Powerware 9315 Manuale utente

Installation

Manual

Uninterruptible Power

Supply

100 kVA -- 160 kVA

164200292 Rev. E

9315

ii Powerware 9315 (100 kVA--160 kVA) Installation

164200292 REV. E 041500

------------------------------------------------------------------------

----------------------------------

IMPORTANT SAFETY INSTRUCTIONS

Instructions Importantes Concernant La Sécurité

SAVE THESE INSTRUCTIONS

Conserver Ces Instructions

This manual contains important instructions for your Uninterruptible Power

Supply (UPS) system. You should follow these instructions during the

installation and maintenance of the UPS, options, accessories, and batteries.

Cette notice contient des instructions importantes

concernant la sécurité.

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

their own expense.

WARNING:

This is a product for restricted sales distribution to informed partners. Installation

restrictions or additional measures may be needed to prevent disturbances.

iii

Powerware 9315 (100 kVA--160 kVA) Installation

164200292 Rev. E 041500

Table of Contents

1Introduction 1............................................

Using This Manual 2............................................

Conventions Used in This Manual 3...............................

For More Information 3..........................................

Getting Help 3..................................................

2Getting Started 5.........................................

Preparing Your Site 6............................................

Environment Considerations 6...................................

Preparing for Wiring the UPS System 6............................

Inspecting and Unpacking Each Cabinet 7.........................

Unloading the UPS Cabinet From the Pallet 8......................

Creating an Installation Plan 10....................................

3Installing the UPS 11.......................................

Preparing the UPS for Installing

Optional Cabinets or Accessories 13............................

Completing the Installation Checklist 15............................

Installation Checklist 16..........................................

Notes 17.......................................................

4Joining Cabinets 19.......................................

Method A --- Joining an Optional Cabinet to the UPS 20..............

Method B --- Joining Optional Cabinets to Each Other 23.............

Grounding Joined Cabinets 25....................................

Method A Grounding 25..........................................

Method B Grounding 25..........................................

5Installing Battery Cabinets 27..............................

Two Models are Available 27......................................

Important Safety Instructions 27...................................

General Notes About Installing Battery Cabinets and

Remote Disconnects 28.......................................

iv Powerware 9315 (100 kVA--160 kVA) Installation

164200292 REV. E 041500

6Installing an Input Transformer 29..........................

7Installing a Power Distribution Module 33...................

8Installing a Remote EPO Control 37.........................

9Installing a Remote Battery Disconnect 39..................

10 Installing a Remote Monitor Panel 41......................

11 Installing a Relay Interface Module 47.....................

12 Installing a Supervisory Contact 51........................

A p p e n d i x A --- C u s t o m e r I n f o r m a t i o n A --- 1..........................

Powerware 9315 (100 kVA--160 kVA) Installation

164200292 REV. E 041500

Powerware 9315 (100 kVA--160 kVA) Installation

164200292 Rev. E 041500

List of Figures

Figure 1. Typical UPS System 1....................................

Figure 2. Cabinet as Shipped, with Outer Packaging and Pallet 7......

Figure 3. Removing Front and Rear Supports 9......................

Figure 4. UPS Cabinet 11..........................................

Figure 5. Preparing the UPS for Installing Other Cabinets 14............

Figure 6. Methods of Joining Cabinets 19............................

Figure 7. Joining an Optional Cabinet to the UPS 20...................

Figure 8. Pushing Cabinets Together 20..............................

Figure 9. Placement of Joining Brackets 21...........................

Figure 10. Installing the Angled Bracket 22...........................

Figure 11. Preparing to Join Component Cabinets 23..................

Figure 12. Joining Component Cabinets 24..........................

Figure 13. Cabinet-to-Cabinet Grounding --- Method A 26..............

Figure 14. Cabinet-to-Cabinet Grounding --- Method B 26..............

Figure 15. Input Transformer Cabinet 29.............................

Figure 16. Installing an Input Transformer Cabinet 31..................

