PMP5080CPRO EN - 1

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

1. Packing List

1. Prestigio MultiPad

2. AC Adapter

3. Carrying Case

4. USB Cable

5. Quick Start Guide

6. Warranty Card

7. Legal and Safety Notices

2. Device Overview

Power

Turn on/off the device; Suspend/Activate

the device

Mini-HDMI video

output

HDMI cable connection.

USB port

USB connection.

DC Port

AC adapter connection.

Earphone Jack

Earphones connection.

Built-in Microphone

Record sounds.

Camera

Take photos

EN –2 PMP5080CPRO

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

Charging indicator

Glows with red while charging, and with

green when fully charged.

Vol +\ Vol - Button

Adjust the volume level

Reset

Reset the device in case of

malfunctioning.

Micro SD card slot

Insert the Micro SD card

Getting Started

3. Charging

Insert the AC connector to the DC port on the device and connect the

power adapter to the wall socket for charging.

Normally it takes approximately 4 hours to fully charge the device.

Operating the device while charging with the AC adapter may extend

the time of full charging.

4. Power on/Power off

Press and hold the Power Button to turn on the device. It will

automatically enter the Home screen after the several start-up steps.

Press the Power Button once to enter sleep mode and press it again

to awake the device.

Press and hold the Power Button, and then tap on Power

off/Standby to power off the device.

5．Inserting a Memory Card

The device supports micro SD/SDHC cards.

To insert a Micro SD card, place the card connector towards the front

side of the device and the printing side of the card towards the rear

side of the device.

To remove the micro SD card, gently press the edge of the card to

release the safety lock and pull the card out of the slot.

To access the files on the memory card, select File icon and tap on SD

Card.

Notice:

When you are reading the file from micro SD card, please don’t

PMP5080CPRO EN - 3

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

remove it, or the device could fail to operate correctly.

Home screen

6. Home screen bars

Your device has the capacitive sensitive screen. It is operated by

touching the screen surface with your finger.

Status bar

The status bar displays the time, battery status, WiFi connection and

various notifications.

Applications drawer

Status bar

Quick access

Buttons

panel

EN –4 PMP5080CPRO

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

Time and WiFi area

Displays the current time.

Connected to a WiFi network.

Battery status

Displays the battery power or charging progress.

Buttons panel

Back

Return to the previous screen

Home

Return to the home screen

Recent apps

Recently opened applications

Applications drawer

Pressing the button opens the list of all applications, folders and

shortcuts on the device.

Quick access menu

Quick access to WiFi and Bluetooth settings, brightness etc.

7. Prestigio home screen

Prestigio home screen allows to adjust it according to the user’s

preferences.

Prestigio home screen is made up of five individual screens. Each

room fits the physical display border and can be set to have its own

shortcuts and widgets. You can move around the home screen in the

following way:

Flick the Home screen horizontally until the desired room is displayed.

All the space of the side screens can be used for installing applications,

widgets and shortcuts.

The home screen shortcuts are either direct shortcuts (by touching

them you are directed straight to the application), or have

second-level menus with a number of applications. You can add or

PMP5080CPRO EN - 5

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

remove any applications.

For optimal viewing experience, the screen orientation changes

automatically to portrait or landscape depending on how you hold the

device.

Downloaded applications may not support automatic screen

orientation to portrait or landscape.

To modify the default behavior, open the orientation settings by

touching Settings DisplayAuto-rotate screen. Check the box

to allow automatic screen orientation or uncheck it to block it.

8. Customizing the home screen

To move an item to the home screen:

Touch the button, choose the desired item, touch it and hold,

until the home screen appears. Choose the desired shortcut on the

home screen (or a desired location on the side screen), and release

the item.

To change wallpapers:

Touch and hold on the free area on the screen, then touch Wallpaper,

and choose the wallpaper you wish to add from the list.

To move an item:

Touch and hold the item you want to reposition until it magnifies and

becomes movable.

With your finger remaining in contact with the item on the screen,

drag the item to another location on the screen.

Release the item in the desired location.

To remove an item:

Touch and hold an item such as a widget, shortcut, or folder that you

want to remove, until it magnifies and becomes movable.

Drag the item onto the top of the delete icon, and when the item

becomes red release it.

EN –6 PMP5080CPRO

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

9. On-screen Google search bar

You can access the Google Search tool directly from home screen by

tapping anywhere on the Google search bar.

Note:

Please, make sure your device is connected to the Internet.

PMP5080CPRO EN - 7

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

Keyboard controls for inserting text:

Touch to type letters into the field where the cursor appears.

Based on the letters being typed, the keyboard shows suggested

words under the bar, the most probable one highlighted in color.

You can touch a suggested word to enter it into the text field.

Touch to select the search area. By selecting All the device will

search all available sources. By selecting Web the device will

search the key word only in Internet. By selecting Apps the

device will search the key word in your applications only.

After having typed at least one letter in the search bar, touch and

hold to open the Edit text window. Various editing options are

available. You can select parts of text or all text, change the input

method or add the typed text to the dictionary. After selecting the

text touch it and hold to display the Cut/Copy pop-up box.

Touch once to show the uppercase keyboard for typing a capital

letter.

Touch twice to enable the Caps Lock mode.

Touch to change back to the lowercase keyboard.

Touch to show the keyboard for typing numbers, punctuation

marks, and symbols other than the period.

EN –8 PMP5080CPRO

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

Touch to switch back to the alphabet keyboard.

Touch to delete a typed character, symbol, or a space.

Touch to search the input word.

If you need to type an accented letter, touch the letter and hold it, until

the accented letters appear.

10. Keyboard settings

Touch the Settings Language & inputAndroid keyboard.

To enable a setting, touch the setting option to select the check box

; to disable a setting, touch the setting option to clear the check

box .

