Potterton Paramount two Manuale di istruzioni

Working towards

a cleaner future

Paramount two

Wall hung condensing boiler

30 – 115kW

Installation, operation & maintenance manual

Aprill 2011

heating specialists

2 POTTERTONCOMMERCIAL

120-393 632.4 04.08 Fh

Table of contents

1. Regarding this Manual. . . . . . . . . . . . . . . . . . . . . . .4

1.1 Content of this manual . . . . . . . . . . . . . . . . . . . . . . .4

1.2 Used symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

1.3 For whom is this manual intended? . . . . . . . . . . . . . . .4

2. Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2.1 General safety precautions . . . . . . . . . . . . . . . . . . . .5

2.2 Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2.3 Installations/Instructions. . . . . . . . . . . . . . . . . . . . . .6

2.4 Regulations and standards . . . . . . . . . . . . . . . . . . . . .6

2.5 C.E. Approvals. . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

2.6 Conformity declaration . . . . . . . . . . . . . . . . . . . . . . .8

3. Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . .9

3.1 Dimensions and connections PARAMOUNT two 30/40 . . .9

3.2 Dimensions and connections PARAMOUNT two 60-115 . . 11

3.3 Technical Data PARAMOUNT two. . . . . . . . . . . . . . . . 13

3.4 Wiring diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3.5 Sensor value tables. . . . . . . . . . . . . . . . . . . . . . . . .15

4. Before installation . . . . . . . . . . . . . . . . . . . . . . . .16

4.1 Combustion air supply. . . . . . . . . . . . . . . . . . . . . . . 16

4.2 Corrosion protection. . . . . . . . . . . . . . . . . . . . . . . . 17

4.3 System water quality . . . . . . . . . . . . . . . . . . . . . . . 17

4.4 Use of additives (e.g. hardness stabilsisers,

frost protective agents, sealing agents) . . . . . . . . . . . 17

4.5 Notes for installation location . . . . . . . . . . . . . . . . . 18

4.6 Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

4.7 Application example. . . . . . . . . . . . . . . . . . . . . . . . 19

5. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

5.1 Connecting to the heating system . . . . . . . . . . . . . . . 21

5.2 Condensate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.3 Filling the heating system . . . . . . . . . . . . . . . . . . . . 21

5.4 Flue connection. . . . . . . . . . . . . . . . . . . . . . . . . . .21

5.5 Flue system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

5.6 Flue terminal positioning. . . . . . . . . . . . . . . . . . . . . 23

5.7 Gas connection . . . . . . . . . . . . . . . . . . . . . . . . . . .24

5.8 CO2-Content. . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

5.9 Changing over from LPG to natural gas and vice versa. . 25

5.10Gas valve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

5.11Guide Values for Injector Pressure . . . . . . . . . . . . . . 28

5.12Electrical connection (general). . . . . . . . . . . . . . . . . 28

120-393 632.4 04.08 Fh

PARAMOUNT two 30 - 115 kW 3

6. Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.1 Switching on . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

