Preethi Regal Manuale utente
c o n ve n i e n t energy efficient
s a f e
Programmed for Indian Cooking
Instruction Manual
ONE TOUCH
Dial
Regal
Vol ts /
Un it s
Si m
Bo il
Re he at
Deepf ry
Fry
Stirf ry
Ti me r /
Pr es et
Ro ti /
Do sa
Sl ow
Co ok
Pressure
Cook
ON / OFF
Mi lk /
Wate r Fr y Ma nu al Gr av y So up
Child Loc k
Keep
warm
Low Mid High
120 300 500 800 1000 1200 1400 1600 1800 2100W
100 120 140 160 180 200 220 240 270 C
Induction Cooktop
Regal
INDI COOK
Every product that bears the PREETHI brand name has to pass a series of stringent quality
tests. Preethi, the flagship brand of Maya Appliances Pvt Ltd, relies on its core values of
Performance, Quality, Reliability & Safety. Our mission remains single-minded: to
improve the family’s quality of life through the superior quality and efficiency of our
home appliances.
Induction Cooktop Instruction Manual
Congratulations
on purchasing a winner
Dear Customer,
Thank you for choosing Preethi’s new Induction Cooktop. This inspired new design is another unique
product from Maya Appliances (P) Ltd., a market leader in kitchen appliances since 1978. INDI COOK is
programmed to specially suit Indian cooking needs. Anything you cook on a Gas Stove can be done with INDI
COOK in a safer and more efficient manner.
Preethi Induction Cooktop’s stunning contemporary design and user friendly features is the outcome of
diligent research and extensive consumer feedback. The result is a product that makes your everyday cooking fast,
flexible and a lot of fun.
All Preethi products are designed to meet international standards in safety and quality. We encourage you
to read and store this reference guide carefully to ensure many years of trouble free and easy cooking!
Welcome to the Preethi Family !!
Warm regards,
T. T. Varadarajan
Managing Director
INDI COOK
Table of contents
Contents Page No
Benefits of INDI COOK
Safety with INDI COOK
Know your INDI COOK
Cookware
Quick Start
Operating Instructions
Cooking Modes
Safety Instructions
Troubleshooting
Technical Specifications
Warranty Card
Customer care
3
4
5
6
7
8-10
11-15
16-17
18-19
19
20-21
22
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
INDI COOK
How Induction Cooking works
An Induction Coil produces a magnetic field that
causes the electrons in the Vessel to vibrate and
produce heat. The Vessel heats up the contents in
it, while the cooking zone itself does not heat up.
Benefits of INDI COOK
Directly heats the Vessel
Thermostat Control
Twice as efficient as Gas Stoves
energy efficient
3
No risk of fire or electrical mishaps Auto Switch Off feature
s a f e
Child Lock Auto Cooling
Cool - No flame Just wipe to clean Portable-Use anywhere
c o n ve n i e n t
Soft Touch Control Preset Timer
Complete Safety with INDI COOK
Antimagnetic Plate: The Glass Top heats only the Vessel, while keeping the sides of the
cooking zone cool.
1
Auto Detection : The INDI COOK beeps for 1 minute if there is no Vessel or
non-magnetic Vessels or Vessels with base diameter less than 12 cm are used.
2
Soft Touch: The easy-to-use soft Touch Buttons also prevent entry of water and other
foreign particles.
3
Temperature Control: If the temperature of the Vessel is excessive, the will stop
heating until the temperature drops.
INDI COOK
4
Auto Cooling : A Fan cools the even after the “OFF” Button is touched
(provided it is still plugged in), enabling the INDI COOK to cool down very quickly.
INDI COOK
5
Auto Switch Off: The will automatically switch off if it is left ‘ON’
without attention for a long time.
INDI COOK accidentally
6
Child Lock : After setting program touch button simultaneously to activate Child Lock.
&
Once you use the Child Lock, the program will not change to any other mode until you release.
