Princess Jet Stream 600 Manuale utente
EN Instruction manual
Cordless Vacuum Cleaner
01.339600.02.001
1
78
3
4
5 6
2
PARTS DESCRIPTION
11
1. Main body
2. Display
3. Extension tube
4. Motorised brush with
brush bar inside
5. Crevice tool
6. Furniture brush
7. Wall holder
8. Power adapter
9. Air outlet cover / Top cover
10. Hepa E12 filter
11. Battery pack
12. Lower dust cup
13. Inlet air sponge / Cotton filter
14. Cyclone filter cover
15. Quick release foot peddle
15
910 12
13 14
Instruction manual
3
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using your Princess product. By ignoring
the safety instructions Princess cannot be held responsible for the
damage. When using an electrical appliance, basic safety
precautions should always be observed, including the following:
IMPORTANT: This appliance is not intended for use by persons
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children shall not use or
play with this appliance. Close supervision is necessary to keep
appliance and cord out of reach of children during use.
• By ignoring the safety instructions the
manufacturer can not be hold responsible
for the damage.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
• Never move the appliance by pulling the
cord and make sure the cord can not
become entangled.
• This appliance is only to be used for
household purposes and only for the
purpose it is made for.
• To protect yourself against an electric shock,
do not immerse the cord, plug or appliance
in the water or any other liquid.
• The plug must be removed from the socket-
outlet before cleaning or maintaining the
appliance.
• This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not play
with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
SAFETY INSTRUCTIONS
• Risk of suffocation! Keep the packaging
material away from children and animals.
• Keep the device, cord and plug away from
water or other liquids in order to avoid the
risk of an electrical shock. Never touch the
mains plug, cord or device with wet or damp
hands.
EN
Instruction manual
4
• Keep animals, hair, jewellery, loose clothing,
fingers and all other parts of the body away
from the moving parts or openings of the
appliance when it is in operation. They can
be caught in the vacuum cleaner. If
something gets stuck in the vacuum cleaner,
switch the appliance off immediately.
• Take special care to avoid falling when
cleaning stairs.
• Use and store the device only out of the
reach of children. Improper use can result in
injury and electric shock. The power cord
may also not be accessible to children.
PROPER USE
• The appliance must only be used
domestically, it is not suitable for industrial or
commercial use.
• The appliance must not be used to clean:
• People, animals, plants or items of clothing
on the body, always keep the appliance
away from body parts and hair.
• Glowing or burning objects like ash,
charcoal, burning cigarettes, matches or
highly flammable substances.
• Water and all other liquids
• Pointed objects like broken glass or nails.
• Fine dust, construction dust.
• Only use and store the device in enclosed
areas. Do not use the device outdoors, in
rooms with high humidity or on hot surfaces.
• Check the devices and accessories for
damage before each use. Do not use the
appliance if the appliance, the cord, the plug
or the filter are visibly damaged, do not
attempt to repair the appliance yourself or
replace the parts yourself. In case of
damage, contact a qualified repair center or
the helpdesk of the supplier.
• Do not use the device if it malfunctions or
has vacuumed up liquids. Have the device
repaired by a qualified repair center.
• Only use the device if it has been completely
and correctly assembled.
• Do not expose the device to extreme
temperatures, severe changes in
temperature, open flames, direct sunlight,
moisture or wetness.
• Never place heavy objects on the device.
• Empty the dust bin after ever use .The filters
must also be cleaned regularly.
• Allow the dust bin, dust filter and exhaust
filter to dry completely before you reinstall
them in the device.
Instruction manual
5
• Only use original spare parts provided by
the supplier.
• Store the device in a cool, dry area that is
not accessible to children and animals when
not in use.
• Never fill the dust bin with liquids.
BATTERY WARNING
• Rechargeable battery is only to be charged under adult
supervision.
• Do not attempt to open the rechargeable battery or battery pack
as there are no serviceable parts inside.
