Pride Mobility Legend Manuale utente

Owner’s Manual

Exeter, PA

St. Catharines, ON 1-800-800-8586

www.pridemobility.com

The Ultimate In Style & Performance

ATTENTION:

Read everything

in this manual

before operating

your Scooter

Legend

SAFETY GUIDELINES

Pride Mobility Products Corp.

Please read and follow all instructions in this owners manual before attempting to operate your cooter for

the first time. If there is anything in this manual you do not understand, or if you require additional assistance

for set-up, contact your authorized Pride provider.

Using your Pride product safely depends upon your diligence in following the warnings, cautions, and

instructions in this owners manual. Using your Pride product safely also depends upon your own good

judgement and/or common sense, as well as that of your provider, caregiver, and/or healthcare professional.

Pride is not responsible for injuries and/or damage resulting from any persons failure to follow the warnings,

cautions, and instructions in this owners manual. Pride is not responsible for injuries and/or damage resulting

from any persons failure to exercise good judgement and/or common sense.

The symbols below are used throughout this owners manual to identify warnings and cautions. It is very

important for you to read and understand them completely.

WARNING! Failure to heed the warnings in this owners manual may result in personal injury.

CAU ION! Failure to heed the cautions in this owners manual may result in damage to your

Scooter.

INFMANU1000/REV A/OCTOBER 2001

3Legend

CONTENTS

I. INTRO UCTION ........................................................................................................................ 4

II. SAFETY ......................................................................................................................................... 6

III. EMI/RFI ........................................................................................................................................ 15

IV. SPECIFICATIONS ................................................................................................................... 17

V. YOUR LEGEN ......................................................................................................................... 19

VI. BATTERIES AN CHARGING ........................................................................................... 23

VII. OPERATION............................................................................................................................... 28

VIII.COMFORT A JUSTMENTS................................................................................................ 30

IX. ISASSEMBLY AN ASSEMBLY ..................................................................................... 33

X. OPTIONAL ACCESSORIES ................................................................................................. 36

XI. BASIC TROUBLESHOOTING ............................................................................................. 37

XII. CARE AN MAINTENANCE ............................................................................................... 38

XIII. WARRANTY .............................................................................................................................. 39

4Legend

I. INTRODUCTION

Welcome to Pride Mobility Products Corporation (Pride). Congratulations on the purchase of your new Pride

cooter. Your cooter design combines the most advanced state-of-the-art components with modern, attractive

styling. We are certain that the design features and trouble-free operation will add convenience to your daily

living and ensure complete satisfaction.

At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before

you attempt to operate your Scooter for the first time. These instructions were produced for your benefit.

Your understanding of these instructions is essential for the safe operation of your new Pride cooter.

Pride is not liable for damage to property or personal injury arising out of unsafe use of a Pride cooter.

Pride is also not liable for any property damage or personal injury arising out of the failure of any person

and or/user to following the instructions and recommendations set forth in this manual or any other

instructions or recommendations contained in other cooter related literature issued by Pride or contained

on the Pride cooter itself.

This owners manual is compiled from the latest specifications and product information available at the time of

publication. We reserve the right to make changes as they become necessary. Any changes to our products may

cause slight variations between the illustrations and explanations in this manual and the product you have

purchased.

If you experience any problems with your cooter that your are unable to solve, or if you do not feel capable of

safely following any of the instructions and/or recommendations as contained in this manual, please contact

your authorized Pride provider for assistance.

Once you understand how to operate and take care of your cooter, we are certain that it will give you years of

trouble-free service and enjoyment.

Information Exchange

We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about

the safety and reliability of your new Pride cooter, and about the service you received from your authorized

Pride provider.

Please notify us of any change of address, so we can keep you apprised of important information about safety,

new products, and new options that can increase your ability to use and enjoy your Pride cooter. Please feel free

to write us at the address below:

Pride Mobility Products Corporation

Attn: Technical ervice Department

182 usquehanna Avenue

Exeter, PA 18643-2694

5Legend

Pride Owners Club

As an owner of a Pride product, you are invited to register your products warranty and enroll in the Pride

Owners Club. You may do so by filling out and returning your enclosed registration card or by visiting Prides

web site at www.pridemobility.com. As a registered member, each time you visit our site, you will have access

to the most interactive and honest educational venue available today for people with mobility needs, their

families, and friends.