6.2 Temperatures for heating and DHW. . . . . . . . . . . . . .30

6.3 Individual time program . . . . . . . . . . . . . . . . . . . . .30

6.4 Programming of necessary parameters . . . . . . . . . . . .31

6.5 Emergency operation (Manual operation) . . . . . . . . . .31

6.6 Instruction for the customer. . . . . . . . . . . . . . . . . . .31

7. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

7.1 Operation elements . . . . . . . . . . . . . . . . . . . . . . . .32

7.2 Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

7.3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

8. Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

8.1 Programming procedure . . . . . . . . . . . . . . . . . . . . .36

8.2 Modification of parameters . . . . . . . . . . . . . . . . . . .37

8.3 Setting table . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

8.4 Explanations for setting table . . . . . . . . . . . . . . . . .46

9. General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

9.1 Room unit RGT . . . . . . . . . . . . . . . . . . . . . . . . . . .61

10.Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

10.1Maintenance work . . . . . . . . . . . . . . . . . . . . . . . . .62

10.2Replace air-vent . . . . . . . . . . . . . . . . . . . . . . . . . .62

10.3Condensate siphon . . . . . . . . . . . . . . . . . . . . . . . . .62

10.4Removing gas burner. . . . . . . . . . . . . . . . . . . . . . . .63

10.5Protection against electrical shock . . . . . . . . . . . . . .66

10.6Boiler view PARAMOUNT two . . . . . . . . . . . . . . . . .67

10.7Dismantling the heat exchanger . . . . . . . . . . . . . . . .70

10.8Check electrodes . . . . . . . . . . . . . . . . . . . . . . . . . .70

10.9Control and regulating centre LMU . . . . . . . . . . . . . .71

10.10Fault switch-off . . . . . . . . . . . . . . . . . . . . . . . . . .71

10.11Fault code table . . . . . . . . . . . . . . . . . . . . . . . . . .73

10.12Operation phases of control and regulation centre LMU

(Press information button). . . . . . . . . . . . . . . . . . . .74

11.Commissioning report . . . . . . . . . . . . . . . . . . . . 76

Regarding this Manual

4 POTTERTONCOMMERCIAL

120-393 632.4 04.08 Fh

1. Regarding this Manual

Read this instruction booklet thoroughly before operating the boi-

ler!

1.1 Content of this manual

This manual contains the instructions for the installation of the PA-

RAMOUNT two for standard applications with 1 heating circuit and/

or 1 DHW circuit (WWF tank sensor required for DHW).

Further applications can be made available (for multiple boilers

and multiple zones) by installing extension modules (clip-ins).

Keep all documents at the installation location of the boiler!

1.2 Used symbols

1.3 For whom is this manual intended?

This installation manual is intended for the heating specialist.

Danger! Danger exists for body and life in case it is not observed.

Danger of electric shock! In case it is not observed, danger from

electricity exists for body and life!

Attention! If warning is not observed, danger exists for environ-

ment and the device.

Note/tip: Here, you can find background information and useful

tips.

Reference to additional information in other documents.

Safety

120-393 632.4 04.08 Fh

PARAMOUNT two 30 - 115 kW 5

2. Safety

Danger! Absolutely observe the following safety instructions!

Otherwise, you may endanger yourself and others.

2.1 General safety precautions

Installation of System:

Important: The boiler must be commissioned following completion

of installation. Operation of an un-commissioned appliance may

cause injury to personnel and damage to the boiler unit which

would invalidate the warranty.

Commissioningmust only be carried out bypersonnelapproved and

competent to do so. This facility is available from Potterton Com-

mercial Service Office.

Important: the boiler unit is supplied in accordance with Potterton

Commercial quality assurance plan registered to meet the require-

ments of BSN ISO 9002. A condition of the supply of the appliance

for compliance with this is the return of the appliance commissio-

ning report.

Electrical Installation:

The electrical installation work must be carried out by a qualified

electrician.

Gas Installation:

Boiler installation as well as commissioning, servicing and mainte-

nance must be carried out by an approved gas installer. For use

with natural gas (G20) nominal supply pressure 20 mbar (LPG opti-

on available).

2.2 Use The POTTERTON PARAMOUNT two wall hung condensing boiler is

available in six sizes with outputs from 30 kW to 115 kW.

They are CE marked for use on Natural Gas (LPG) on open vented

systems (min 1 bar) and are suitable for use on sealed systems with

a maximum operating pressure of 3 bar (30/40 kW), 4 bar (60 -

115 kW). Refer to relevant British Standards and Codes of Practice

for installation of condensing boilers on sealed system. The heat

exchanger consists of aluminium - silicon alloy, which allows very

compact and lightweight boiler construction. The fully premix bur-

ner works in a modulating range of between 25 % and 100 %. There-

fore the boiler can adapt to the particular heat requirements of

thecircuit.The gas/airratiocontrol ensuresuniformCO2emissions

and low NOx. This is obtained by comparing the target boiler tem-

perature and actual boiler temperature. If there is a difference

between these two values then the internal microprocessor calcu-

lates a new fan speed. The change in fanspeed in turn changes the

combustion chamber static air pressure which is monitored by the

gas/air ratio control and the gas rate is adjusted thus maintaining

the correct gas to air ratio in the boiler. This ensures that a uniform

Safety

6 POTTERTONCOMMERCIAL

120-393 632.4 04.08 Fh

gas/air ratio is maintained over the total range of the boiler mo-

dulation, and that constant CO2values are achieved.