• Do not disassemble, incinerate or short-circuit the battery or the
battery pack. Only replace the battery with an original battery, the
use of another battery can cause a fire or explosion.
• The battery is a sealed unit and under normal circumstances it
does not constitute a safety hazard. If in any case liquid does
leak out of the battery don't touch it and consult a doctor
immediately in case of inhalation, skin or eye contact.
• Should a battery leak, the device may become damaged. Clean
the battery compartment immediately, avoiding touching your
skin.
• Avoid storing the battery in extremely hot or cold environment. A
device with a hot or cold battery may not work temporarily, even
when the battery is fully charged.
• Do not dispose battery in a fire as it may explode. Battery may
also explode if damaged. Please dispose it according to local
regulation. Do not dispose it as household waste.
BEFORE THE FIRST USE
Installation of the appliance
• Take the appliance and accessories out the box. Remove the
stickers, protective foil or plastic from the device.
• Insert the removable battery into the rear of the vacuum cleaner
unit.
• Your battery will have a nominal charge out of the box. If you find
that it runs out sooner than expected, simply follow the charging
instructions.
• Insert one end of the tube into the floor head and the other end
into the vacuum cleaner.
• The accessories can be attached directly to the device or for
cleaning high positions at the end of the extension tube.
EN
Instruction manual
6
Docking station installation
• Do not install on weak structures such as plaster walls and
compressed wood boards when their thickness is less than
10mm.
• To prevent fire or electric shock due to leakage, please do not
install it on metal walls.
• Hanging area must be flat.
• Wall holder must be placed in ambient temperature between 5°C
and 40°C.
• Ensure the screws will not damage any gas pipes, water pipes or
wires insides of the walls.
• No part of the appliance should touch the ground when placed on
the docking station.
• When installing the docking station, 4mm x 30mm screw is
suggested to be used on wooden surface.
• The 6mm x 32mm Wall plug and 4mm x 30mm screw should be
used on cement surface.
Charge
• Put the main body on a horizontal table.
• Connect the power cord to the power outlet and the charging port
in the handle section of the main body to start charging. The
power indicator flashes blue.
• Charging time: 2.5-3.5 hours; discharging time: 15-25 minutes
• The adapter may become warm during charging, this is normal.
Instruction manual
7
Replacing the battery
• If the battery life becomes shorter and charging time becomes
longer, please visit princesshome.co.uk to purchase an additional
battery.
• Switch off the power supply before removing the battery.
• Do not use and store batteries at temperatures below 5°C or
above 40°C.
• When disposing of this product, remove the battery from the
device.
USE
• To prevent blockage of the air passage large objects like large
paper and packing materials should be removed from the area
before start cleaning.
• Do not use the device when the plug is connected.
• Wait 3 seconds before starting after disconnecting the power
supply.
• Hold the handle and push the switch to turn the vacuum cleaner
on.
• Push the switch button again to stop cleaning.
EN
Instruction manual
8
• The power indicator lights under the battery symbol show how full
the battery is.
• Place on charge when the power indicator flashes.
• This device has 2 speed settings, press the lower part of the
button (MAX) below the display to choose between these 2
settings. The display shows "MAX" at the maximum speed. Press
this button again and the device works at normal speed. The
"MAX" sign will no longer be shown on the display.
• Pressing the upper part of the button (CARPET/FLOOR) below
the display changes the rotation speed of the brush. When the left
icon is shown in the display, the brush will rotate at maximum
speed. When you press this button again, the right icon will be
displayed and the rotation speed will be slower.
• The crevice nozzle can be fitted in order to reach awkward
places.
• There is a quick release foot peddle at the base of the tube. Press
down on this peddle to allow easy removal of the motorised head.
You are now able to attach and use one the various accessories
supplied.
• The whole tube itself can also be removed for closer cleaning.
Again the accessories supplied will simply click into the main
body.
CLEANING AND MAINTENANCE
• Make sure you regularly empty the dust container and clean the
filters.
• The parts must be completely dry before installing.