From our home page, click on the button that reads Owners Club to enter a page dedicated to current and

potential Pride product owners. You will gain access to interviews, stories, recreation ideas, daily living tips,

product and funding information, and interactive message boards. On these message boards you are invited to

speak with other Pride customers as well as Pride representatives who are available to assist you with any

questions or concerns you may have.

My Authorized Pride Provider Is:

Name:_______________________________________________________________________________

Address:_____________________________________________________________________________

Phone Number:________________________________________________________________________

Quick Reference Information:

cooter Model:________________________________________________________________________

erial Number:__________________________________________________________________________

Purchase Date:________________________________________________________________________

NOTE: If you ever lose or misplace your warranty card or your copy of this manual, call or write to us and

we will be glad to send you a new one immediately.

I. INTRODUCTION

6Legend

GENERAL

WARNING! Do not operate your new Scooter for the first time without completely reading and

understanding this owners manual.

Your cooter is a state-of-the-art life-enhancement device designed to increase mobility. Pride provides an

extensive variety of products to best fit the individual needs of the cooter user. Please be aware that the

final selection and purchasing decision regarding the type of cooter to be used is the responsibility of the

cooter user who is capable of making such a decision and his/her healthcare professional (i.e., medical

doctor, physical therapist, etc.).

The contents of this manual are based on the expectation that a mobility device expert has properly fitted

the cooter to the user and has assisted the prescribing healthcare professional and/or the authorized Pride

provider in the instruction process for the use of the product.

There are certain situations, including some medical conditions, where the cooter user will need to practice

operating the cooter in the presence of a trained attendant. A trained attendant can be defined as a family

member or care professional specially trained in assisting a cooter user in various daily living activities.

As you begin using your cooter during daily activities, you will probably encounter situations in which

you will need some practice. imply take your time and you will soon be in full and confident control as

you maneuver through doorways, on and off elevators, up and down ramps, and over moderate terrain.

Below are some precautions, tips, and other safety considerations that will help the user become accustomed

to operating the cooter safely.

MO IFICATIONS

Pride has designed and engineered your cooter to provide maximum mobility and utility. A wide range of

accessories is available from your Pride provider to further customize your cooter to better suit your needs

and/or preferences. However, under no circumstances should you modify, add, remove, or disable any

feature, part, or function of your cooter.

WARNING! Do not modify your Scooter in any way not authorized by Pride. Unauthorized

modifications may result in personal injury and/or damage to your Scooter.

II. SAFETY

7Legend

PRE-RI E SAFETY CHECK

Get to know the feel of your cooter and its capabilities. Pride recommends that you perform a safety check

before each use to make sure your cooter operates smoothly and safely. For details on how to perform

these necessary inspections, see XII. Care and Maintenance.

Perform the following inspections prior to using your cooter:

nCheck for proper tire inflation. Maintain 30-35 psi in each tire (if equipped with pneumatic tires).

nCheck all electrical connections. Make sure they are tight and not corroded.

nCheck all controller connections to the utility tray. Make sure they are secured properly.

nCheck the brakes.

nCheck battery charge.

WARNING! It is critically important that 30-35 psi tire pressure be maintained in pneumatic tires at

all times. Failure to maintain 30-35 psi tire pressure in pneumatic tires at all times may result in

catastrophic tire and/or wheel failure, causing serious personal injury and/or damage to your

Scooter.

WARNING! Do not carry passengers on your Scooter. Carrying passengers on your Scooter may

result in personal injury and/or property damage.

If you discover a problem, contact your authorized Pride provider for assistance.

WEIGHT LIMITATIONS

Your cooter is rated for a 300-lb. maximum weight limit.

