face mask designed for use

with your specific application.

4- ENG

HAZARD

RISK OF BURSTING

Air Tank: On February 26, 2002, the U.S. Consumer Product Safety Commission

published Release # 02-108 concerning air compressor tank safety:

Air compressor receiver tanks do not have an infinite life. Tank life is dependent

upon several factors, some of which include operating conditions, ambient condi-

tions, proper installations, field modifications, and the level of maintenance. The

exact effect of these factors on air receiver life is difficult to predict.

If proper maintenance procedures are not followed, internal corrosion to the

inner wall of the air receiver tank can cause the air tank to unexpectedly rupture

allowing pressurized air to suddenly and forcefully escape, posing risk of injury to

consumers.

Your compressor air tank must be removed from service by the end of the year

shown on your tank warning label.

The following conditions could lead to a weakening of the air tank, and result in a

violent air tank explosion:

WHAT CAN HAPPEN HOW TO PREVENT IT

• Failuretoproperlydraincondensed

water from air tank, causing rust

and thinning of the steel air tank.

• Drainairtankdailyoraftereachuse.

If air tank develops a leak, replace

it immediately with a new air tank

or replace the entire compressor.

• Modificationsorattempted

repairs to the air tank. • Neverdrillinto,weld,ormakeany

modifications to the air tank or its

attachments. Never attempt to

repair a damaged or leaking air

tank. Replace with a new air tank.

• Unauthorizedmodifications

to the safety valve or any

other components which

control air tank pressure.

• Theairtankisdesignedtowithstand

specific operating pressures.

Never make adjustments or

parts substitutions to alter the

factory set operating pressures.

Attachments & accessories:

• Exceedingthepressurerat-

ing of air tools, spray guns, air

operated accessories, tires,

and other inflatables can cause

them to explode or fly apart, and

could result in serious injury.

• Followtheequipmentmanufacturers

recommendation and never exceed

the maximum allowable pressure

rating of attachments. Never use

compressor to inflate small low

pressure objects such as children’s

toys, footballs, basketballs, etc.

5- ENG

Tires:

• Over inflation of tires could

result in serious injury

and property damage.

• Useatirepressuregaugetocheck

the tires pressure before each use

and while inflating tires; see the tire

sidewall for the correct tire pressure.

NOTE: Air tanks, compressors and

similar equipment used to inflate

tires can fill small tires very rapidly.

Adjust pressure regulator on air

supply to no more than the rating

of the tire pressure. Add air in small

increments and frequently use the

tire gauge to prevent over inflation.

HAZARD

RISK OF ELECTRICAL SHOCK

WHAT CAN HAPPEN HOW TO PREVENT IT

• Yourcompressorispoweredby

electricity. Like any other electrically

powered device, if it is not used

properly it may cause electric shock.

• Neveroperatethecompressor

outdoors when it is raining

or in wet conditions.

• Neveroperatecompressor

with protective covers

removed or damaged.

• Repairsattemptedbyunqualified

personnel can result in serious

injury or death by electrocution.

• Anyelectricalwiringorrepairs

required on this product should be

performed by authorized service

center personnel in accordance with

national and local electrical codes.

• Electrical Grounding: Failure to

provide adequate grounding to

this product could result in serious

injury or death from electrocution.

Refer to Grounding Instructions

paragraph in the Installation section.

• Makecertainthattheelectrical

circuit to which the compressor

is connected provides proper

electrical grounding, correct voltage

and adequate fuse protection.

HAZARD

RISK OF SERIOUS INJURY OR PROPERTY DAMAGE

WHEN TRANSPORTING COMPRESSOR

WHAT CAN HAPPEN HOW TO PREVENT IT

• Oilcanleakorspillandcouldresult

in fire or breathing hazard; serious

injury or death can result. Oil leaks

will damage carpet, paint or other

surfaces in vehicles or trailers.

• Alwaysplacecompressorona

protective mat when transporting to

protect against damage to vehicle

from leaks. Remove compressor

from vehicle immediately upon

arrival at your destination.

6- ENG

HAZARD

RISK FROM FLYING OBJECTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairstreamcan

cause soft tissue damage to

exposed skin and can propel dirt,

chips, loose particles, and small

objects at high speed, resulting in

property damage or personal injury.

