Prestigio GeoVision 7790 Manuale utente

Inside your package

+/-

RESET

В комплекте

Device overview

Обзор устройства

GV7790_QSG_V1.0.indb 1 5/13/2015 3:50:25 PM

Nano SIM

Micro SIM

Standard SIM

Getting started Начало работы

GV7790_QSG_V1.0.indb 2 5/13/2015 3:50:26 PM

Quick Start Guide

Prestigio GPS

1. Program interface

116 13

№Name Function

1 Sound Tapping on the button opens the sound

menu.

2 Compass Tapping on the button opens the context

menu, which controls options of map

orientation ("North up" – the map will

always be oriented northwards, "Track

up" – the map will always be oriented

in the direction of movement along the

route), type of map view (Plain view "2D",

Panoramic view "3D") and skins ("Night

skin", "Day skin", "Auto").

3 Road lanes The sign displays road lanes with possible

maneuvers.

4 Information

panel

The sign shows the upcoming maneuver

(for example, turning) and distance to

the maneuver. Tapping on the sign opens

the menu containing route options, for

instance an option which allows stopping

route guidance.

5 Route Visualization of a current route.

6 Information

panel

The panel shows current speed, the

remaining time to the destination point,

distance to the destination point, and

estimated arrival time.

7 GPS-cursor Indication of a current position on the

map, when the GPS receiver is switched

on.

8 Menu Tapping on the button opens the main

program menu.

9 Information

panel

The panel shows the name of the street

you are currently driving along. The

information is available only if GPS/

GLONASS connection is established and

the map contains such information. If

there is no street name, the direction will

be displayed.

GV7790_QSG_V1.0.indb 1 5/13/2015 3:50:26 PM

Quick Start Guide

Prestigio GPS

24 21

№Name Function

17 "Cursor"

button

Tapping on the button shows the menu

for operations with the point marked on

the map (making it a destination point by

pressing "Go!" button or proceeding to

the properties screen.

18 "Save WP"

button

Saves the point marked on the map as a

waypoint.

19 2D/3D Switching between the plain 2D and the

panoramic 3D map formats.

20 Point on

the map

Short tap on the map marks the point

for further operations with it: saving as a

waypoint, adding to the route or viewing

the object’s data, and others.

10 Scale

button

Zoom out button.

11 Scale

button

Zoom in button.

12 "Navitel.

Events"*

Button for controlling the “Navitel.

Events” service.

13 Route

progress

bar

The progress bar displays the remaining

route, waypoints (if any) and traffic

density on the route marked by color.

14 Battery The icon indicates the level of battery

charge. Tapping on the icon shows free

device memory.

15 GPS GPS-connection indicator. Grey indicator

– GPS/GLONASS-receiver is off; red –

receiver is turned on, but there is no

connection with satellites; yellow –

bad connection; green – connection

is established. The number in the icon

indicates the number of satellites.

16 "Navitel.

Friends"*

The icon of the “Navitel.Friends” service,

tapping on which opens its menu. The

service is intended for adding friends,

viewing their location and exchanging

messages with them.

GV7790_QSG_V1.0.indb 2 5/13/2015 3:50:26 PM

Quick Start Guide

Prestigio GPS

№Name Function

25 "Go!" Tapping on the button gives a command

to the program to calculate a route from

the current position or the set initial point

to the selected point.

26 "Set start" Tapping on the button determines the

selected point as a starting point of the

route (GPS-receiver must be switched

off).

27 "Set finish" The button is active only when there is

an existing route. Pressing the button

continues the route up to the selected

point making it the destination point of

the route.

28 "Route

through"

The button is active only when there is

an existing route. Pressing the button

marks the selected point as a point to

be included in the route. The last added

point becomes the first one in the route

after the starting point.

29 Map Back to map.

* – functionality is available only for devices, having access to

the Internet.

21 Updates * Provides access to the program and map

update menu screen.

22 Track

recording

Button for track recording: red dot–

recording is on, grey dot – recording is

stopped.

23 Navitel.

Traffic*

The icon displays general traffic intensity

on ten-point scale. Tapping on the button

shows the menu for controlling the

“Navitel.Traffic” service.

