pro user RVC3110 Manuale utente
1
WIRELESS BACK-UP CAMERA SYSTEM
KABELLOSES RÜCKFAHR-KAMERA-SYSTEM
SYSTÈME DE CAMERA DE RECUL SANS FIL
DRAADLOOS CAMERASYSTEEM
with 2,4 i ch mo itor
mit 2,4” Mo itor
avec écra 2,4 pouces
met 2,4 i ch mo itor
RVC3110
2
INTRODUCTION
The Pro-User RVC3110 is member of the family of advanced car back-up systems
manufactured by Pro User nternational Ltd.
The Pro-User Wireless Back-up Camera and Monitor, when used as described, will
improve your ability to see behind your car, camper, trailer, or mini-van. We have taken
numerous measures in quality control to ensure that your product arrives in top condition,
and will perform to your satisfaction.
Please carefully read a d follow the followi g safety a d operati g i structio s.
IMPORTANT SAFETY INSTRUCTIONS
Before You I stall
f you are not confident working with 12 volt DC vehicle wiring, removing and reinstalling
interior panels, carpeting, dashboards or other components of your vehicle, contact the
vehicle’s manufacturer, or consider having the camera system professionally installed.
I terfere ce
This device, as well as all other wireless devices, may be subject to interference.
nterference may be caused by cell phones, Bluetooth headsets, Wi-F routers, power
lines and other various electrical equipment, etc.
Repair
The camera system should not be opened. Any attempt at modification or repair by the
user will entail the loss of your guarantee.
PARTS
1. Monitor and mounting Arm 2. Camera with mounting plate
3. Transmitter Box 4. Mounting Accessories 5. Monitor Power Cable
6. Transmitter Box Power Cable
3
INSTALLATION
These i structio s do ot apply to all vehicles. They are o ly mea t as a ge eral
guide due to the umber of differe t makes & models. For vehicle specific
questio s co tact your vehicle’s ma ufacturer.
Camera i stallatio
There are several ways to mount the camera on the back of your car. But the most
convenient is to mount it near the license plate of the car. Supplied is one mounting plate
that can be fixed behind the license plate, and the mounting plate have been installed in
the camera.
The camera is tiltable, camera angle can be adjusted manually on vertical direction.
Make
sure that its field of view and detection are not obstructed.
At some type of cars it is not possible to mount the camera near the license plate. You
may have to find another spot at the back of your car to mount the camera.
1. Remove the rear license plate, and then loosen the license plate bolts/screws.
2. Position the supplied mounting plates (with camera together) behind the license plate
bracket. Secure both license plate bracket and mounting plates with the license plate
bracket bolts/screws.
4
3. Mount the license plate on the license plate bracket.
4. Choose a routing path for the camera’s power cable through the vehicle’s body to the
reverse light circuit. f in doubt, seek professional installation assistance.
5. Some vehicles may have a hole available to pass the wire through, such as where the
license plate light is mounted, or you can drill a hole close to where the power cable
is attached to the camera. Once you have chosen where the cable will enter the
vehicle’s body, remove the camera. If you are able to use an existing opening, skip
the next two steps.
6. Before you drill a hole you MUST CHECK and see WHAT S BEH ND WHERE YOU ARE
DR LL NG. f there are any vehicle components, such as electrical parts or fuel
system components behind where you are drilling, you must take whatever
precaution is necessary not to damage them. Remove the license plate and camera
before drilling.
7. After you have drilled the hole, insert the supplied grommet, then pass the camera
cables through the grommet into the vehicle. You must use the grommet to prevent
the metal edge of the hole from cutting the camera cable.
8. Mount the transmitter box inside the trunk. Connect the camera’s power cable and
the transmitter box power cable to the transmitter box.
9. Next you’ll need to find the vehicle’s reverse lights. Turn the vehicle’s ignition key to
the accessory position, engage the parking brake and put the car in reverse. Look at
the vehicle’s tail lights to see where the reverse lights are located, they are the white
lights. To locate the reverse light’s 12V+ wire it will be necessary to gain access to
the rear of the vehicle’s tail light. For help locating the vehicle’s reverse light circuit
contact your vehicle’s manufacturer for vehicle specific wiring diagrams.
10. Once you have located the reverse light circuit you will have to route the transmitter
box power cable to that location. You must securely fasten the power cable to prevent
it from being caught on any vehicle component such as the trunk hinge. Never route
the cable on the outside of the vehicle!
5
11. The reverse light sockets on
most vehicles have two wires
connected to them. Usually the
negative wire is black and the
positive wire is a colored wire. f
you are uncertain about the
wiring, you can use a 12 volt
multimeter available at most
auto parts stores to determine
which is the positive wire. Follow
the manufacturer’s instructions
for the safe use of the
multimeter.
12. After determining which wire is
the positive and which is the negative, turn off the ignition key, then remove the
battery’s negative cable.
13. Splice the red wire using the supplied in-line wire connectors to the reverse light’s
positive (+) wire. Use a set of slip joint pliers to squeeze the TAP and insure good
connection.
14. Next splice the black wire of the transmitter box power cable to the reverse light’s
negative (-) wire or ground.
15. Replace the reverse light bulb, and then re-install the light socket. Secure all the
wires with cable ties or electrical tape.