Available keyboard settings:

Spelling correction

Automatic correction of the input words.

Personal dictionary

The list of user added words.

Keyboard and input

methods

Select the input language.

Pointer speed

Select the pointer speed.

Creating personal dictionary:

The keyboard uses the default dictionary to display suggested words as

you type. You can create a personal dictionary to include words not found

in the main dictionary. The keyboard will also use the words that are

added to your personal dictionary to make word suggestions.

To add a word to the dictionary:

Touch the Settings Language & inputPersonal

dictionaryAdd.

Type a desired word into the Add to dictionary text field.

Touch OK.

PMP5080CPRO EN - 9

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

To edit a word in the dictionary:

Touch the Settings Language & inputPersonal dictionary.

Touch a desired word.

Edit the spelling of the word in the Edit word text field.

Touch OK.

To delete a word from the dictionary:

Touch the Settings Language & inputPersonal dictionary.

Touch a desired word and press the red cross next to it.

12. Settings

To check storage spaces:

Touch Settings Storage. The screen displays the total and available

space on the device and on the micro SD card.

To erase unwanted application data and to free storage space:

Touch Settings Apps.

From the applications list, touch the application whose cache or data

you want to remove.

In the Application info screen, touch Clear data to erase unwanted

application data; touch Clear cache to erase unwanted cache.

Touch Uninstall to delete the application completely.

To format the microSD card:

Touch Settings Storage.

Touch Erase DS Card.

CAUTION:

Formatting a microSD card erases all data and downloaded applications,

stored on it. Ensure that you back up the data that you need before

formatting your microSD card.

EN –10 PMP5080CPRO

USER MANUAL

Prestigio MultiPad

PMP5080CPRO

Connecting to Internet

13. Connecting to WiFi

Touch Settings Wireless & networks.

If the WiFi is off, tap on the Wi-Fi line to turn it on. Then select the

Wi-Fi settings.

The device will scan for available WiFi networks and display them at

the bottom of the screen.

Tap on the network you want to connect to. Then tap inside the

Wireless password field to make the virtual keyboard appear. Enter

the required network information, tap on Done, and then tap on

Connect.

Your device will now attempt to establish a connection to the WiFi access

point with the network parameters you entered.

14. Browsing the Web

Choose Browser.

In the upper part of the screen the URL of the current page will be

displayed.

To input the address, press the address bar and input the symbols.

During the input the system will suggest possible versions.

The following symbols are displayed next to the address:

Bookmark

Adding a bookmark

Network search

History

The list of visited websites and bookmarks

To stop downloading a page, press Xon the left from the address bar.

The symbol Xis displayed only during page download.

Navigation on a web page

Flick your finger horizontally or vertically on the screen to scroll and view

desired areas of a web page.

Indice

Altri manuali Prestigio Tavoletta

Prestigio

Prestigio MULTIPAD WIZE 3408 4G Manuale utente

Prestigio

Prestigio PMT4348 Manuale utente

Prestigio

Prestigio MultiPad Visconte 4U 3G Manuale utente

Prestigio

Prestigio MultiPad PMP3074B Manuale utente

Prestigio

Prestigio PMP7100 Manuale utente

Prestigio

Prestigio MultiPad PMP7070C3G Manuale utente

Prestigio

Prestigio PMP5101D3G QUAD Manuale utente

Prestigio

Prestigio MULTIPAD WIZE 3407 4G Manuale utente

Prestigio

Prestigio MultiPad 7.0 Prime DUO Manuale utente

Prestigio

Prestigio MultiPad 4 Ultra Quad 8.0 3G Manuale utente

Prestigio

Prestigio MULTIPAD WIZE 3131 3G Manuale utente

Prestigio

Prestigio PMP3370B Manuale utente

Prestigio

Prestigio multipad Manuale utente

Prestigio

Prestigio MultiPad 8.0 Pro Duo Manuale utente

Prestigio

Prestigio MultiPad Visconte Quad PMP880TD Manuale utente

Prestigio

Prestigio MultiPad 7.0 ULTRA+ Manuale utente

Prestigio

Prestigio MULTIPAD GRACE 4991 4G PMT4991-4G Manuale utente

Prestigio

Prestigio MultiPad PMP7100D3G Manuale utente

Prestigio

Prestigio MultiPad 7.0 Prime Duo 3G Manuale utente

Prestigio

Prestigio MultiPad 4 Diamond 7.85 3G Manuale utente

Prestigio

Prestigio MultiPad PMT5001 3G Manuale utente

Prestigio

Prestigio MultiPad 4 Diamond 10.1 3G Manuale utente

Prestigio

Prestigio multipad Manuale utente

Prestigio

Prestigio Q PRO Manuale utente

Manuali Tavoletta popolari di altre marche

Laser

Laser MID-1060 Guida utente

MUNBYN

MUNBYN IRT09J Guida rapida

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manuale utente

Dell

Dell Latitude ST Manuale del proprietario

Lenovo

Lenovo IdeaTab S6000L Manuale del proprietario

Venturer

Venturer WT9L11 Manuale utente

EDUGEAR

EDUGEAR UnoBook Manuale utente

Philips

Philips PI3210G/58 Manuale utente

ADLINK Technology

ADLINK Technology IMT-BT Manuale utente

TwinMOS

TwinMOS TwinTAB-T102D1 Manuale utente

Archos

Archos 9.7 xenon Manuale utente

Getac

Getac E100 Manuale utente

HANNspree

HANNspree HANNspad SN70T3 Manuale utente

Philips

Philips PI3105W2/55 Manuale utente

LG LG-V935 Manuale utente

Zeki

Zeki TBDB763B Manuale utente

Ricoh

Ricoh eQuill Manuale utente

DT Research

DT Research DT365CT Istruzioni per il montaggio