• Alwayswearcertifiedsafety

equipment: ANSI Z87.1 eye

protection (CAN/CSA Z94.3)

with side shields when

using the compressor.

• Neverpointanynozzleorsprayer

toward any part of the body or

at other people or animals.

• Alwaysturnthecompressor

off and bleed pressure from

the air hose and air tank before

attempting maintenance,

attaching tools or accessories.

HAZARD

RISK OF HOT SURFACES

WHAT CAN HAPPEN HOW TO PREVENT IT

• Touchingexposedmetalsuch

as the compressor head, engine

head, engine exhaust or outlet

tubes, can result in serious burns.

• Nevertouchanyexposedmetal

parts on compressor during or

immediately after operation.

Compressor will remain hot for

several minutes after operation.

• Donotreacharoundprotective

shrouds or attempt maintenance

until unit has been allowed to cool.

HAZARD

RISK FROM MOVING PARTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Movingpartssuchasthepulley,

flywheel, and belt can cause

serious injury if they come into

contact with you or your clothing.

• Neveroperatethecompressor

with guards or covers which

are damaged or removed.

• Keepyourhair,clothing,and

gloves away from moving parts.

Loose clothes, jewelry, or long hair

can be caught in moving parts.

• Airventsmaycovermovingparts

and should be avoided as well.

• Attemptingtooperatecompressor

with damaged or missing parts or

attempting to repair compressor

with protective shrouds removed

can expose you to moving parts

and can result in serious injury.

• Anyrepairsrequiredonthisproduct

should be performed by authorized

service center personnel.

7- ENG

HAZARD

RISK OF UNSAFE OPERATION

WHAT CAN HAPPEN HOW TO PREVENT IT

• Unsafeoperationofyour

compressor could lead to serious

injury or death to you or others.

• Reviewandunderstandall

instructions and warnings

in this manual.

• Becomefamiliarwiththeoperation

and controls of the air compressor.

• Keepoperatingareaclearofall

persons, pets, and obstacles.

• Keepchildrenawayfromthe

air compressor at all times.

• Donotoperatetheproduct

when fatigued or under the

influence of alcohol or drugs.

Stay alert at all times.

• Neverdefeatthesafetyfea

tures of this product.

• Equipareaofoperation

with a fire extinguisher.

• Donotoperatemachine

with missing, broken, or

unauthorized parts.

HAZARD

RISK OF FALLING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Aportablecompressorcanfall

from a table, workbench, or roof

causing damage to the compressor

and could result in serious injury

or death to the operator.

• Alwaysoperatecompressorina

stable secure position to prevent

accidental movement of the unit.

Never operate compressor on a

roof or other elevated position. Use

additional air hose to reach high

locations.

HAZARD

RISK OF INJURY FROM LIFTING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Seriousinjurycanresult

from attempting to lift

too heavy an object.

• Thecompressoristooheavytobe

lifted by one person. Obtain assis-

tance from others before lifting.

8- ENG

RISK FROM NOISE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Undersomeconditionsandduration

of use, noise from this product

may contribute to hearing loss.

• Alwayswearcertifiedsafety

equipment: ANSI S12.6

(S3.19) hearing protection.

SAVE THESE INSTRUCTIONS

FOR FUTURE USE

SPECIFICATION CHART

Model No. C5512

Running Horsepower 1.6 *

Bore 2.875" (73.0 mm)

Stroke 2" (50.8 mm)

Voltage 120/240

Hz-Single Phase 60

Minimum Branch Circuit Requirement 15 amps

Fuse Type Time Delay

Air Tank Capacity (Gallon) 20 (75.7 liters)

Approximate Cut-in Pressure 120 PSIG

Approximate Cut-out Pressure 150 PSIG

SCFM @ 40 psig 7.3 *

SCFM @ 90 psig 5.7 *

* Tested per ISO 1217

Refer to Glossary for abbreviations.

GLOSSARY

Become familiar with these terms before operating the unit.

CFM: Cubic feet per minute.

SCFM: Standard cubic feet per minute; a unit of measure of air delivery.

PSIG: Pounds per square inch gauge; a unit of measure of pressure.

