Premier Mounts LMVP Manuale utente

LMVP Press & Release™Pop Out

Mount in Portrait Orientation

ITEM: LMVP

WEIGHT CAPACITY:

160 LB/ 73 KG

1 (800) 368-9700 |ORDERS@@PREMIERMOUNTS.COM PREMIERMOUNTS.COM

FEATURES

The LMVP Press & Release™ Pop Out Mount is a portrait oriented customizable

video wall mount for displays weighing up to 160 lb/ 73 kg with a mounting

pattern of 200 x 200 (min) to 400 x 400mm (max). It features multi-monitor

stacking, spring-loaded release, open design, custom spacers, top adjustable

mounting brackets and scissor-design for smooth extension.

Open frame design

allows for quick and easy

access to cables & wiring

Spring-loaded locking

mechanism provides

quick release in under 5

seconds

Top-adjustable ne-tune

mounting points allow

for post-installation

alignment

1 Industry’s rst Press &

Release™ Design for

easy service access in

under 5 seconds with

a gentle press to the

display

2Scissor-design with

compact mounting arms

allow for extension in one

smooth motion with a

slight press to the display

edge

3 Top-adjustable ne-tune

mounting brackets ensure

post-installation alignment

• Spring-loaded locking

mechanism provides

quick release from locked

position

• “Click-It” locking feature

conrms display is secure

through an audible noise

• Single latch design and

smaller base frame size

provide quick and easy

installation

• Laser cut, precision

design spacers ensure

seamless alignment

without need for time

consuming adjustments

• VESA pattern is 400

x 600mm max with

extension adapters

1 (800) 368-9700 |ORDERS@@PREMIERMOUNTS.COM PREMIERMOUNTS.COM

LMVP Press & Release™Pop Out Mount in Portrait Orientation

ARCHITECTURAL DRAWING

SPECIFICATIONS

WEIGHT COLOR WEIGHT CAPACITY/MOUNT MOUNTING PATTERN

43 lb. | 20 kg Black 160 lb. | 73 kg 200 x 200 mm (Min) x 400 x 400 mm (Max)

WIDTH X HEIGHT X DEPTH TOTAL WEIGHT CAPACITY WARRANTY

19.9 x 24.7 x 5.1-13.4 in. | 505 x 627 x 131-341 mm 160 lb | 73 kg Lifetime

PACKAGING

LENGTH x WIDTH x DEPTH CONTENTS

28.4 x 27.9 x 5.5 in | 721 x 709 x 140 mm Mount (x1), Brackets (x2), Adapter Arms (x2), Universal Hardware Pack (x1)

ACCESSORIES

In-wall A/V and Power

GearBox™

GB-INWAVPB

Model-Specic Video

Wall Spacer

LMVP-610

Model-Specic Video

Wall Spacer

LMVP-712
