PowerAcoustik PD-1032B Manuale utente
PD-1032B
2 DIN 10' Touch Screen
DVD/CD/MP3/MP4 Player
AM/FM Radio
Support Bluetooth
Owner’s Manual
Take the time to read through this owner’s manual.
Familiarity with installation and operation procedures will help you obtain the best
Performance from your new DVD-receiver.
2
WARNING!
To promote safety, certain functions are disabled unless the parking brake is on. The Unit is
designed to detect parked status and must be connected to the power supply side of the
parking brake switch. Improper connection or use of his connection may violate applicable law
and may result in serious injury or damage. To avoid the risk of damage and injury and the
potential violation of applicable laws, this unit is not for use with a video screen that is visible to
the driver.
To avoid the risk of accident and the potential violation of applicable laws, the front Video
image feature should never be used while the vehicle is being driven. Also, other video
displays should not be in a location where it is a visible distraction to the driver. In some
countries or states the viewing of images on a display inside a vehicle even by persons
other than the driver may be illegal. Where such regulations apply, they must be obeyed
and this unit’s DVD features should not be used.
Please remember to wear your seat belt at all times while operating your vehicle. If you are
ever in an accident, your injuries can be considerably more severe if your seat belt is not
properly buckled.
The supplier waves any and all liability when these warnings are not followed.
OPERATION PRECAUTIONS
Only connect to a 12VDC battery and negative grounding.
Avoid placing the product in direct sunlight, in areas with high levels of dust, high
temperatures (over 40°C) or high humidity (over 90%). In case of high temperatures, cool
down the car interior by means of ventilation or air-conditioning.
Operate in well ventilated areas.
Do not turn on or off the product in short intervals. When turning the unit off, wait for at least
10 seconds prior to turning the unit on again. Do not operate the player with scratched,
bended or broken discs and when a disc is not loaded properly, do not force it into the
player.
Do not watch video playback while driving which will cause serious danger and risks of
traffic accident. It may violate the laws and regulations.
(There may be exceptional case, i.e., using rear view camera and navigation system)
Do not install the unit where the operation for safety driving is restrained.
Do not disassembly the unit by yourself, if need repairing, please take the unit to the after
service center.
Do not open and close the monitor manually, it may damage the monitor tilt system.
Do not touch the LCD screen by hard objects, it may damage or give scratch to the LCD
screen.
If the back of monitor touches dashboard or air-conditioner inlet etc after open the monitor,
then setup TILT level in monitor TILT menu to prevent damage from repeat touching.
Car parking under direct sunlight may increase the temperature inside the car and the unit
may not be in proper operation, please try it again after the temperature returns to normal.
Do not replace the fuse on the power cable without professional guidance, using improper
fuse may cause damage to the unit or even cause burn the unit.
Do not use irregular shaped Disk.
IR remote control operation may be hindered by monitor when the monitor is opened, thus
please use the remote control at the similar level of remote control receiver.
Do not install the unit where the cooling fan is blocked.
3
CONTENTS
WARNING! .................................................................................................................. 2
OPERATION PRECAUTIONS .................................................................................... 2
CONTENTS ................................................................................................................ 3
ACCESSORIES .......................................................................................................... 4
UNIT INSTALLATION AND REMOVAL…………………………………………………....5
WIRING CONNECTIONS ........................................................................................... 7
FRONT PANEL ........................................................................................................... 9
REMOTE CONTROL ................................................................................................ 11
REMOVE BATTERY ................................................................................................. 13
MAIN MENU ............................................................................................................. 14
◆ RADIO .................................................................................................................. 14
◆ DVD PLAYER ....................................................................................................... 15
◆ DISC/USB/SD INTERFEACE OPERATION ......................................................... 15
◆SETTING CONTROL ............................................................................................ 16
◆SOUND SETTING ................................................................................................. 17
◆DISPLAY SETTING ............................................................................................... 17
◆RADIO SETTING .................................................................................................. 17
◆GENERAL SETTING ............................................................................................. 17
◆DVD SETTING ...................................................................................................... 18
◆SYSTEM ................................................................................................................ 18
◆BLUETOOTH SECTION ........................................................................................ 19
◆AUX-IN MODE ...................................................................................................... 21
◆AV-IN MODE ......................................................................................................... 21
OTHER FUNCTIONS................................................................................................ 21
NOTES ON DISC ...................................................................................................... 22
TROUBLESHOOTING .............................................................................................. 23
TROUBLESHOOTING .............................................................................................. 24
TECHNICAL SPECIFICATIONS ............................................................................... 25
BLUETOOTH CONNECTION ATTENTION INSTRUCTIONS .................................. 26
VIDEO FILE CONVERSION ..................................................................................... 27
4
ACCESSORIES
Package contains the following accessories for installation and operation of the unit.
(1) Washer, Spring
Washer, M5 Nut 1 each
(2) Metal Mounting Strap
1
(3) Hex Bolt 1
(4) Screw
Max. 8mm (7/32 x
max. 5/16 in)
4
(5) Metal
Mounting Sleeve 1
(6) Release Key 2
(7) Tapping Screw 1
(8) Rubber Cushion 1
Note:
Product image may vary from the actual delivery.
