Prestigio PMP5597D Manuale utente

Prestigio



GEOVISION

PMP5597D_DUO



TECHNICAL

SERVICEMANUAL



Prestigio

1/2

Product Specification

Model:PMP5597D_DUO

Features:

1. CPU: RockChip 3066 Duo Core ARM Cortex-A9

2. Screen:9.7” 1024*768 pixels

3. CTP: G+G

4. 1GB DDR3, 8GBFLASH; optional: 16 GB FLASH

5. WIFI: IEEE 802.11b/g/n

6. Dual camera:2M front camera and 2M rear camera

7. HDMI 1.4 TYPE-C

8. 3D G-Sensor

9. USB OTG

10. Battery: 7000mAh

Specification:

Hardware

CPU RockChip 3066 Duo Core ARM Cortex-A9 + HD video

codec + 3D graphic accelerator

Memory

Flash 8GB MLC

Optional: 16GB MLC

RAM 1GB DDR3

TF CARD Support 2/4/8/16/32GB TF Card

LCD

Size

(Diagonal) 9.7' TFT

Aspect Ratio 4:3

Resolution 1024*768 pixels

Touch Panel Capacitive touch panel(G+G, Support 10 points touch)

Key Power, Reset, Volume+/-, Home

Prestigio

2/2

Camera Front: 2million pixels

Rear: 2 million pixels

Audio Recording

USB

Earphone Via microphone

Speaker 3.5mm stereo earphone

USB 2.0 OTG 1W@8Ωx2

WIFI Support IEEE 802.11b/g/n transport protocol

G-Sensor Support 3D accelerometer game

Video Decoding

AVI（H.264, DIVX, DIVX, XVID, rm, rmvb, WMV, MOV, MP4

（H.264, MPEG, DIVX, XVID), DAT（VCD), VOB（DVD),

MPEG, MPG, FLV（H.263，H.264), ASF, TS, TP, 3GP, MPG

etc

Audio Decoding MP3,WMA,MP2,OGG,AAC,M4A,MA4,FLAC,APE,3GP,WA

Video Container MKV, MP4, AVI, RV/RMVB, VOB, WMV, MPG, TS etc

Picture Format JPG, JPEG, GIF, BMP, PNG

HDMI Support HDMI 1.4 protocol, TYPE-C

Battery 7000mAh

System Update Via TF card and OTA

Logo Update Via TF card

Certification & Regulation CE, FCC, and RoHS compliant

Physical Characteristics Dimension

Operating System

Humidity

Storage

Package

Contents

Humidity

Android 4.0

Operation 0~50°C

Storage -10~60°C

Humidity

Android 4.0

0~90%, Non-Condensed

Micro USB cable * 1pcs

OTG cable*1pcs

AC/DC adapter * 1pcs

User’s manual * 1pcs

Gift box * 1pc (Size: TBD)

