RemotePlusController

Synergy TRU-Balance

BASIC OPERATION INSTRUCTIONS

Remote Plus

Controller

ACN# 088 609 661

TMTM

2 BasicOperationInstructions

Remote Plus Controller www.pridemobility.com

INFORMATION LABELING

Read and follow the information in the owner’s manual.

Avoid exposure to rain, snow, ice, salt, or standing water

whenever possible. Maintain and store in a clean and dry

condition.

Disposal and recycling - Contact your authorized Pride

Provider for information on proper disposal and recycling of

your Pride product and its packaging.

PrideMobilityProductsCorporation

INFMANU1773/RevC/November 06

Thesymbols beloware usedthroughout thisowner's manualand onthe power

chairtoidentifywarningsandimportantinformation.Itisveryimportantforyouto

readthemandunderstandthemcompletely.

WARNING! Indicates a potentially hazardous condition/

situation. Failure to follow designated procedures can cause

either personal injury, component damage, or malfunction.

On the product, this icon is represented as a black symbol

on yellow triangle with black border.

MANDATORY! These actions should be performed as

specified. Failure to perform mandatory actions can cause

personal injury and/or equipment damage. On the product,

this icon is represented as a white symbol on a blue dot with

a white border.

PROHIBITED! These actions are prohibited. These actions

should not be performed at any time or in any circumstances.

Performing a prohibited action can cause injury to personnel

and/or damage to equipment. On the product, this icon is

represented as a black symbol with a red circle and a red

slash.

BasicOperationInstructions 3

www.pridemobility.com Remote Plus Controller

TABLE OF CONTENTS

INTRODUCTION ................................................................................. 4

REMOTE PLUS CONTROLLER ................................................... 6

PRECAUTIONARY GUIDELINES................................................. 6

OPERATING THE REMOTE PLUS CONTROLLER............ 10

3-PIN OFF-BOARD CHARGER/PROGRAMMING SOCKET .13

CONTROLLER COMMUNICATIONS CONNECTOR ........... 14

ACTUATOR ADJUSTMENT ......................................................... 14

SPEED ADJUSTMENT/PROFILE SELECT........................... 15

SLEEP MODE .................................................................................... 15

THERMAL ROLLBACK .................................................................. 15

FAULT CODES................................................................................... 16

CARE AND MAINTENANCE ........................................................ 17

WARRANTY ........................................................................................ 17

4 BasicOperationInstructions

Remote Plus Controller www.pridemobility.com

INTRODUCTION

WELCOMEto PrideMobility ProductsCorporation (Pride).The productyou

havepurchasedcombinesstate-of-the-artcomponents with safety, comfort, and

stylinginmind.Weareconfidentthatthedesignfeatureswillprovideyouwiththe

conveniencesyouexpectduringyourdailyactivities.Understandinghowtosafely

operateandcareforthisproductshouldbring you yearsoftroublefreeoperations

andservice.

Readand followallinstructions,warnings,andnotesinthismanualandallother

accompanying literature before attempting to operate this product for the first

time.Inaddition,yoursafetydependsuponyou,aswellasyourprovider,caretaker,

orhealthcareprofessionalinusinggoodjudgement.

Thismanualistobeusedinadditiontothepowerbaseowner’smanualthatcamewith

yourpowerchair.Ifthereisanyinformationinthismanualwhichyoudonotunderstand,

or if you require additional assistance for setup or operation, please contact your

authorizedPrideProvider.Failuretofollowtheinstructions,warnings,andnotes

inthismanualandthoselocatedonyourPrideproductcanresultinpersonal

injuryand/orproductdamageandwillvoidPride’sproductwarranty.

PURCHASER’SAGREEMENT

Byacceptingdeliveryofthisproduct,youpromisethat you will notchange,alter,

or modify this product or remove or render inoperable or unsafe any guards,

shields,orothersafetyfeaturesofthisproduct;fail,refuse,orneglecttoinstallany

retrofitkits fromtimeto timeprovided byPrideto enhanceor preserve thesafe

useofthis product.

INFORMATIONEXCHANGE

Wewant tohearyour questions,comments,and suggestions aboutthis manual.

We would also like to hear about the safety and reliability of your new Pride

product,andabouttheserviceyoureceivedfromyourauthorizedPrideProvider.

Pleasenotifyusofanychangeofaddress,sowecankeepyouapprisedofimportant

informationabout safety, newproducts, and newoptions that canincrease your

abilitytouse andenjoyyourPride product.

BasicOperationInstructions 5

www.pridemobility.com Remote Plus Controller

NOTE: If you ever lose or misplace your product registration card or your

copy of this manual, contact us and we will be glad to send you a new one

immediately.