Figure 17. Typical PDM Cabinet 33..................................

Figure 18. Remote EPO Control 37..................................

Figure 19. Remote Battery Disconnect Enclosure 39...................

Figure 20. Remote Monitor Panel (RMP) 42...........................

Figure 21. Terminal Block Bracket 43................................

Figure 22. Wiring an RMP to the UPS 44.............................

Figure 23. Relay Interface Module 47................................

Figure 24. Terminal Block Bracket 48................................

Figure 25. Wiring an RIM to the UPS 48..............................

Figure 26. Supervisory Contact Module 51...........................

Figure 27. Terminal Block Bracket 52................................

Figure 28. Wiring an SCM to the UPS 52.............................

Figure 29. Supervisory Contact Module TB2 54.......................

vi Powerware 9315 (100 kVA--160 kVA) Installation

164200292 REV. E 041500

This Page Intentionally Left Blank.

Powerware 9315 (100 kVA--160 kVA) Installation

164200292 Rev. E 041500

Introduction

This manual describes how to install your Powerware9315

Uninterruptible Power Supply (UPS) system. It contains instructions for

installing the UPS and each optional component and accessory. The information

you will use depends on the system you purchased.

Each component of your UPS system is housed in a free-standing cabinet. The

cabinets line up and match in style and color, and have safety shields behind the

doors for hazardous voltage protection. Figure 1 shows a sample UPS system that

includes at least one of each component.

(optional)

PDM CABINET

(optional) INPUT

TRANSFORMER

CABINET CABINET

UPS CABINET

BATTERY

(up to four)

Figure 1. Typical UPS System

These basic UPS system configurations are possible:

·The UPS and one or more battery cabinets

·The UPS, battery cabinet(s), and a Power Distribution Module (PDM)

·The UPS, battery cabinet(s), and an input transformer

·TheUPS,batterycabinet(s),PDM,andinputtransformer.

You can enhance any of these system configurations by adding optional accessories,

such as a Remote Monitor Panel (RMP),Relay Interface Module (RIM),orRemote

Emergency Power Off (EPO) control.

2Powerware 9315 (100 kVA--160 kVA) Installation

164200292 REV. E 041500

Using This Manual

The system you are installing dictates which parts of this manual you should read.

Everyone should read Chapters 1 through 4:

·Chapter 1 discusses installation considerations for your entire UPS system.

·Chapter 2 tells you how to prepare your site for the installation of your UPS

system. It discusses equipment environmental requirements, inspecting and

unpacking cabinets, and pallet removal.

·Chapter 3 describes how to install the UPS cabinet.

·Chapter 4 illustrates the two methods for joining cabinets together.

·Chapter 5 contains safety instructions and general notes for installation of the

UPS manufacturer’s optional battery cabinets.

·Chapter 6 contains information for installing the optional input transformer

cabinet.

·Chapter 7 contains information for installing the optional Power Distribution

Module (PDM).

·Chapter 8 discusses installing the optional Remote Emergency Power Off

(EPO) control.

·Chapter 9 contains information for installing the optional remote battery

disconnect.

·Chapter 10 contains information for installing the optional Remote Monitor

Panel (RMP).

·Chapter 11 contains information for installing the optional Relay Interface

Module (RIM).

·Chapter 12 contains information for installing the optional Supervisory Contact

Module (SCM).

·Appendix A contains important information for planning and installing your UPS

system, including illustrations of cabinets and optional accessories.

Read through each installation procedure before you begin. Perform only those

procedures that apply to the UPS system you are installing.

Powerware 9315 (100 kVA--160 kVA) Installation

164200292 Rev. E 041500

Conventions Used in This Manual

The text in this manual uses these conventions:

·Bold type highlights important concepts in discussions, key terms in

procedures, and menu options.

·Italic type highlights notes and new terms where they are defined.

·Rectangular boxes containing bold type are warnings or cautions that pertain to

the UPS system or its electrical connections.

In this manual, the term UPS refers only to the UPS cabinet and its internal elements.