24 Navitel.

SMS*

The icon allows reading/sending messages

and using coordinates in them. It also

shows the number of unread messages.

26 27

GV7790_QSG_V1.0.indb 3 5/13/2015 3:50:26 PM

Quick Start Guide

Prestigio GPS

2.2 Route to an address

To have a route calculated to a point of a known address,

press "Menu" in the bottom left corner of the screen [1] →

"Find" [2] → "By address", then press "Select country" [3]

and start entering the name of a country [4]. Press the icon

in the upper right part of the screen to hide the keyboard.

Select the country [5]. "Select city", "Select street" and

"Select building" become active only if the previous fields

were filled out [6]. When all information is entered the object

will be shown in the screen [7]. Press "Go!". The program

will automatically plan a route from a current location to the

indicated address [8]. Now you can follow the route [9].

Fig.1

Fig.2

Fig.3

Fig.4

2. Routing

2.1 Route to a point selected on the map

You can have a route planned to a point, which can be found

and marked on the map and then set as the destination,

while current position of the device, determined by the GPS

system becomes the starting point. To plan a route press on

the map to mark the point, select "Cursor" [1] and then "Go!"

[2]. The route will be displayed on the map [3].

Fig.1

Fig.2

Fig.3

GV7790_QSG_V1.0.indb 4 5/13/2015 3:50:27 PM

Quick Start Guide

Prestigio GPS

bottom of the screen [2]. Press "Set start" in the "Properties"

screen [3]. The GPS-receiver must be switched off. The

point will be marked on the map as a starting point. Select

a destination point on the map: tap on the map to mark the

point, press "Cursor" [4] and then press "Go!" in the "My

route" screen [5]. The program will automatically plan a route

[6].

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.5

Fig.6

Fig.7

Fig.8

Fig.9

2.3 Manual setting of all route points

To plan a route, where the starting and the destination points

are determined manually, first mark a point on the map

where you plan to start and press "Cursor" [1] to proceed to

the "My route" screen. Tap on the information panel at the

GV7790_QSG_V1.0.indb 5 5/13/2015 3:50:28 PM

Quick Start Guide

Prestigio GPS

3.2 Navitel. Friends

The "Navitel.Friends" interactive service allows viewing

positions of friends on the map in real-time mode, to plan a

route, using their coordinates, to share coordinates of other

points and exchange messages. To turn the service on select

"Menu" → "Settings" → "Online services" and set the switch

in the "Turn on Navitel.Friends" field to "On" position.

Fig.1

3. Some additional features

For those devices which support Internet connection, various

NAVITEL® online services, including "Navitel.Traffic" and

"Navitel.Friends" are available.

3.1 Navitel.Traffic

The service provides and displays real-time information about

density of traffic on the map. If a part of a road is marked

green on the map this means that road traffic here is normal,

if it is marked yellow – traffic is rather dense, orange – traffic

is heavy, red – there is a traffic jam [1]. To set the service

select "Menu" → "Settings" → "Online services".

Fig.1

GV7790_QSG_V1.0.indb 6 5/13/2015 3:50:28 PM

Quick Start Guide

Prestigio GPS

6. Use the DVR application

a. Tap on the home screen or list menu.

b. Tap Video to start video recording.

Tap Photo to capture photos.

Tap camera mode to select a mode.

In preview mode, tap to enter settings.

7. Technical specifications

Processor Dual Core, 1.3 GHz

Navigation

software

Navitel

Memory RAM 512 MB + 8 GB Flash

Micro SDHC/SDXC, up to 32 GB

OS Android™ 4.4, KitKat®

Display 7” TN, 16:9, 1024*600

Camera Front 0.3 MP, rear 2.0 MP

Band WCDMA: 900/2100 MHz

GSM: 850/900/1800/1900 MHz

Connection Wi-Fi (802.11 b/g/n), 3G, Bluetooth 4.0

Interfaces Micro USB 2.0, micro SD

Battery 3200 mAh

Power source Built-in battery, car charger

Dimension 191.8*119.2*10.7 mm (H*W*D)

Weight 320 g

4. Connect to the Internet

Connect to the Internet either via a Wi-Fi network or your

mobile operator's data connection.