For optimum utilisation condensing boilers should be operated at

a low return temperature. However the PARAMOUNT two will also

work at designed temperatures of 70/50°C. In the condensing

mode as the return temperature is below the dew point (dew point

is 53°C at 8.5 % CO2).

They fulfil EN 483 and EN 677, Type C. Installation types B23, B33,

C13x, C33x, C43x, C63x. Emission value group G 61.

Category II2H3P.

2.3 Installations/Instructions

Before starting work a risk assessment should be carried out in the

boiler house and its access to ensure a safe installation and wor-

king environment. Any person installing or working on the boiler

must be qualified and attention is drawn to the mandatory require-

ments of C.O.R.G.I. registration for all gas installers.

Manual Handling: Any person or persons moving or lifting the boiler

or any part there of should be trained in manual handling techni-

ques and if necessary use suitable lifting equipment to reduce the

risk of injury to themselves or other people.

2.4 Regulations and standards

The installation should comply with relevant British Standard Spe-

cifications, Codes of Practice and current Building Regulations, to-

gether with any special regional requirements of the Local

Authorities, Gas undertaking and Insurance I.E.E. Regulations for

the Electrical Equipment of Buildings. The installation of the boiler

must be in accordance with the relevant requirements of:

Health and Safety at Work act 1974

Building Regulations 2006

Electricity at Work Regulation 1989

Management of H&S at Work Regulations 1998

Manual Handling Regulations 1992

Model Water By-Laws 1986

BS 7671: 1992 - Requirements for Electrical Installations, IEE Wi-

ring Regulations Sixteenth Edition.

BS 5440: 2000: Part 1 - Specifications for Installation of Flues

BS 5440: 2000: Part 2 - Specifications for Installation of Ventilation

for Gas Appliances.

BS 6644: 2005 - Installations of Gas Fired Hot Water Boilers for in-

puts between 60 kW and 2 MW.

BS 7074: 1989: Part 2 - application Selection and Installation of Ex-

pansion Vessels and Ancillary Equipment for Sealed Water Systems.

BS 6880: 1988 - codes of Practice for Low temperature Hot Water

Systems.

EN 677: 1997 - Gas Fired Central Hating Boilers for Condensing Boi-

lers with a nominal heat input not exceeding 70 kW.

CP 342:2 - Centralised Hot Water Supply Gas Safety (Installation

and Use) Regulations 1998

Safety

120-393 632.4 04.08 Fh

PARAMOUNT two 30 - 115 kW 7

IM/II - Flues for commercial and Industrial Gas Fired Boilers and Air

Heaters.

IGE/UP/1 - Soundness Testing and Purging Procedure for Non Do-

mestic Installations.

IGE/UP/2 - Gas Installation Pipe work, Boosters and Compressors

for Industrial Commercial Premises.

Manufacturer's notes must not be taken in any way as over-riding

statutory obligations.

2.5 C.E. Approvals The CE approval symbol means that the boilerfulfils the basic re-

quirements of the Gas Equipment Directive 90/396/EEC, the Low

Voltage Directive 73/23/EEC as well as Directive 89/336/EEC

(Electromagnetic Compatibility EMC) of the Council for Unification

of Legal Regulations of the members Countries. The boiler fulfils

the basic requirements of the Boiler Efficiency Directive 92/43/

EEC for condensing boilers.