• Press the eject button, open the dust container and dump the
dust.
Instruction manual
9
• Twist dust container left to remove the dust container, and clean
the dust inside the container and on the bottom cover.
• Twist the dust filter left to remove and clean the dust filter.
• Twist right to remove the top cover, take out HEPA vertically, and
wash with water.
• When the parts are fully dry, install again by reversing the above
steps.
• Never immerse the appliance under water. The appliance and the
various parts are not dishwasher-proof.
• Warning! The appliance contains a driven brush bar. This can
cause various hazards to people, animals and objects.
• Make sure the appliance is switched off before you open the
brush bar lock, remove or clean the brush bar.
• Unlock the brush bar lock - Disassemble the brush bar for
cleaning, remove any debris or hairs caught around the brush bar
and reassemble after all parts are completely dried.
• Never block the outlet openings during vacuuming.
• Never vacuum flammable liquids.
• Please pay attention to sharp objects such as glass to prevent
injury.
• Do not scrub the cotton filter or apply brute force to it.
• Please make sure that the cotton filter has been installed before
assembly.
• Do not continue to use when the cotton filter in the dust cup is
damaged.
EN
Instruction manual
10
TROUBLESHOOTING
Problem Possible reason Solution
Power brush doesn’t
work.
Power brush is
jammed by large
garbage (e.g.
packaging film) or hair
stuck in the brush.
Clear the garbage or
hair that is stuck in the
brush.
Running time
becomes shorter
Battery is aged or
ambient temperature
is too high or too low.
Contact your dealer to
purchase battery.
Use in an appropriate
environment.
Suction power
becomes weak.
Too much garbage in
the dirt container or
Cotton filter is
blocked.
Clean dirt container.
Wash the cotton filter.
Can’t charge Ambient temperature
is too high or too low
Charge in an
appropriate
environment (5~40°C)
Battery leaks The battery is not
used for a long time
Replace battery
ENVIRONMENT
This appliance should not be put into the domestic garbage at
the end of its life, but must be offered at a central point for the
recycling of electric and electronic domestic appliances. This symbol
on the appliance, instruction manual and packaging puts your
attention to this important issue. The materials used in this appliance
can be recycled. By recycling of used domestic appliances you
contribute an important push to the protection of our environment. Ask
your local authorities for information regarding the point of recycling.
The European directive for batteries (2006/66/EC) states that it is not
permitted to throw batteries away with the household waste. They
may contain substances which are harmful to the environment. Empty
batteries can be handed over to a local, public collection point or a
local recycling centre. To avoid overheating as a result of a short
circuit, lithium batteries must be removed from the product and the
poles must be protected using insulation tape or some other means
against short-circuiting.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
Support
princesshome.co.uk
princesshome.co.uk
Questo manuale è adatto per i seguenti modelli
3
Indice
Altri manuali Princess Aspirapolvere
Princess
Princess 332928 Manuale utente
Princess
Princess 01.339600.01.001 Manuale utente
Princess
Princess 332829 Manuale utente
Princess
Princess Air Stream 500 Manuale utente
Princess
Princess 01.338902.01.001 Manuale utente
Princess
Princess 332835 Manuale utente
Princess
Princess Twister Manuale utente
Princess
Princess Pink Flamingo Manuale utente
Princess
Princess Airstream 550 PET Manuale utente
Princess
Princess Turbo Tiger Compact Manuale utente
Princess
Princess 01.339600.01.001 Manuale utente
Princess
Princess 339000 Manuale utente
Princess
Princess Arctic Manuale utente
Princess
Princess TURBO TIGER 332756 Manuale utente
Princess
Princess BLACK PANTHER II Manuale utente
Princess
Princess 332755 Manuale utente
Princess
Princess 01.338902.01.001 Manuale utente
Princess
Princess 332766 Manuale utente
Princess
Princess 01.339650.02.001 Manuale utente
Princess
Princess RED FOX Manuale utente