INCLINE INFORMATION

More and more buildings have ramps with specified degrees of inclination, designed for easy and safe

access. ome ramps may have turning switchbacks (180-degree turns) that require you to have good

cornering skills on your cooter.

nProceed with extreme caution as you approach the downgrade of a ramp or other incline.

nTake wide swings with your cooters front wheel(s) around any tight corners. If you do that, the

cooters rear wheels will follow a wide arc, not cut the corner short, and not bump into or get hung up

on any railing corners.

nWhen driving down a ramp, keep the cooters speed adjustment set to the slowest speed setting to

ensure a safely controlled descent. ee V. Your Legend.

nAvoid sudden stops and starts.

WARNING! Exceeding the weight limit voids your warranty and may result in personal injury and

damage to your Scooter. Pride will not be held responsible for injuries and/or property damage

resulting from failure to observe weight limitations.

II. SAFETY

8Legend

When climbing an incline, try to keep your cooter moving. If you must stop, start up again slowly, and

then accelerate cautiously. When driving down an incline, do so by setting the speed adjustment dial to the

slowest setting and driving in the forward direction only. If your cooter starts to move down the incline

faster than you anticipated or desired, allow it to come to a complete stop by releasing the throttle control

lever. Then push the throttle control lever forward slightly to ensure a safely controlled descent.

In compliance with the Americans with Disabilities Act of 1990, all handicap public access ramps in the

United tates are required to have a maximum slope of five degrees. Therefore, Pride recommends that the

maximum degree of an incline you attempt to safely ascend or descend on your cooter does not exceed

those shown in figures 1 and 2.

These tests were conducted with the Legends seat in the highest position and adjusted backward on the

seat base to its farthest rearward position. Use this information as a guideline. Your Legends ability to

travel up inclines is affected by your weight, your cooters speed, your angle of approach to the incline,

and your cooter setup.

II. SAFETY

WARNING! Any attempt to climb or descend a slope steeper than shown in figures 1 and 2 may

put your Scooter in an unstable position and cause it to tip, resulting in personal injury.

CELEBRITY 4

5˚

6˚

7˚

250 lbs. 300 lbs.

200 lbs.

8˚

150 lbs.

CELEBRITY 3

5˚

6˚

7˚

200-250 lbs. 300 lbs.

150 lbs.

FIGURE 1. MAXIMUM RECOMMENDED INCLINE ANGLE FOR THE 3-WHEEL LEGEND

FIGURE 2. MAXIMUM RECOMMENDED INCLINE ANGLE FOR THE 4-WHEEL LEGEND

WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.

Drive your Scooter straight up the incline. his greatly reduces the possibility of a tip or a fall.

Always exercise extreme caution when negotiating an incline.

WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered

with snow, ice, cut grass, or wet leaves).

WARNING! When on any sort of an incline or decline, never place the Scooter in manual freewheel

mode while seated on it or standing next to it.

9Legend

FIGURE 4. INCREASED STABILITY DRIVING POSITION

FIGURE 3. NORMAL DRIVING POSITION

When you approach an incline, it is best to lean forward. ee figures 3 and 4. This shifts the center of

gravity of you and your Legend toward the front of the cooter for improved stability.

WARNING! Do not exceed the incline guidelines or any other specifications presented in this

manual.

CORNERING INFORMATION

Excessively high cornering speeds can create the possibility of tipping. Factors which affect the possibility

of tipping include, but are not limited to, cornering speed, steering angle (how sharply you are turning),

uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction

(such as passing from a grassy area to a paved area  especially at high speed while turning), and abrupt

directional changes. High cornering speeds are not recommended. If you feel that you may tip over in a

corner, reduce your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your cooter

from tipping.

WARNING! When cornering sharply, reduce your speed. When using your Scooter at higher

speeds, do not corner sharply. his greatly reduces the possibility of a tip or fall. o avoid

personal injury or property damage, always exercise common sense when cornering.

II. SAFETY

10 Legend

BRAKING INFORMATION

Your cooter is equipped with two powerful brake systems:

1. Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the

center/stop position; and

2. Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop, or

when power is removed from the system for any reason.

STATIONARY OBSTACLES (STEPS, CURBS, ETC.)

