Setting Up the Personal Viewing System

(PVS)

North American and Pro:Idiom Versions

Equation 1: Englis h

Edition Information

Setting Up the PVS (North American and Pro:Idiom Versions)

P/N 303835-112 rev B

Trademark Note

Precor, AMT, EFX, and Preva are registered trademarks of Precor Incorporated. Other names in this document may be the

trademarks or registered trademarks of their respective owners.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Intellectual Property Notice

All rights, title, and interests in and to the software of the Preva Business Suite, the accompanying printed materials, any copies

of such software, and all data collected via the Preva Business Suite, are exclusively owned by Precor or its suppliers, as the case

may be.

Precor is widely recognized for its innovative, award-winning designs of exercise equipment. Precor aggressively seeks U.S. and

foreign patents for both the mechanical construction and the visual aspects of its product design. Any party contemplating the

use of Precor product designs is hereby forewarned that Precor considers the unauthorized appropriation of its proprietary rights

to be a very serious matter. Precor will vigorously pursue all unauthorized appropriation of its proprietary rights.

Precor Incorporated

20031 142nd Ave NE, P.O. Box 7202

Woodinville, WA 98072-4002

www.precor.com

Keypad Orientation

Important

The information provided in this section is intended for system administrators and registered service technicians. Please do

not share it with equipment users or non-administrative staff.

Use the System Setting mode to configure equipment settings in ways that benefit your users and your facility. Changes made

to these settings are stored in the equipment, allowing them to persist after a loss of power.

Figure 1

The keys are labeled with their primary function for TV operation by the user, but have an alternate function during system

setup

Number

Key Name

Function during system setup

Channel (Up/Down) Scrolls up and down from one subcategory to another through sub-categories

located under the main headings

Volume (Up/Down) Scrolls right to left across the main categories at the top of the screen menu

Volume Down: Acts as a Back key.

TV Status Green: TV on / Red: TV off

Direct Channel Access (1-0) Selects specific channel numbers

— (Dash) Saves setting and exits menu

CC/Mute Enters a selection

Source Returns to previous menu

Power (On/Off) Turns PVS on or off

Main Menu Access

The Main Menu categories are:

•Channel

•Picture

•Audio

•Time

•Setup

Grayed out settings are not available.

To view the Main Menu:

1. Press Power On/Off

o turn on the PVS.

2. Press CC + Volume Up + Channel Down

Note

If you do not press a button within 30 seconds (default), the PVS screen returns to the normal viewing mode.

3. Use Volume Up/Down to select a Main Menu category.

4. Use Channel Up/Down to navigate the sub menu.

5. Press CC/Mute

to make a selection.

6. Press Source

to return to previous menu.

7. Press Dash (-)

to save setting and exit the menu.

View the Channel Menu Settings

This menu contains the following presets:

•Input

•Auto Scan

•Show/Hide

•Digital Strength

Input

Note

Precor recommends using Auto Scan to ensure channel selection is complete.

Default: Cable + Air

Auto Scan

Auto Scan searches the selected ATV and/or DTV signals and saves the discovered channels to the current channel list.

For Pro:Idiom version: Auto Scan detects all encrypted channels and automatically adds them to the channel list. These

channels can be hidden during service set up if required by your facility.

Show/Hide

Use this setting to select which channels you want available for your users. Hidden channels are not deleted and can still

be accessed by pressing the channel number on the keypad.

For Pro:Idiom version: Use this setting to hide channels you do not want available in your facility.

To show or hide channels:

1. Use Channel Up/Down to navigate the channels in this setting.

2. Press CC

to hide the channel.

This symbol Ø means that a channel is hidden.

3. Press CC

again to show the channel to your users.

Digital Strength

When the PVS is tuned to a TV channel, this setting displays the digital signal strength for that channel.

View the Picture Menu Settings

This menu contains the following presets:

•Picture Mode

•Color Mode

•Aspect Ratio

Table 1: Picture Menu

Setting

Values

Default

Picture Mode Standard, Dynamic, Personal, Soft Standard

Color Mode Normal, Warm, Cool Normal

Aspect Ration 4:3, 16:9 Selected by PVS

Picture Mode

Use the Personal setting to adjust contrast, brightness, sharpness, tint, and color.

View the Audio Menu Settings

This menu contains the preset, Audio Language. Grayed out settings are not available.

Use this setting to select primary audio language for your user audience.

The three audio language choices are:

•English (default)

•French

•Spanish

View the Time Menu Settings

This menu contains the preset, Time Zone. Grayed out settings are not available.

Use this setting to select a time zone for your user audience.

The time zone choices are:

•Atlantic

•Eastern

•Central

•Mountain

•Pacific

•Alaska

•Hawaii

View the Setup Menu Settings

This menu contains the following presets:

•Menu Language

•OSD Time Out

•Closed Caption

•Restore Default

•Headphone Detect

•USB Update

•Software Version

Grayed out settings are not available.

Table 2. Picture Menu

Setting

Value

Default

Menu Language English, French, Spanish English

OSD Time Out 5, 15, 30, 45, 60 sec 30

Closed Caption Basic Off

-Basic CC1 Off, CC1, CC2, CC3, CC4, Text1, Text2, Text3, Text4 mode CC1

-Advanced Service1 Off, Service1, Service2, Service3, Service4, Service5, Service6 mode Service1

Restore Default Restores all settings to factory default settings N/A

Headphone Detect Enabled, Disabled Disabled

USB Update Use to update software (see procedure below) N/A

Software Version For example: 303751-xxx xxx N/A

USB Update

Use this setting to update software for your PVS.

Important

Perform the following procedure in the order presented.

To perform a USB Update:

1. Turn on the PVS.

2. Insert the USB flash drive before entering the Setup Menu.

3. In the Setup Menu, select USB Update

4. Select F/W File, then press CC.

Note

If USB is not properly inserted, the message, No Device, displays in the top left corner of the screen.

5. Select the USB drive, then press CC. After upload is completed (approximately 30 seconds), the TV turns off.

Important Do not turn off the TV power or remove USB flash drive during the USB update.

6. Remove the USB flash drive.

Setting Up the PVS (N. American/Pro:Idiom Versions) | P/N 303835-112 rev B , ENU