Material No# Desription 数量

13800122 TP_CAP_9.7寸_236.6*183.5mm 1

13800128(Substitute material :13800163) TP_CAP_9.7寸_G+G_1024*768_创仕 1

13800158 TP_CAP_9.7寸_G+G_创仕_10点触摸_CT097GG017-00 1

13800163

TP CAP 9 7

寸

瑞视

点触摸屏

支持

点

13800163 TP_CAP_9.7寸

G+G_瑞视

5点触摸屏

支持10点1

138M0179 LCM_9.7寸_1024*768_350Cd/m2_无TP_30pin_深超 1

16000068 螺丝0068_自攻_PB1.7*2.9*3*0.5_电黑_0#槽无介子_平尾 9

16090007 不锈钢压片0007_6*5.4*2.3mm_无表面处理_不锈钢原色 9

18000212

缓冲垫

5mm

18000212

缓冲垫

_20 5mm

18020106 黄色高温胶纸_115*72mm 1

16000075 螺丝_自攻_KA1.4*4mm_银色_十字平头_2.5mm_尖尾 8

15910115 喇叭框架素材_MW07-972_PC+ABS_黑色 1

13020019 PCB_FPC_MR07_LCD_FPC_V2-BI097XN02_1层单拼沉金 1

13830027 CAMERA_200万像素_GSK4-924MR07-K1_66度-SP2518 1

13740054 LI_BAT_7000mAh_3.8*120*140mm 1

13430040 SPK_8R_0.8W_20.0*14.0*3.4mm_单磁(TTK) 2

135M0019 ANT_ASSY_MW07_WIFI外购成品天线_130mm 1

18020106

黄色高温胶纸

115*72

18020106

黄色高温胶纸

115*72mm 1

18090035 铜箔纸_30*11*0.1mm 1

18000351 后置摄像头垫_10*10*0.7mm 1

13680071 CAB_OTH_按键板连接线_63mm_4PIN排线_MR07-9721 1

005

摄橡头垫片

黑色

15910052

摄橡头垫片

_MW07 9703

黑色

18020054 黄色高温绝缘胶纸_50*21mm 5

18020057 高温绝缘胶纸0057_75*20mm 1

18020045 高温绝缘胶纸_10*20mm 8

18010010 EMI 辅料_导电布_100*21mm 1

18010020 EMI 辅料_导电泡棉0020_15*10*3mm 2

16000210 螺丝_机牙_KAB1.4*3.5mm_碳钢加硬_红色_十字槽_2.7_尖脚 2

18000206 喇叭泡棉垫_12*0.7MM+3M_PSR0.7+4972 2

15010018 密封圈_喇叭密封圈_21*15MM+3M 2

18000212 缓冲垫_20*5mm 4

TESTPTVE910S1301 TESTTVE910S_V1.3_01_1G-D_16G-F_WIFI德天方案 1

TESTPTVE910RK131 TESTTVE9010R-K1-V1.3_01德天方案 1

151M0306

面壳组件

MR07 9721

红色

橡胶漆

151M0306 面壳组件

MR07-9721_红色

橡胶漆 1

153M0262 底壳组件_MR07-9721_黑色镭雕 1

13440028 MIC_Φ4.0*1.5_-42dB±3dB_带Φ4.8mm咪头套_128mm 1

17002321 20092_防水贴纸_4*4mm_水损 1

13700077

CHARG 5V/2A 2 5mmDC

头

12m

不带插头

带磁环

13700077

CHARG

5V/2A

5mmDC

头

不带插头

带磁环

-2

13180065 JAC_OTH_电源插头_BI10-050200-I-欧规插脚 1

13180067 JAC_OTH_电源插头_BI10-050200-I-英规插脚 1

Maintenance Manual for Tablet MR07(TVE910S_V1.3)

This manual describes common failures and troubleshooting from the angle of circuit

principles. It is for your information. This manual introduces in general positions for circuit

investigation. Please refer to maintenance schematic diagram for circuit details.

I. Booting Failure

The phenomena of booting failure include no display of LCD (and no backlight), no

speaker sounds, no response of touch screen when touching, no response of power-on/

power-off key stroke and no response of reset. Reasons for these vary. Following the

troubleshooting steps below for failures of different kinds.

1. Abnormal System Power Supply

Firstly perform tests of short circuit to earth on the power test points on the board to

eliminate cause of short circuit to earth. Connect the board to DC power or battery,

power on the device and investigate the problem as stated in the table below.

Table 1 System Power Supply

Power Test Point Normal Voltage

Range Reasons for Failures (Investigation Range)

DC 5V 5+/-0.5V Plug with DC power, this point shall have

5+/-0.5V

VSYS 3.5V-5V This point is system main power, if abnormity,

check if PMU well welded or if short circuit to

earth.

T27/VDD_LOG 1.2V+/-0.2V This is CPU core power supply,if abnormity,

check if PMU well welded or if short circuit to

earth.

T30/VDD_ARM 1.2V+/-0.2V This is CPU core power supply, if abnormity,

check if PMU well welded or if short circuit to

earth.

T28/VCC_DDR 1.56V+/-0.1V This is power supply of CPU and memory, if

abnormity, check circuit of PMU part.

T29/VCC_IO 3.0V +/-0.1V This is IO power supply, check circuit of PMU

part.

Since RK platform apply PMU, power supply abnormity is usually caused by poor

welding of PMU and related peripheral components

2. Poor Welding or Abnormity of CPU, Memory and Flash

After the above investigation, the system power supply should be normalized. The

following circuits need to be checked.

a. Check if the CPU and peripheral components are well welded.

b. Check if Y2 crystal oscillates.

c. Check if RAM, Flash and peripheral components are well welded, if Flash card data

lost or if reprogram Flash.

