POWEREPUBLIC T3000 Manuale utente
Model: T3000
Portable Power Station EN
User Manual
1
ATTENTION:
AC output voltage and frequency will be different depending on different countries or
areas. Please refer to the actual product before using.
Product Description
Thanks for purchasing our portable solar generator power station. Please read this manual
carefully before use and keep it for review.
This manual helps you to operate this device correctly. But it is not the introduction of the
soft & hard ware configuration. To know the configuration of the product,please refer to the
related contract or consult with your distributor. The images in this manual are for
reference only.
Thank you!
2
LCD Display
TYPE-C Output
USB Output
AC ON/OFF
QC3.0
USB ON/OFF
DC Output
Anderson 2
Anderson 1
AC Output
LED ON/OFF
LED Light
DC ON/OFF
DC Input
DC Output
Anderson 2 Port Cautions:
1. You should use the original charger or the charger with the same parameters (the
voltage range is 28.8±0.2V and the current range is 5A~40A), and correctly connect it to
the positive and negative poles of this port;
2. This port is a fast charging port, when the device is charged to 90% via it, the charging
will stop to protect the device;
3. If the parameters of the charger do not match, the display of this device will light up
while the charging will not start.
Specifications
LED Flashlight
Model T3000
Battery Capacity 25.6V 125000mAh 3200Wh
Rated Power 3000W, Peak 6000W
Battery Type LiFePO4
Charge Input CC/CV 28.8V/20A
AC Output 100V~120V 60Hz
USB Output 5V/2.4A
QC 3.0 Output 5V/3A, 9V/2A,12V/1.5A
DC Output 2*12V/10A Max
Type C Output 1 PD 100W: 5V/3A, 9V/3A, 12V/3A,15V/3A, 20V/5A
Type C Output 2 PD 18W: 5V/3A, 9V/2A, 12V/1.5A
Anderson 1(30A) Input
Output Waveform
Gross Weight
Product Size
Operation Temperature
4W
18V~30V 8A Max
Anderson 2(50A) Input 28.8V 40A Max
Pure Sine Wave
About 37KG
L466*W300*H369mm
-10°C（14°F）~60°C（140°F）
Protection Circuit
Short Circuit Protection
Over Current Protection
Over Power Protection
Over Discharge Protection
Over Charge Protection
Over Temperature Protection
Package Included
1 x Portable Power Station
1 x AC Adaptor
1 x Car Charger
1 x Power Cable
1 x User Manual
3
LCD Display
4
LED
Light
DC Input Solar Charging DC Output Power AC Output Power
Fan Temperature Status
Fault Charging Discharge
DC Output
USB Output AC Output
Battery Level Indicator
* The LCD screen will shut down automatically when no outputs are activated within 60
seconds.
Shows the percentage of the power. It’s recommended to charge the power station
when battery indicates less than 20%.
The fan is intelligently started when battery temperature gets high.
Shows the current input power in watts and provides remaining charging time in hours
under current input.
Shows the current output power in watts and provides remaining usage time in hours
under current output.
Fan Indicator
Current Input
Current Output
5
How to Use Your Portable Power Station?
According to the power station you currently have, Limited
device wattage<3000W, Such as laptop, Fan, TV, CPAP, Etc
can be charged. AC will shut down when it's short circuited
or power overloaded. Remove the device to recover from
short circuit or over power protection.
1.AC Output Switch
Turn on AC output: Press and hold the AC power button for 2 seconds to turn on
the AC output, the corresponding indicator light will light up and the display screen will
show Frequency “ ”. AC output will switch off within 3 hours automatically when
there are no loads(less than 5W).
When there is Short-circuit, Exceed maximum current/power limit or Low voltage, the
Function Failure sign will appear on the display and the corresponding outlet indicator will
flash simultaneously for 60 seconds.Output automatically shuts down immediately. Please
remove the overloaded devices and then restart the power station to resume work.
Turn off AC output: Press and hold the AC power button for 2 seconds to turn off the
product,the corresponding LED indicator light and the display screen “ ” will turn off.