Safety

8 POTTERTONCOMMERCIAL

120-393 632.4 04.08 Fh

2.6 Conformity declaration

Paramount two 30 - 115

Technical Data

120-393 632.4 04.08 Fh

PARAMOUNT two 30 - 115 kW 9

3. Technical Data

3.1 Dimensions and connections PARAMOUNT two 30/40

Fig. 1: Dimensions and connections PARAMOUNT two 30/40

Technical Data

10 POTTERTONCOMMERCIAL

120-393 632.4 04.08 Fh

Table 1: Dimensions and connections PARAMOUNT two 30/40

Model 30 / 40

HV –Heatingflow G 1“

HR – Heating return G 1“

Gas – Gas connection G 3/4“

SiV –Safetyvalve G 3/4“

KA – Condensate water connection Ø 25 mm

Dimension A [mm] 116

Dimension E [mm] 177

Dimension F [mm] 185

Dimension G [mm] 192

Dimension H [mm] 407

Indice

Altri manuali Potterton Caldaia

Potterton

Potterton eurocondense four 125 kw Istruzioni generali

Potterton

Potterton Promax 15 HE Istruzioni di installazione e manutenzione

Potterton

Potterton Prorile Prima 30e Guida utente

Potterton

Potterton EC three 125 Manuale utente

Potterton

Potterton Osprey CF 180 Istruzioni di installazione e manutenzione

Potterton

Potterton Sirius WH 50-60-70 Manuale di istruzioni

Potterton

Potterton Heatmax Combi HE Range Istruzioni di installazione e manutenzione

Potterton

Potterton Kingfisher Mf Manuale utente

Potterton

Potterton Suprima 80 HE Manuale di istruzioni

Potterton

Potterton Titanium 12 Heat Guida rapida

Potterton

Potterton Performa 24 Eco HE Istruzioni di installazione e manutenzione

Potterton

Potterton Promax Combi HE Plus A Range Istruzioni di installazione e manutenzione

Potterton

Potterton assure combi 25 Manuale

Potterton

Potterton Performa 24 Guida utente

Potterton

Potterton Titanium 24 Istruzioni di installazione e manutenzione

Potterton

Potterton Puma Flowsure+ Istruzioni di installazione e manutenzione

Potterton

Potterton Puma 100 Istruzioni di installazione e manutenzione

Potterton

Potterton Suprima 100 Istruzioni di installazione e manutenzione

Potterton

Potterton Promax System HE Guida utente

Potterton

Potterton Statesman 45/50 Istruzioni di installazione e manutenzione

Potterton

Potterton Performa 24 Eco HE Guida rapida

Potterton

Potterton Eden Two Series Specifiche tecniche

Potterton

Potterton Gold 24 HE Istruzioni di installazione e manutenzione

Potterton

Potterton Performa 28i Guida utente

Manuali Caldaia popolari di altre marche

Vaillant

Vaillant uniSTOR VIH SW GB 500 BES Manuale utente

Radijator

Radijator BIO max 23.1 Manuale utente

Brunner

Brunner BSV 20 Manuale utente

Buderus

Buderus Logamax GB062-24 KDE H V2 Manuale utente

UTICA BOILERS

UTICA BOILERS TriFire Manuale utente

Joannes

Joannes LADY Series Manuale

ECR International

ECR International UB90-125 Manuale di istruzioni

Froling

Froling FHG Turbo 3000 Manuale utente

Froling

Froling P4 Pellet 8 - 105 Manuale utente

U.S. Boiler Company

U.S. Boiler Company K2 Manuale utente

Henrad

Henrad C95 FF Manuale utente

NeOvo

NeOvo EcoNox EF 36 Manuale utente

Eco Hometec

Eco Hometec EC 25 COMPACT Manuale utente

Viessmann

Viessmann VITODENS 200 Guida

Baxi

Baxi Prime 1.24 Manuale utente

REXNOVA

REXNOVA ISA 20 BITHERMAL Manuale utente

Radiant

Radiant R2K 55 Manuale

Worcester

Worcester Greenstar 36LXi Manuale utente