3. No Display of LCD

Confirm the current is normal the equipment is started. If LCD has no display when

connected, do investigation by following the steps below.

a. Firstly check if voltage of VCC_LCD (3.0V+/-0.1V) is normal,

if abnormal, check U19 and surrounding circuits.

If normal, the system startup is normal, please check backlight IC(U22) and surrounding

circuits.

b. Connect the LCD and then check backlight driving circuit.

c. If the system cannot be started after confirming that relevant components of the CPU,

memory and Flash are well welded, please consider replacing Flash, CPU and

memory.

II. Functional Fault Checking

1. Failure of Charging and Power Detection

Abnormal charging: For charging failure when DC is applied, check whether the welding

of U85 2611 charging IC peripheral components are good,whether the battery is

damaged, whether the surrounding circuit is normal.

Abnormal DC insertion check (software shows battery power supply when DC

power is inserted): Confirm first DC 5V has a voltage of around 5V,and then check if U85

is well welded.

The equipment does not work with battery power supply (but work with

external power supply): Without external power supply, check if the voltage of VSYS is

normal and if the circuit of PMU part is normal.

2. Abnormal Operation of USB and USB Peripheral

Detection failure of USB insertion: While connecting MID with PC via USB cable,

USB insertion cannot be detected. Check mainly the circuits of USB-DET, R53 R56 Q7

are well welded.

OTG dysfunction：Confirm if VCC-OTG has a voltage of around 5V when OTG

cable inserted. Confirm if OTG-ID voltage is at a low level. If the voltage is lower than

5V, check if U16 well welded.

3. Abnormal LCD Operation

Abnormal LCD backlight：

LCD backlight does not work：Check if the circuit of Part U22 in normal operation.

Nonadjustable LCD backlight brightness: Check if the circuit of Part U22 is

normal.

Abnormal LCD color display:

Check if LCD extension cords are well welded, if circuits of U19 and surrounding

parts are normal.

Touch screen abnormity:

Run touch screen calibration program and then check if it is normalized.

Replace the LCD screen.

Check if display base is well welded. Check if the connection of LCD extension cords

and the CPU is normal. Check if the CPU is welded without tin.

4.Abnormal Operation of TF card

Detection failure of card insertion:

Check if the card connector is damaged and if it is well welded.

Check if power supply of VDD_SD is normal as 3.0V+/-0.1V，if abnormal, please

check PMU circuit.

Check if TF card peripheral components are well welded or if damaged.

5.Abnormal sounds

No sounds of earphone and speaker:

Check U17 related components.

Check if the earphone extension cord is damaged.

Earphone with sounds and speaker no sounds

Check earphone related components.

Abnormal sounds of earphone and speaker

Check U17 related components.

6.WIFI abnormity

WIFI can not scan：

Turn on WIFI，then check if the voltage of VCCIO-WLis normal as 3.3V+/-0.1V，if not,

please check PMU circuit.

Check if welding of WIFI module is good.

Can not detect signal：

Check if antenna plate and feeder are well welded.

7. Camera Abnormity

Run the camera application and then check if related current is normal, if voltage of

VCC28-CIF is 2.8V around. Check if voltage of VCC18-CIF is 1.8V around.

Check if exclusion and camera extension cords are well welded.

8.G-sensor Failure

Check if G-sensor IC is well welded.

9. Button Failure

Check if circuit of the button part is normal. Check if each voltage is normal when

buttons pressed down.

10.Other Failures

A. Large operation current of the system：Check if the main board has heating

components. Test if the power test points of relevant heating components are short

circuited to earth or with small resistance to earth. If yes, replace relevant components.

B. Booting Failure：

Firstly check if PMU related power is normal, if yes, then rewrite img file since the

problem is maybe caused by img file loss. If the device can not boot after rewriting,

probably there is something wrong with the memory.