Function Failures Warning
2.DC Output Switch
Turn on DC output: Press the DC power button to turn on DC output, the
corresponding indicator light will light up and the display screen will show“ ”. DC
output will switch off within 1 hour automatically when there are no loads(less than 2W).
Turn off DC output: Press the DC power button to turn off the product,the
corresponding indicator light and the display screen “ ” will turn off.
3.USB Output Switch
Turn on USB output: Press the USB power button to turn on USB/TYPE-C
output, the corresponding indicator light will light up and the display screen will show “
”. USB output will switch off within 1 hour automatically when there are no loads
(less than 1W).
Turn off USB output: Press the USB power button to turn off the product, the
corresponding indicator light and the display screen “ ” will turn off.
Support DC12V Devices, Such as Vacuum Cleaner,
Inflation Pump, Electric Wrench, Car Fridge, Etc.
6
4.LED Light Switch
Turn on LED light: Press and hold the LED button for 2 seconds to turn on the
light, and the display screen will show “ ”.One more click to switch the modes,including
High light, Low light, SOS and Strobe.
Turn off LED light: Press and hold the LED button for 2 seconds to turn off the
light.
Smartphone, Digital Camera, Tablet, Etc.
7
1.Charging by DC input(7.9*5.5*0.9mm)(12V~30V, 8A max /230W max)
The icon“ ” will light up, show the current input power in watts “ ” and
provide remaining charging time in hours under current input,and the percentage of the
battery.
2.Charging by Anderson port 1 (18V~30V, 8A max /230W max)
The icon“ ” will lights up, show the current input power in watts“ ” and provide
remaining charging time in hours under current input ,and the percentage of the battery.
How To Charge The Portable Power Station?
AC Socket
Charge this unit with
AC adapter
8
3.Charging by Anderson port 2 (28.8V,40A max/1000W max)
The icon“ ”will lights up, show the current input power in watts “ ” and
provide remaining charging time in hours under current input,and the percentage of the
battery.
Frequently Asked Questions
1. Can the product be carried on the plane?
No. According to international air transport standards, the lithium battery should not
exceed 100Wh. You can not board the plane with the product because the built-in battery
is 3200Wh.
2. Why the device power sometimes not available within 3000W?
a.The power station's power is less than 20%, and it needs to be charged in time.
b.The instantaneous starting power of your equipment is larger than the peak power of the
power station, or the nominal power of the equipment is larger than the actual power of our
power station. It is recommended to choose our larger power products.
3. Why it’s noisy when the product works?
It’s the power station built-in cooling fans system. The built-in fan can better help the
product to dissipate heat to achieve a high conversion rate. It is common to have a slight
noise during use.
4. Is the charger(adaptor) heating up normally while the product is charging?
It is normal for the charger to heat up during charging. The standard charger conforms to
national safety standards.
9
Product Application Skills
1) This product is built-in high quality original lithium ion battery. It has no memory effect
but has high-capacity, and it is durable. However, we still recommend you to apply in the
range of 10 ℃~30 ℃, so as to obtain the optimal charging capacity.
2) When charging, in order to avoid interference, please stay away from TV, radio and
other equipment.
3) If the device has not been used for a long time, please disconnect the cable and store.
4) Some portable devices may need to be set in charge mode to charge. Refer to the
corresponding equipment use manual for more information.
5) After starting it, if there is no output, it’s display will automatically shut down within 60
seconds, so as to achieve better energy-saving effect.
6) Please deal with scrap products in accordance with the regulations, Do not treat the
built-in battery as a household garbage, so as not to cause explosion and pollution.
7) The product is only used for emergency power station, which can not replace the
standard DC or AC power for household appliances or digital products.
8）The device has an internal, non-removable, rechargeable battery. Do not attempt to
remove the battery, as you may damage the device.
10
Avoid extreme
temperatures
Avoid dropping
Don’t disassemble
To preserve lifespan
recharge every 3 months
Don’t expose
to liquids
Use original
or certified cables
