Prestigio PAP5000 DUO Manuale utente

PAP5000 DUO EN - 1

Quick Start Guide

Prestigio MultiPhone

PAP5000 DUO

1. Packing List

1. Prestigio MultiPhone

2. AC Adapter

3. Earphone

4. USB Cable

5. Quick Start Guide

6. Warranty Card

7. Legal and Safety Notices

8. Battery

9. Pouch

2. Device Overview

3. Uninstalling the back cover and battery

Uninstalling the back cover: hold the side of device tightly with one hand and lift up the back cover at its buckle

with the other hand.

Vol +\ Vol - Button

Adjust the volume level

Earphone Jack

Earphones connection.

USB port

Micro USB cable connection.

Display menu options.

Back

Back to the previous page.

Home

Back to the Home screen.

Power

Turn on/off the device;

Suspend/Activate the device.

Camera

Take photos.

Speaker

Listen to phone calls or music.

EN - 2 PAP5000 DUO

Quick Start Guide

Prestigio MultiPhone

PAP5000 DUO

Taking out the battery: hold the side of device tightly with one hand and pull up the battery handle with the other

hand.

4. Installing the SIM cards and Micro SD card

Insert SD Card

Insert SIM

PAP5000 DUO EN - 3

Quick Start Guide

Prestigio MultiPhone

PAP5000 DUO

a. Insert SIM cards

The slot on the right is card 2 slot for GSM card, the left is card 1 slot for 3G WCDMA card (compatible with 2G

card).

Please make sure the gold contact area on the SIM is facing downwards.

b. Insert Micro SD card

To insert a Micro SD card, place the card connector towards the front side of the device and the printing side of

the card towards the rear side of the device.

To remove the micro SD card, pull the card out of the slot.

5. Charging

Insert one end of USB cable into the USB port on the

device and plug the power adapter to the electrical socket.

Normally it takes approximately 3.5 hours to fully charge

the device. Operating the device while charging with the

AC adapter may extend the charging time.

Notice: If you don’t use your phone for a long time, it will gradually discharge. Please charge it first before your

next use or charge the phone every 3 months even you don’t use it.

6. Power on/Sleep Mode/Power off

Press and hold the Power Button for a few seconds. It will automatically enter the Home screen after start-up

screen.

EN - 4 PAP5000 DUO

Quick Start Guide

Prestigio MultiPhone

PAP5000 DUO

Press the Power Button once to enter sleep mode and press it again to awake the device.

Press and hold the Power Button, and then tap on Power off to power off the device.

Technical Specifications

Processor

MT6577 Cortex A9 Dual Core at 1 GHz

Memory

512MB DDR2 RAM + 4GB eMMC, Micro SD slot supports up to 32GB

Android 4.0 (Ice Cream Sandwich)

Display

5.0" WVGA TFT-TN LCD, Capacitive multi-touch

Resolution

800*480 WVGA pixels

Band

WCDMA + GSM (UMTS:900/2100MHz; GSM:850/900/1800/1900MHz)

Interfaces

Communications

Battery

USB 2.0, Micro SD (micro SDHC/SDXC compatible)

WiFi (802.11 b/g/n), 3G

2300mAh Polymer Li-ion battery

Dimensions

148.5*79*10.5mm (L x W x H)

Weight

199g

PAP5000 DUO EN - 5

Quick Start Guide

Prestigio MultiPhone

PAP5000 DUO

As the Prestigio products are constantly updated and improved, your device’s software and hardware may have a

slightly different appearance or modified functionality than presented in this Quick Start Guide.

Prestigio hereby states that this Smartphone complies to basic requirements and another relevant

regulations given by the EU directive1999/5/ES. Full version of the declaration of conformity is

available on http://www.prestigio.com/compliance.