The term UPS system refers to the entire power protection system—the UPS cabinet

plus any options or accessories you have installed.

For More Information

This manual describes how to install your UPS system. For more information

about the operation and communications capabilities of the UPS system, refer to

the following:

164200252 Powerware9315 30 kVA---160 kVA UPS Operation

Describes the UPS cabinet Control Panel and Monitor Panel, and

explains the functions of the UPS; discusses the standard

features of the UPS and optional accessories; provides

procedures for starting and stopping the UPS, and information

about maintenance and responding to system events.

A l s o d e s c r i b e d a r e t h e R S --- 4 8 5 a n d R S --- 2 3 2 s e r i a l

communications capabilities of the UPS system; discusses the

two communications ports on the Customer Interface Panel

inside the UPS and how to connect optional remote accessories

to your UPS system; provides information about enabling,

disabling, and customizing building alarms.

Contact your local Field Service office for information on how to obtain copies of

this manual.

Getting Help

If you have a question about any of the information in this manual, or if you have a

question this manual does not answer, please call Powerware Corporation Field

Service:

United States 1-800-843-9433

Canada 1-800-461-9166

Outside the U.S. Call your local representative

4Powerware 9315 (100 kVA--160 kVA) Installation

164200292 REV. E 041500

This Page Intentionally Left Blank.

Altri manuali per 9315

Indice

Altri manuali Powerware UPS

Powerware

Powerware 300 VA Manuale utente

Powerware

Powerware 5140 Manuale utente

Powerware

Powerware 9315s Manuale utente

Powerware

Powerware 5110 Manuale utente

Powerware

Powerware Ferrups FE/QFE UPS Manuale utente

Powerware

Powerware 9315 Manuale utente

Powerware

Powerware 9125 Manuale utente

Powerware

Powerware Ferrups FE/QFE 500VA Manuale utente

Powerware

Powerware 9120 Manuale utente

Powerware

Powerware P93 Manuale utente

Powerware

Powerware Prestige series 9 Manuale utente

Powerware

Powerware 9125 PowerPass Manuale utente

Powerware

Powerware UPS 1000 - 2200 Manuale utente

Powerware

Powerware 5140 Manuale utente

Powerware

Powerware 9305 HS Series Manuale operativo

Powerware

Powerware 9305 Manuale operativo

Powerware

Powerware 8 - 15 kVA Manuale utente

Powerware

Powerware 3110 Manuale utente

Powerware

Powerware Prestige 6000 Guida all'installazione

Powerware

Powerware 9170+ Manuale utente

Powerware

Powerware 5125 9910 P18 Manuale utente

Powerware

Powerware 9330 Manuale utente

Powerware

Powerware 5140 Manuale utente

Powerware

Powerware 5125 Manuale utente

Manuali UPS popolari di altre marche

Pylontech

Pylontech Victron & Pylontech US5000 Manuale utente

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuale utente

Mecer

Mecer ME-1000-WTU Manuale utente

Mustek

Mustek PowerMust 530(B) Plus Manuale di installazione e funzionamento

Emerson

Emerson Liebert NXL series Manuale utente

MAKELSAN

MAKELSAN BOXER SERIES Manuale utente

Block

Block PC-0524-400-0 Manuale utente

CyberPower

CyberPower CP585LCD Manuale utente

Eaton

Eaton 3S Istruzioni per il montaggio

CyberPower

CyberPower Office Tower Series UPS 1000 Manuale utente

CyberPower

CyberPower BM100 Manuale utente

Best Power

Best Power 610 Manuale utente

Best Power

Best Power Unity/I UT3K Manuale utente

Mustek

Mustek PowerMust 400 Offline Manuale utente

Xantrex

Xantrex Trace 512 UR-UPS Manuale utente

Forza

Forza SL-1501UL Manuale utente

LEGRAND

LEGRAND keor 310081 Manuale utente

ABB

ABB Conceptpower DPA 500 Manuale utente
