Pneumatic Detail Polishing Kit
A 29 piece, lightweight pneumatic detail polishing kit,
for buffing & polishing intricate areas on any vehicle
to achieve a rich, swirl
free, high gloss finish.
2
www.power-tec.co.uk
92559
Pneumatic Detail Polishing Kit
Introduction:
This new air-powered detail polisher is ultra-compact and lightweight, which
makes it easy to use in confined areas. Ideal for all spot repair and touch-up
work. Polish and finish areas that have previously been inaccessible: inside
door handles, the back of the door mirror, and areas adjacent to body fittings
such as grilles, badges, etc. The polisher is super-slim and the backing and
polishing pads just 25-30mm in diameter.
Hook and loop backing pad for quick change between different pads.
Comprehensive range of polishing pads (four grades — from cutting to final
finishing), felt mops and lambswool pads. Also included are a pair of detail
felt point mops, just 11.5mm in diameter. Spare pads are available. Easy
to operate speed control. This tool delivers low noise and low vibration for
safety and comfort in use. Useful 130cm flexible air line keeps the heavy
workshop air line away from the job.
3
www.power-tec.co.uk
Accessories included:
4
www.power-tec.co.uk
92559
Pneumatic Detail Polishing Kit
Please read this instruction manual carefully before operating the tool
and always keep this manual within easy reach.
Ref. Component
ABacking pad (25mm) x 2
BSponge pad green, cutting (30mm) x 2
CSponge pad yellow, compounding (30mm) x 2
DSponge pad blue, polishing (30mm) x 2
ESponge pad red, final finish (30mm) x 2
FWool polishing pad (25mm) x 2
GBuffing mop pad (25mm) x 2
HDetail felt point bullet mop (11.5mm) x 2
ILambswool polishing pad (50mm) x 2
JCylinder sponge pad yellow (coarse)
KTapered sponge pad yellow (coarse)
LCylinder sponge pad dark red (medium)
MTapered sponge pad dark red (medium)
NCylinder sponge pad blue (fine)
OTapered sponge pad blue (fine)
PChuck spanner x 2
QAir line adaptor
RBottle: (empty) for air tool lubricating oil
5
www.power-tec.co.uk
Operation:
Compressed air supply:
The tool must be connected to a suitable, clean, dry and lubricated workshop
air supply. It is recommended that the air pressure measures 90psi at the tool
while running free. Water in the air line will damage the tool. Drain the air tank
daily and drain any dryer/filter unit when necessary.
Lubrication: For first use of the tool, add a few drops of air tool lubricating
oil to the compressed air line connection. In use, if an in-line oiler is not
installed, add a few drops of air tool lubricating oil daily. Adequate lubrication
will help to ensure long tool service life.
When tool is not in use, disconnect from compressed air supply.
Regulating the speed:
Refer to Figure 2: adjust the air pressure and therefore the speed of the
instrument by turning the speed control towards ON or OFF. Lower speeds
are recommended for detail work using the smaller pads. Remember to
switch OFF when finished. Do not disconnect air line while tool is ON.
6
www.power-tec.co.uk
92559
Pneumatic Detail Polishing Kit
Attaching the backing pads and accessories:
Refer to Figure 3: Fit the backing pad or accessory pad to the tool; use the
supplied spanners to grip the tool and then turn the locking collar clockwise
to tighten the chuck. To remove an accessory, turn the locking collar
anticlockwise.
7
www.power-tec.co.uk
Specifications:
No-load RPM: 70,000
Maximum accessory RPM: 15,000
Air inlet: 1/4"
Average air consumption: 1.0 CFM
Maximum air pressure: 90psi
Consumables available:
Part number Item description
92560 Cylinder & tapered sponge pads blue (fine) 2 pieces.
92561 Cylinder & tapered sponge pads dark red (medium) 2 pieces.
92562 Cylinder & tapered sponge pads yellow (coarse) 2 pieces.
92563 Backing pad (25mm) x 2.
92564 Felt point bullet mop (11.5mm) x 2.
92565 Wool polishing pad (25mm) x 2.
92566 Buffing mop pad (25mm) x 2.
92567 Lambswool polishing pad (50mm) x 2.
92568 Sponge pad: green, yellow, blue, red (30mm) 8 pieces.
Safety Precautions:
• Eye and face protection plus work gloves and suitable work clothing must be
used. Never wear loose clothing or jewellery that could be trapped by moving
parts.
• Dust hazard: a suitable-grade dust mask or respirator must be used for any
dust-generating operations.
• Vibration hazard: exposure to vibration can cause damage to nerves
and blood supply of the hands and arms. If you experience numbness,
tingling, pain or whitening of the skin in fingers or hands, stop using the tool
immediately.
• Noise hazard: unprotected exposure to high noise levels can cause hearing
loss and tinnitus (ringing or buzzing in the ears). Wear suitable ear protection
as required by occupational health and safety regulations.
• Do not attempt to remove or change a polishing pad until the tool has been
disconnected from the compressed air supply.
• In use, if an in-line oiler is not installed, add a few drops of air tool lubricating
oil daily.
• Never carry an air tool by the hose.
• Keep the instrument clean and well-maintained. Store in supplied case when
not in use.
Our products are designed to be used correctly and with care for the purpose for which they are
intended. No liability is accepted by the Tool Connection for incorrect use of any of our products, and
the Tool Connection cannot be held responsible for any damage to personnel, property or equipment
when using the tools. Incorrect use will also invalidate the warranty.
If applicable, the applications database and any instructional information provided has been designed
to offer general guidance for a particular tool’s use and while all attention is given to the accuracy
of the data no project should be attempted without referring first to the manufacturer’s technical
documentation (workshop or instruction manual) or the use of a recognised authority such as
Autodata.
It is our policy to continually improve our products and thus we reserve the right to alter
specifications and components without prior notice. It is the responsibility of the user to ensure the
suitability of the tools and information prior to their use.
This item contains consumable elements that are NOT covered by the
Tool Connection guarantee. For spares contact our service department
direct on: +44 (0) 1926 818186
Guarantee
www.power-tec.co.uk
Distributed by The Tool Connection Ltd
Kineton Road, Southam, Warwickshire CV47 0DR
T+44 (0) 1926 815000 F+44 (0) 1926 815888
92559_Instructions_V1