4.1 Connect to a wireless network

a. Tap Settings on the home screen or list menu , and

turn on Wi-Fi.

b. Any detected Wi-Fi networks will be listed. Tap to select

the desired Wi-Fi network.

c. Tap Connect. Enter the network password if required.

4.2 Turn on data connection

a. Tap Settings > More... > Mobile networks > Data enabled.

b. Turn on data connection.

5. Make a call

Tap to open the dial pad, enter the number directly, and

then tap . Or tap the desired number from the call log or

contacts.

GV7790_QSG_V1.0.indb 7 5/13/2015 3:50:28 PM

Quick Start Guide

Prestigio GPS

8. Disclaimer

As Prestigio continuously updates and improves its products,

your device’s software and hardware may have a slightly

different appearance or modified functionalities than those

presented in this quick start guide.

Prestigio hereby states that this device complies to basic

requirements and other relevant regulations given by the

EU directive 1999/5/EC. Full version of the declaration of

conformity is available at: www.prestigio.com/certificates

For the SAR (specific absorption rate) information, please go

to: www.prestigio.com/catalogue/Navigators

GV7790_QSG_V1.0.indb 8 5/13/2015 3:50:28 PM

Altri manuali per GeoVision 7790

Indice

Lingue:

Altri manuali Prestigio GPS

Prestigio

Prestigio GV5055 Manuale utente

Prestigio

Prestigio GeoVision 4700-5700 Manuale utente

Prestigio

Prestigio GV7059 Manuale utente

Prestigio

Prestigio GeoVision 5050 Manuale utente

Prestigio

Prestigio GEOVISION 5055 Manuale utente

Prestigio

Prestigio GeoVision 5500 Manuale utente

Prestigio

Prestigio RoadScout 4150 Manuale utente

Prestigio

Prestigio GeoVision 5500 Manuale utente

Prestigio

Prestigio GeoVision 4466 Manuale utente

Prestigio

Prestigio GeoVision 5056 Navitel Manuale utente

Prestigio

Prestigio GV4300 Manuale utente

Prestigio

Prestigio GEOVISION 5000 Manuale utente

Prestigio

Prestigio GEOVISION 5066 Mireo Manuale utente

Prestigio

Prestigio GV5069 Manuale utente

Prestigio

Prestigio 4050 Manuale utente

Prestigio

Prestigio GV4700BT Manuale utente

Prestigio

Prestigio GEOVISION 5055 Manuale utente

Prestigio

Prestigio GEOVISION 5000 Manuale utente

Prestigio

Prestigio GeoVision 5850HDDVR Manuale utente

Prestigio

Prestigio GeoVision 430 Manuale utente

Prestigio

Prestigio GEOVISION 5055 Manuale utente

Prestigio

Prestigio GV7790 Manuale utente

Prestigio

Prestigio Geovision Tour 3 Sygic Manuale utente

Prestigio

Prestigio GEOVISION 150 Manuale utente

Manuali GPS popolari di altre marche

Raven

Raven Cruizer II Manuale

Hama

Hama 53118 Manuale utente

Garmin

Garmin SOUNDER 125 Manuale utente

Garmin

Garmin DEZL 580 Manuale utente

Jigabot

Jigabot EX Manuale utente

Pointer

Pointer Cellocator CelloTrack XT LTE Guida all'installazione

Queclink

Queclink GV55LITE Manuale utente

Voxson

Voxson Voxtrack GPS500 Manuale di istruzioni

Garmin

Garmin ECHOMAP PLUS Manuale utente

Starcom Systems

Starcom Systems Kylos Compact Manuale utente

Garmin

Garmin 15 H Series Manuale utente

Cobra

Cobra Marine MC 600Ci Manuale utente

Cellocator

Cellocator CelloTrack T Manuale utente

Enfora

Enfora Mini-MT GSM2228UG001 Manuale utente

Magellan

Magellan eXplorist 100 Manuale utente

LTE

LTE G50B Manuale utente

Garmin

Garmin DEZL OTR500 Manuale utente

SkyGolf

SkyGolf SkyCaddie SG1 Manuale utente