Warranty card
User Manual
Remote Control
trim ring
ISO cable
AAA B
attery
extra trim ring
for special installation
SD card
5
UNIT INSTALLATION AND REMOVAL
Note
Before starting installation of the unit, make sure the wiring is connected properly.
Use only the parts provided with the unit to ensure proper installation.
The use of unauthorized parts may cause malfunction.
Install the unit where it does not get in the driver’s way and will not injure the passenger in case
there is a sudden stop, like an emergency stop.
INSTALLATION （Figure 1）
Insert the unit into dash-board hole and fix it
If necessary, place the mount strap at the rear of the unit and fix it with provided washer as
figure 2.
Place Trim Ring over the unit and installation is completed as figure 1.
Make sure all faceplate tabs meet properly with the mounting plate. (As Figure. 4)
Press the panel, make sure the gear locked to the mounting hole. (As Figure. 5)
Figure 4
Figure
5
6
Removing the Unit
1) Press the button. (As Figure. 6)
2) Safely detach the faceplate. (As Figure. 7)
3)Insert the supplied release key into the unit and pull the unit out with keeping the release key
(As Figure. 8)
Figure
6
Figure
8
Figure
7
7
WIRING CONNECTIONS
Make sure you have good chassis ground. A good ground connection will eliminate most
electrical noise problems. A good chassis ground requires a tight connection to the vehicle’s
metal chassis. The area around the ground connection should be clean, bare metal without rust,
paint, plastic, dust, or dirt for a good electrical connection.
Caution: Do not interchange the
connection of the wiring!!!
For some car models you may
need to modify wiring of the
supplied power cord. Contact
your authorized car dealer
before installing this unit.
Using the ISO Connector
1. If your car is equipped with
the ISO connector, then connect
the ISO connectors as illustrated.
2. For connections without the
ISO connectors, check the
wiring in the vehicle carefully
before connecting, incorrect
connection may cause serious
damage to this unit.
3. Cut the connector; connect
the colored leads of the power
cord to the car battery as shown
in the color code table below for
speaker and power cable
connections
NOTE: Never connect cable to the system while it is connected to the battery power. Whenever
the unit is disconnected from the battery, the preset memory will be erased and the unit will go
back to its factory defaults.
When the brown cable for steering wheel control connected to the steering wheel, we can use
the steering wheel to control some unit
Note: To watch video the parking wire should be connected to break signal.
2 cables is connected to a Hands-Free device (not included).
Parking wire
Note: The parking wire is connected with brake signal; for safety, the programs can be seen on
the monitor after braking the car.
8
Connecting the reversing line to taillight on the car
After connecting, when you start up the reverse gear, the unit will receive the picture from car
rear view camera.
Note:
- Only use groundless loudspeakers.
- Use only loudspeakers of minimal 40Watt, using fewer watts may result in damaging
your loudspeakers at higher volumes.
- Use 4~8 Ω (Ohm impedance) loudspeakers only; using higher or lesser impedance may
damage the unit.
- Do not use 3-cable loudspeakers and do not connect the loudspeakers minus to the car
body (GND). The unit is using a BTL circuit and each loudspeaker must be connected
with insulated cables according the diagram.
- Loudspeaker cables and/or optional external power amplifiers must always be about
30cm away from the antenna and/or antenna extension parts.
Connect the speakers according the following diagram, incorrect connections will damage the
unit or your loudspeakers
Correct Speaker Connection
Incorrect Speaker Connection"
9
FRONT PANEL
1
2
3
4
5
7
8
6
11 13 12
9
10
10
1. Info Display
Information Display LCD when operation the unit.
2. IR Sensor
3. MIC
4. POWER/MUTE Button
Press it to turn on the unit. Press and hold for 2 seconds to turn the unit off .Press the button
briefly to Mute .Please note that the volume will be muted on all audio output connector.
5. MODE Button
Press it to select different input mode: Radio, DISC (if there is a disc in unit), USB (if there is a
USB device in the unit), CARD (if there is a SD/MMC card in the unit), Bluetooth, and AUX IN.
6. VOL Decrease（-） Button
Press VOL decrease button to decrease the volume.
7. VOL Increase（+） Button
Press VOL increase button to increase the volume.
8. Release Button
Press to detach and release the front panel. When the unit was released, it will switch off
automatically after a few second. Detach/Attach the Panel: Press REL button and pull out the
panel towards yourself to release the panel. To attach it, press the control panel into the main
unit until the “click” sound is heard.
9. AUX Jack
Connect an external audio source to the AUX-IN jack.
10. USB slot
11. SD/MMC CARD slot
SD/MMC card slot, for Multimedia playback files only. Insert a SD/MMC CARD into this slot and
the unit will automatically start reading and playback the card.
12. Anti-theft LED light
13. RESET Button
Press it with a thin, sharp object. The device will then be reset to factory default settings.