Code Certification: Products that bear one or more of the following marks: UL®,

CUL, ETL®, CETL, have been evaluated by OSHA certified independent safety

laboratories and meet the applicable Standards for Safety.

Cut-In Pressure:Whilethemotorisoff,airtankpressuredropsasyoucontinue

touseyouraccessory.Whenthetankpressuredropstoacertainlowlevelthe

motor will restart automatically. The low pressure at which the motor automatically

restarts is called "cut-in" pressure.

Cut-Out Pressure:When anaircompressoristurned onandbegins torun,air

pressure in the air tank begins to build. It builds to a certain high pressure before

the motor automatically shuts off - protecting your air tank from pressure higher

than its capacity. The high pressure at which the motor shuts off is called "cut-out"

pressure.

Branch Circuit: Circuit carrying electricity from electrical panel to outlet.

9- ENG

DUTY CYCLE

This air compressor pump is capable of running continuously. However, to prolong

the life of your air compressor, it is recommended that a 50%-75% average duty

cycle be maintained; that is, the air compressor pump should not run more than

30-45 minutes in any given hour.

ACCESSORIES

Accessories for this unit are available at the store the unit was purchased.

The use of any other accessory not recommended for use

with this tool could be hazardous. Use only accessories rated equal to or

higher than the rating of the air compressor.

ASSEMBLY

TOOLS REQUIRED FOR ASSEMBLY

1 - 9/16" socket or open end wrench

1 - 1/2" socket or open end wrench

UNPACKING

Remove unit from carton and discard all packaging. NOTE: Save all parts bags.

This compressor was shipped with oil in the pump crankcase.

Check oil before operating air compressor, see Check Oil under Maintenance.

TO INSTALL HANDLE

The wheels and handle do not provide adequate clearance,

stability, or support for pulling the unit up and down stairs or steps. The unit must

be lifted or pushed up a ramp. Do not lift the unit by the manifold assembly, the

unit could be damaged.

1. To make installation easier, submerge handle grip into warm soapy water.

Remove handle grip from soapy water and slide onto handle.

2. Insert the open end of the handle under the saddle. Before attaching handle,

you may have to pull the open ends of the handle apart so they fit tightly

against the side of the saddle. Looking in from the open end of the saddle,

position the handle toward the two bent tabs, on the inside walls of the

saddle.

3. Slowly push the open ends of the handle onto both tabs at the same time.

Continue pushing the handle into the saddle until the holes on the side of the

saddle and handle are in line.

Saddle Hole

Handle

Hole

Bent Tabs

Open End

Of Handle

Bent Tabs

Saddle

Open End

Of Handle

Open

End Of

Saddle

10- ENG

4. Guide the straight end of each retaining

Handle

Inserted

On Tabs

Retaining

Clip

Handle

clip through the saddle hole and both

handle holes.

5. Rotate each retaining clip and press

down until it snaps into place over the

handle.

6. If the handle has excessive movement,

it is improperly installed. Check the

following.

A. Are both tabs inside the handle?

B. Does each clip pass through both

the saddle and handle?

TO ASSEMBLE WHEELS

It will be necessary to brace or

Wheel

Shoulder Bolt

Nut

support one side of the unit when installing

the wheels because the compressor will have

a tendency to tip.

1. Attach wheels with shoulder bolts and

nuts as shown.

2. Tighten securely. NOTE: The unit will sit

level if the wheels are properly installed.

The wheels and handle do

not provide adequate clearance, stability or

support for pulling the unit up and down

stairs or steps. The unit must be lifted, or

pushed up a ramp.

ASSEMBLE RUBBER FEET

Screw

Nut

Flat

Washer

Rubber Foot

1. Attach rubber feet with the screws,

washers, and nuts provided as shown.

2. Tighten securely.

INSTALLATION

HOW TO SET UP YOUR UNIT

Location of the Air Compressor

• Locatetheaircompressorinaclean,dryandwellventilatedarea.

• Theaircompressorshouldbelocatedatleast12"(30.5cm)awayfromthe

wall or other obstructions that will interfere with the flow of air.

• Theaircompressorpumpandshroudaredesignedtoallowforpropercooling.

Do not place rags or other objects on top of compressor.