My authorized Pride Provider Is:

Name: _____________________________________________________

Address:____________________________________________________

PhoneNumber: ______________________________________________

PurchaseDate: _______________________________________________

6 BasicOperationInstructions

Remote Plus Controller www.pridemobility.com

REMOTEPLUS CONTROLLER

TheRemotePlusControllerisafully-programmable,modularelectroniccontroller

systemthatallowsyoutooperateyourpowerchair. It is designedtoallowtheuser

tohavecomplete controloverchairmovement andspeed.

The controller has been pre-programmed to meet a typical user’s needs. The

programis set using either apersonal computer with software providedby the

controllermanufacturer orwith ahand-held programmer, also providedby the

controllermanufacturer.

WARNING! The controller program can affect speed,

acceleration, deceleration, dynamic stability, and braking.

If it is programmed incorrectly or outside of the safe limits

as determined by your healthcare professional, it can create

a dangerous situation. Only the power chair manufacturer,

an authorized representative of the manufacturer, or a trained

service technician should program the controller.

PRECAUTIONARYGUIDELINES

Beforeoperating theRemote PlusController, please read thefollowing.These

guidelinesareprovided foryourbenefitand willaidyouin thesafeoperationof

thecontrollersystem.

!Turnoffthe power tothecontrollerwhentransferring to orfromyourpower

chair.

!Followalloftheproceduresandheedthewarningsasexplainedinyourpower

chairowner’smanual.

Failure to heed the above warnings can result in personal injury and/or

equipmentdamage.

BasicOperationInstructions 7

www.pridemobility.com Remote Plus Controller

Electromagnetic and Radio Frequency Interference (EMI/RFI)

WARNING! Laboratory tests have shown that electromagnetic

and radio frequency waves can have an adverse affect on

the performance of electrically-powered mobility vehicles.

ElectromagneticandRadioFrequencyInterferencecancomefromsourcessuchas

cellularphones,mobiletwo-wayradios(suchaswalkie-talkies),radiostations,TV

stations,amateurradio(HAM)transmitters,wirelesscomputerlinks,microwavesig-

nals,pagingtransmitters,andmedium-rangemobiletransceiversusedbyemergency

vehicles.Insomecases,thesewavescancauseunintendedmovementordamageto

thecontrolsystem.Everyelectrically-poweredmobilityvehiclehasanimmunity(or

resistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainst

EMI.Thisproducthasbeentestedandhaspassedatanimmunitylevelof20V/m.

WARNING! Be aware that cell phones, two-way radios,

laptops, and other types of radio transmitters may cause

unintended movement of your electrically-powered mobility

vehicle due to EMI. Exercise caution when using any of these

items while operating your mobility vehicle and avoid coming

into close proximity of radio and TV stations.

WARNING! The addition of accessories or components to

the electrically-powered mobility vehicle can increase the

susceptibility of the vehicle to EMI. Do not modify your power

chair in any way not authorized by Pride.

WARNING! The electrically-powered mobility vehicle itself

can disturb the performance of other electrical devices

located nearby, such as alarm systems.

NOTE: For further information on EMI/RFI, go to the Resource Center on

www.pridemobility.com. If unintended motion or brake release occurs, turn

yourcontroller offassoon as itissafe to doso.Call Prideor your authorized

Pride Provider to report the incident.

8 BasicOperationInstructions

Remote Plus Controller www.pridemobility.com

Remote Plus Controller Features

Figure1providesinformationontheRemotePluscomponents and connections.

Usethis diagramto familiarize yourself with the function andlocation ofeach

componentbeforeusingtheRemotePlusController.

ThefollowingfunctionsareavailablewiththeRemotePlusController:

!JoystickControl

Thejoystick is usedto controlthedirection andspeed of thepower chair.

!ActuatorAdjustment

TheusercancontrolpositioningofpoweraccessoryactuatorswiththeRemote

Plus.

!DriveProfileSelection

Theusercanselectoneoffiveavailabledrive profiles.

!SpeedAdjustment

Theuser can increaseor decrease themaximum speed ofthe power chair.

!SleepMode

Thisfeatureisdesignedtopreservebatterycharge,andcanbedisabledthrough

programming.

!ThermalRollback

Thisisasafetyfeaturedesignedtoprevent the power chairfromoverheating

andcausingdamage to themotorsorcontroller.

NOTE: The Remote Plus can be programmed to have up to five drive

profiles or one drive profile and five speed adjustments.

BasicOperationInstructions 9

www.pridemobility.com Remote Plus Controller

Figure 1. Remote Plus Components and Connections (3-Key Shown)

Mode Button

Used to select the various

functions available with the

Remote Plus.

On/Off Button

Press to power on or off the

power chair and controller.

BACK VIEW

Speed/Profile Indicator

Series of five colored LEDs

which display the speed or

profile setting.

Battery Condition Meter

Indicates the approximate

amount of battery life using

color-coded LED bars.

Horn Button

Activates a warning horn.

Mounting Bracket Access

An alternate Remote Plus mounting option

may be available with your power chair.