µÂÌìÐÅÏ¢¼¼ÊõÓÐÏÞ¹«Ë¾



Monday, August 20, 2012



TECHVISION INFORMATION TECHNOLOGY CO.LTD



Index



V1.0



TVE907R



Sheet



Date:



Rev



Project



Size



Schematic



11.AUDIO



12.LCD PANEL



13.TOUCH PANEL



14.HDMI/ATSC



15.CAMERA/G_SENSOR/KEY/COMP/IR



05.DC/CHARG



07.USB OTG/VIB



08.DDR3



03.Block Diagram



01. INDEX



04.SYSTEM POWER DIAGRAM



02.Modify note



09.FLASH/SD



10.GPIO



06.SYSTEM POWER



16.WIFI/3G



17.GPS



above 80 miles



PCB POWER WIRE WIDTH INDICATE



above 50 miles



above 16 miles



above 30 miles



Under needs



No indicate



CONTENT INDEXING



6 LAYERS PCB STACK



Hoz(18um) + plating copper(18um)



1oz(35um)



1oz(35um)



1oz(35um)



1oz(35um)



Hoz(18um) + plating copper(18um)



Prepreg 3313*1 4.0MIL(0.10mm)



Prepreg 3313*1 4.0MIL(0.10mm)



Core 3.94MIL(0.1mm)



Core 3.94MIL(0.1mm)



Adjust



GND



S1(S2)



GND(POWER)



S2(BOTTOM)



TOP



POWER(S1)



µÂÌìÐÅÏ¢¼¼ÊõÓÐÏÞ¹«Ë¾



Monday, August 20, 2012



TECHVISION INFORMATION TECHNOLOGY CO.LTD



NOTE



V1.0



TVE907R



Sheet



Date:



Rev



Project



Size



Schematic



Approved



Author



Change Note



Date



Version



V1.0



20120220



HCH



First edictor



Altri manuali per PMP5597D

Indice

Altri manuali Prestigio Tavoletta

Prestigio

Prestigio MultiPad 7.0 ULTRA+ Manuale utente

Prestigio

Prestigio PMP7074B3G Manuale utente

Prestigio

Prestigio PMT3777 Manuale utente

Prestigio

Prestigio Multipad Visconte M Manuale utente

Prestigio

Prestigio MULTIPAD GRACE 4991 4G PMT4991-4G Manuale utente

Prestigio

Prestigio MultiPad PMT3038 3G Manuale utente

Prestigio

Prestigio MultiPad PMP3084BRU Manuale utente

Prestigio

Prestigio Grace 3318 3G Manuale utente

Prestigio

Prestigio MultiPad PMP7100D3G Manuale utente

Prestigio

Prestigio MultiPad 7.0 Prime Duo 3G Manuale utente

Prestigio

Prestigio Muze 4231 4G Manuale utente

Prestigio

Prestigio MultiPad PMT3037 3G Manuale utente

Prestigio

Prestigio MultiPad PMT5021 3G Manuale utente

Prestigio

Prestigio MultiPad PMT3787 Manuale utente

Prestigio

Prestigio MultiPad PMT 30 1 Series Manuale utente

Prestigio

Prestigio MultiPad 4 Ultra Quad 8.0 3G Manuale utente

Prestigio

Prestigio MultiPad PMT3047 3G Manuale utente

Prestigio

Prestigio MultiPad PMP5097CPRO Manuale utente

Prestigio

Prestigio PMP812 Manuale utente

Prestigio

Prestigio PMP5570C Manuale operativo

Prestigio

Prestigio MultiPad 4 Diamond 10.1 3G Manuale utente

Prestigio

Prestigio PMP5597D_BF_DUO Manuale utente

Prestigio

Prestigio MultiPad 8.0 HD Manuale utente

Prestigio

Prestigio MULTIPAD WIZE 3147 3G Manuale utente

Manuali Tavoletta popolari di altre marche

Laser

Laser MID-1060 Guida utente

MUNBYN

MUNBYN IRT09J Guida rapida

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manuale utente

Dell

Dell Latitude ST Manuale del proprietario

Lenovo

Lenovo IdeaTab S6000L Manuale del proprietario

Venturer

Venturer WT9L11 Manuale utente

EDUGEAR

EDUGEAR UnoBook Manuale utente

Philips

Philips PI3210G/58 Manuale utente

ADLINK Technology

ADLINK Technology IMT-BT Manuale utente

TwinMOS

TwinMOS TwinTAB-T102D1 Manuale utente

Archos

Archos 9.7 xenon Manuale utente

Getac

Getac E100 Manuale utente

HANNspree

HANNspree HANNspad SN70T3 Manuale utente

Philips

Philips PI3105W2/55 Manuale utente

LG LG-V935 Manuale utente

Zeki

Zeki TBDB763B Manuale utente

Ricoh

Ricoh eQuill Manuale utente

DT Research

DT Research DT365CT Istruzioni per il montaggio