Proceed with extreme caution when driving near raised surfaces, unprotected ledges and/or drop-offs (curbs,

porches, stairs, etc.).

WARNING! Do not attempt to have your Scooter climb or descend an obstacle that is inordinately

high. Serious personal injury and/or damage may result.

WARNING! Do not attempt to have your Scooter proceed backwards down any step, curb, or other

obstacle. his may cause the Scooter to tip and cause personal injury.

OUT OOR RIVING SURFACES

Your cooter is designed to provide optimum stability under normal driving conditionsdry, level surfaces

composed of concrete, blacktop, or asphalt. However, Pride recognizes that there will be times when you

will encounter other surface types. For this reason, your cooter is designed to perform admirably on

packed soil, grass, and gravel. Feel free to use your cooter safely on lawns and in park areas.

nReduce your cooters speed when driving on uneven terrain and/or soft surfaces.

nAvoid tall grass that can become tangled in the running gear.

nAvoid loosely packed gravel and sand.

nIf you feel unsure about a driving surface, avoid that surface.

II. SAFETY

Altri manuali per Legend

Indice

Altri manuali Pride Mobility Scooter

Pride Mobility

Pride Mobility Celebirty The Ultimate In Style &... Manuale utente

Pride Mobility

Pride Mobility CELEBRITY DELUXE Manuale utente

Pride Mobility

Pride Mobility Sonic Manuale utente

Pride Mobility

Pride Mobility Victotory XL Manuale utente

Pride Mobility

Pride Mobility Legend 3-Wheel Scooter Manuale utente

Pride Mobility

Pride Mobility Go-Go Elite traveller Manuale utente

Pride Mobility

Pride Mobility Legend 3-Wheel Scooter Manuale utente

Pride Mobility

Pride Mobility Hurricane Manuale utente

Pride Mobility

Pride Mobility Legend Manuale utente

Pride Mobility

Pride Mobility Victory Economy Manuale utente

Pride Mobility

Pride Mobility iRIDE S25 Manuale utente

Pride Mobility

Pride Mobility Maxima Scooter SC940 Manuale utente

Pride Mobility

Pride Mobility Sidekick Manuale utente

Pride Mobility

Pride Mobility Apex Sprint Manuale utente

Pride Mobility

Pride Mobility Quantum 614 Manuale utente

Pride Mobility

Pride Mobility CELEBRITY X Manuale utente

Pride Mobility

Pride Mobility CELEBRITY X Manuale utente

Pride Mobility

Pride Mobility Zero Turn 10 Manuale utente

Pride Mobility

Pride Mobility LEGEND CLASSIC XL-8 Manuale utente

Pride Mobility

Pride Mobility Victory ES9 Manuale utente

Pride Mobility

Pride Mobility TRAVEL SCOOTER Series Manuale utente

Pride Mobility

Pride Mobility Colt Series Manuale utente

Pride Mobility

Pride Mobility Rally SC151 Manuale utente

Pride Mobility

Pride Mobility 613 Manuale utente

Manuali Scooter popolari di altre marche

TEKTRO

TEKTRO CHEETAH Manuale utente

Douglas

Douglas Vespa Sprint Guida all'installazione

PLAYTIVE

PLAYTIVE AS-2448 Manuale utente

Ebinger

Ebinger DONKEY XL Manuale utente

Flyer

Flyer Mountain Guida utente

BackCountry eBikes

BackCountry eBikes Storm Manuale utente

equipmed

equipmed FreeRoam II Manuale utente

Yoto

Yoto Lion Manuale utente

WESTHILL BIKES

WESTHILL BIKES LINK Manuale utente

BAnff

BAnff eProdigy series Manuale utente

Winther

Winther 475 Manuale utente

Jetson

Jetson JBZL17 Manuale utente

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuale utente

Carrera

Carrera impel Manuale utente

Afikim

Afikim Superlight SL-3 Manuale utente

CareCo

CareCo ZOOM Manuale utente

Douglas

Douglas Vespa G.S. Manuale utente

Gazelle

Gazelle with BOSCH System Manuale utente