To release Child Lock touch button simultaneously once again, or switch off the INDI COOK
&
7
INDI COOK 4
Know Your INDI COOK
1. Power Cord
2. Air Vent
4.Control Panel
3. Glass Top
5.Cooking Zone
INDI COOK
5
Dial
Regal
Vol ts /
Un it s
Si m
Bo il
Re he at
Deepfr y
Fry
Stirfr y
Ti mer /
Pr es et
Ro ti /
Do sa
Sl ow
Co ok
Pressu re
Cook
ON / OFF
Mi lk /
Water F ry Ma nu al Gr av y Soup
Child Lock
Keep
warm
Low Mid High
120 300 500 800 1000 1200 1400 1600 1800 2100W
100 120 140 160 180 200 220 240 270 C
3
4
2
1
Regal
5
Stainless Steel Pots
Do not use
Use Only
Iron, Stainless Steel and Aluminium Vessels with SS Cladding magnetic base.
Flat base Vessels with diameter between 12 cm and 20 cm & Cladding diameter to be minimum 15 cm
The will switch ON only if the Cookware is suitable.INDI COOK
Enamelled Steel
Utensils and Kettles
Enamelled Stainless
Steel Kettles
Convex bottom Pots Base Diameter
less than 11 cm Pots with stands Concave base Pots
Heat-resistant Glass Pots Aluminium/Copper Pots Ceramic Pots
Iron Kettles
Cookware
INDI COOK 6
Iron Frying Pans Iron Pans Iron Plates Iron Frying Pans
With Cladding
Iron Pans
With Cladding
Iron Plates
With Cladding
Quick Start
1. Insert the Plug firmly into socket and switch “ON”. The powers up with a beep and
the LED display blinks once.
2. Place the Vessel at the center of the Glass Top.
3. Touch the “ON/OFF” Button once, the “ON/OFF” indicator will blink continuously with a single
beep then select a particular mode.
4. In the Regal INDI COOK, the temperature and cooking duration can be controlled
using the Buttons.
INDI COOK
Before you switch on your INDI COOK
wPlace the in a well ventilated area on a non-metal flat platform.
wRemoving all metal, plastic and canned items near the is recommended.
wClean the top zone of the Glass Top with a soft damp cloth to remove dust and spills if any.
wMake sure the ingredients are ready for cooking.
wEnsure that the power supply is 230V/50 Hz AC.
INDI COOK
INDI COOK
INDI COOK
7
1. Touch the “ON/OFF” Button once,
select a particular mode.
2. If there is no Vessel / unsuitable Vessel then the will beep for 1 minute and switch OFF.
3. Several “Cooking Modes” are available in the model (Refer Page No. 11 - 15) for details. Select the Mode
which suits your requirement.
4. After cooking, touch the “OFF” Button and remove the Vessel. This will activate the Fan to cool the
the “ON/OFF” indicator will blink continuously with a single beep then
INDI COOK
INDI
COOK.
INDI COOK
Operating Instructions
Model Control Panel
Regal
IC 105
Volts /
Units
Sim
Boil
Rehe at
Deepfry
Fry
Stirfry
Timer /
Pres et
Roti /
Dosa
Slow
Cook
Pressure
Cook
ON / OFF
Milk /
Water Fry Manu al Grav y Soup
Child Lock
Keep
warm
Low Mid High
120 300 500 800 1000 1200 1400 1600 1800 2100W
100 120 140 160 180 200 220 240 270 C
8
wThe ‘Timer’ Button controls the cooking duration for the selected “Cooking Mode”.
wTouch the ‘Timer’ Button once to display the cooking duration for the selected mode.
wLeft side Indicator above the button will glow.
wIn this INDI COOK touch the Buttons to increase/decrease the cooking duration from 1to180 minute.
Cooking Time
INDI COOK
9
Cooking Temperature
wIn this INDI COOK, use the Buttons to increase and decrease temperature.
wThe temperature can be varied from ”Keep Warm” to 270º C in increments determined by the selected
Cooking Mode.
Maintenance & Cleaning
1. Clean after every use. Before cleaning, disconnect Plug and wait till the INDI COOK cools down
completely.
2. Clean the INDI COOK and the Control Panel with a damp cloth.
3. Do not wash or immerse INDI COOK in water.
4. Use clean Pots/Vessels from outside to avoid discoloration or stains on the Glass Top.
5. To clean the Glass Top, first wipe it with a wet cloth and then with a sponge using mild
Finally wipe it dry with a soft damp cloth.
6. Keep the INDI COOK clean to avoid trapping insects into the Fan. This may cause malfunction.
detergent.
