Prestigio MultiPhone PAP4505DUO Manuale utente

PAP4505DUO EN - 1

Quick Start Guide

Prestigio MultiPhone

PAP4505DUO

1. Packing List

1. Prestigio MultiPhone

2. AC Adapter

3. Earphone

4. USB Cable

5. Quick Start Guide

6. Warranty Card

7. Legal and Safety Notices

8. Battery

9. Stylish Carrying Case

2. Device Overview

Vol +\ Vol - Button

Adjust the volume level

Earphone Jack

Earphone connection

USB port

Micro USB cable connection

Front Camera Lens

Take pictures while facing the screen.

Display menu options

Home

Back to the Home screen

Back

Back up to the previous page

Power

Turn on/off the device;

Suspend/Activate the device

Back Camera Lens

For taking photos

Speaker

To listen to music, and other sounds

offered by your phone.

3. Uninstalling the back cover and battery

EN-2 PAP4505DUO

Quick Start Guide

Prestigio MultiPhone

PAP4505DUO

Uninstalling the back cover: hold the side of device tightly with one hand and lift up the back cover at its buckle

with the other hand.

Taking out the battery: hold the side of device tightly with one hand and pull up the battery handle with the

other hand.

Notice: Your device must be powered off before exchanging or uninstalling the battery.

4. Installing the SIM cards and Micro SD card

a. Insert SIM cards

The left slot is card 1 slot and for 3G WCDMA card (compatible with 2G card), the right is card 2 slot and for

GSM card.

Please make sure the gold contact area on the card is facing downwards.

SIM1

SIM2

Micro SD

Card

PAP4505DUO EN - 3

Quick Start Guide

Prestigio MultiPhone

PAP4505DUO

b. Insert Micro SD card

Insert Micro SD card into the Micro SD card slot with the metallic pins facing

downwards. Push the card until it locks into place.

To remove the micro SD card, pull the card out of the slot.

5. Charging

Insert one end of USB cable into the USB port on the

device and plug the power adapter to the electrical socket.

Normally it takes approximately 3~4 hours to fully charge

the device. Operating the device while charging with the AC adapter may extend the time of full charging.

Notice: If your battery has been not used for a long time, it will gradually discharge. If this happens and you

want to use your device, you must first recharge the battery.

6. Power on/Sleep Mode/Power off

Press and hold the Power Button for a few seconds. It will automatically enter the Home screen after

start-up screen.

Press the Power Button once to enter sleep mode and press it again to awake the device.

Press and hold the Power Button, and then tap on Power off to power off the device.

Technical Specifications

EN-4 PAP4505DUO

Quick Start Guide

Prestigio MultiPhone

PAP4505DUO

Processor

MTK6577T @ Dual core 1.2GHz

Memory

512MB RAM + 4GB ROM, Micro SD slot supports up to 32GB

Android 4.1 Jelly Bean

Display

4.5-inch TN LCD, Capacitive multi-touch

Resolution

480x854 pixels

Net Mode

WCDMA + GSM (UMTS:900/2100MHz; GSM:900/1800MHz)

Camera

0.3MP front + 8.0MP AF Rear camera

Interfaces

Communications

Battery

USB 2.0, Micro SD, USB Host

Wi-Fi (802.11b/g/n), 3G

1800 mAh Lithium-Polymer Battery

Dimensions

130×66×9.9mm (H * W * D)

Weight

120g

Disclaimer

As the Prestigio products are constantly updated and improved, your device’s software and hardware may have

a slightly different appearance or modified functionality than presented in this Quick Start Guide.

Prestigio hereby states that this Smartphone complies to basic requirements and another

relevant regulations given by the EU directive1999/5/ES. Full version of the declaration of

conformity is available on http://www.prestigio.com/compliance.