Harness Connector Port

Used to connect the Remote Plus to the

power base.

Actuator Indicators

Four LEDs indicate

recline, tilt, power leg

rests, and elevating seat

actuator modes.

Joystick

A multi-functional tool used

to control speed, direction,

and actuator adjustment.

Off-board Charger/

Programming Port

Used to charge or

program the power base.

10 BasicOperationInstructions

Remote Plus Controller www.pridemobility.com

OPERATING THEREMOTE PLUSCONTROLLER

The Remote Plus Controller is used to operate your power chair and all of its

components.

TheRemotePluscontrollerconsistsof(seefigure2):

1. joystick

2. keypad

3. controllercommunicationsconnector

4. 3-pinoff-boardcharger/programmingsocket

5. powermodule

6. intermediateharnesswithchargerconnection

Joystick Control

The joystick controls the direction and speed of your power chair. When you

movethejoystick from theneutral(center) position, theelectromagneticbrakes

releaseand allow your power chairto move. The farther youpush thejoystick

fromitsneutralposition,thefasteryourpowerchairmoves.Whenyoureleasethe

joystickandallowittoreturn to the neutralposition,youengagetheelectromag-

neticbrakes.This causes yourpowerchairto decelerate andcometoa complete

stop.

Keypad

Thekeypadislocateddirectlyinfrontofthejoystick.Itcontainskeysthatyouwill

useto controlyour powerchair.See figures3 and4.

On/Off Key

Theon/offkeyturns the systemonandoff.

WARNING! Unless faced with an emergency situation, do

not use the on/off key to stop the chair. This will cause the

power chair to stop abruptly.

WARNING! Always turn the power off when you are stationary

to prevent unexpected movement.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Pride Mobility Ausilio alla mobilità

Pride Mobility

Pride Mobility TRAVEL SCOOTER Series Manuale utente

Pride Mobility

Pride Mobility Vista Manuale utente

Pride Mobility

Pride Mobility Go-Go Ultra X Manuale utente

Pride Mobility

Pride Mobility Jazzy 610 Series Manuale utente

Pride Mobility

Pride Mobility Jazzy Select Traveller Manuale utente

Pride Mobility

Pride Mobility SilverStar SilverBoom 300 Manuale utente

Pride Mobility

Pride Mobility Victory XL-3 Manuale utente

Pride Mobility

Pride Mobility Jet 12 Manuale utente

Pride Mobility

Pride Mobility PVM Series Manuale utente

Pride Mobility

Pride Mobility Jazzy Elite ES Manuale utente

Pride Mobility

Pride Mobility Jazzy 1122 Manuale utente

Pride Mobility

Pride Mobility QUEST Manuale utente

Pride Mobility

Pride Mobility S34P Manuale utente

Pride Mobility

Pride Mobility SilverStar Mobility Exterior LIft Manuale utente

Pride Mobility

Pride Mobility Power Tote P-100 Manuale utente

Pride Mobility

Pride Mobility Meuris Manuale utente

Pride Mobility

Pride Mobility CELEBRITY X Manuale utente

Pride Mobility

Pride Mobility PURSUIT Manuale utente

Pride Mobility

Pride Mobility SilverStar Wheelchair/Scooter Lift Manuale utente

Pride Mobility

Pride Mobility Knock-Down Lift Chair KD Manuale utente

Pride Mobility

Pride Mobility SilverStar Exterior Lift System Manuale utente

Pride Mobility

Pride Mobility FUSION Manuale utente

Pride Mobility

Pride Mobility Jazzy 600 Series Manuale utente

Pride Mobility

Pride Mobility Go-Go Elite traveller Manuale utente

Manuali Ausilio alla mobilità popolari di altre marche

Alber

Alber Scalamobil iQ Manuale utente

Ferno

Ferno CCT-PX Manuale utente

HEPRO

HEPRO Gripo Manuale utente

Otto Bock

Otto Bock Pheon 3R62 Manuale utente

NRS Healthcare

NRS Healthcare M11090 Manuale utente

Medline

Medline MDS86835DSHEC Guida all'installazione

Guldmann

Guldmann Twin Turner II Manuale utente

Drive

Drive ROOMBA Manuale utente

Gate

Gate Balder Manuale utente

Decon wheel

Decon wheel TNS Notos Manuale utente

ExoAtlet

ExoAtlet ExoAtlet-II Manuale utente

Invacare

Invacare Storm Series Manuale di istruzioni

Rhythm Healthcare

Rhythm Healthcare B3800F Manuale utente

AMF-BRUNS

AMF-BRUNS PROTEKTOR Manuale utente

Drive DeVilbiss Healthcare

Drive DeVilbiss Healthcare OTTER Manuale utente

Rhythm Healthcare

Rhythm Healthcare C500U Manuale utente

Lumex

Lumex RJ4200A Manuale utente

Rebotec

Rebotec Jumbo Manuale utente