16. Re-attach the negative battery cable to the battery.
Mo itor I stallatio
When choosing a location to mount the monitor, make sure the
monitor is in an area that will not obstruct your vision while driving.
1. Before mounting the monitor, clean the mounting surface well.
2. Position the suction mount to the smooth surface which suits
your requirement.
3. Press the suction cap against the smooth surface and press the
lock down to attach and fix the mount to the surface.
4. Snap in the monitor to the suction mount.
5. Adjust the mounting arms to suit your view angle to the monitor and tighten the
screws on the mount to fix the position.
6
6. Route the power cable to the vehicle’s cigarette lighter socket/12V power outlet. The
cable must not interfere with the safe operation of the vehicle.
7. nsert the small 12 Volt DC plug of the power cable into the right side of the monitor.
8. Plug the 12 Volt cigarette lighter plug into the vehicle’s cigarette lighter socket.
To maximize the effectiveness of the suction mount, it is recommended that the
application be performed under the following conditions:
•Surface temperature should be between 21 and 38 degrees Celsius.
•Application below 10 degrees should be avoided.
•Application should not occur in direct sunlight.
Mounting should be protected from exposure to direct sunlight for a period of 24 hours.
NOTE: UNDER EXTREME BR GHT L GHT COND T ONS, THE SCREEN MAGE MAY TAKE A
FEW SECONDS TO STABL ZE. PLEASE WA T UNT L THE MAGE HAS STABL ZED BEFORE
BACK NG UP.
System testi g
1. Reattach the vehicle’s negative battery cable.
2. Turn the ignition key to the accessory position, do not start the vehicle.
3. Engage the parking brake, and then put the shifter in the reverse position.
4. Look at the monitor, if the image does not match your rear view mirror press the
mage Orientation button on the monitor to correct the image.
5. After testing the unit and you are satisfied with the route you have chosen for the
cabling, you must permanently install it.
6. Route all wires behind interior panels or under carpeting so they are hidden. Use
supplied cable ties to neatly gather any excess wire.
7
OPERATION
The monitor will automatically turn on when the vehicle is in reverse gear.
There are 4 control buttons available for users to have their controls:
Power butto
Press the POWER button to supply power to the monitor. When the monitor image is on,
the blue LED will be lit. f there is power to the monitor, but the monitor image is OFF,
the blue LED will blink on and off. When the monitor power is off, no picture can appear
on the screen and the blue LED will be off.
Bright ess butto
There are 10 levels of brightness. To adjust the brightness, press the Brightness Control
button. Pressing the button to increase the brightness at the highest level will return to
the lowest level.
Co trast butto
There are 10 levels of contrast. To adjust the contrast, press the Contrast Control button.
Pressing the button to increase the contrast at the highest level will return to the lowest
level.
Image Orie tatio butto s
Press these buttons to reverse the angle of the camera.
mage orientation buttons
Brightness button
Power button
Contrast button
8
TECHNICAL SPECIFICATIONS
Camera
Operating Voltage 12V DC
Current consumption <150mA
mage sensor CMOS
No. of pixel 640x480
Resolution >330
Optical lens 2,4mm / F2,1
Wireless tra smitter
Transmission frequency 2414MHz
RF transmission distance (open space) >60M
LCD mo itor
Operation Voltage 12V DC
Standby Current <20mA
Operation Current <200mA
LCD display screen size 2,4inch
No. of pixel 480x240
Operation temperature -10 to +45 degree Celsius
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your local authority or
retailer for recycling advice.
WARRANTY
Pro-User warrants this product for a period of 2 years from the date of purchase to the
original purchaser. Warranty is not transferable. Warranty covers defect against
workmanship and materials only. To obtain warranty service, please return the unit to
the place of purchase or authorized Pro-User dealer together with your proof of purchase.
The warranty is void if the product has been damaged or not used as described in this
manual. Warranty is void if a non-authorized repair has been performed. Pro-User makes
no other warranty expressed or implied. Pro-User is only responsible for repair or
replacement (at Pro-Users’ Discretion) of the defective product and is not responsible for
any consequential damage or inconvenience caused by the defect.
9
EINLEITUNG
Der Artikel Pro-User RVC3110 gehört zur Familie der zukunftsweisenden Auto-Rückfahr-
Kamera-Systeme der Firma Pro-User- nternational Ltd.
Die kabellose Pro User Rückfahr-Kamera mit Monitor ermöglicht es hnen bei
ordnungsgemäßer Bedienung, hinter hr Auto, hren Anhänger oder Mini-Van zu sehen.
Es wurden zahlreiche Maßnahmen bei der Qualitätskontrolle ergriffen, um hnen ein Top
Produkt zu hrer Zufriedenheit zu liefern.
Bitte lese Sie die Bedie u gsa leitu g sorgfältig durch u d folge Sie de
Sicherheitshi weise u d der Mo tagea leitu g.
WICHTIGE SICHERHEITSHINWEISE
Vor der Mo tage
Falls Sie sich nicht sicher fühlen, dieses System an die 12V Stromversorgung hres
Fahrzeuges selbstständig zu montieren (bohren von Löchern, abnehmen von
Verkleidungen etc.) nehmen Sie Kontakt zu hrem Autohaus oder zur Kfz-Werkstatt hres
Vertrauens auf. Dort können Sie eine professionelle Montage des Systems in Auftrag
geben.
Störu g
Dieses Kamera-System kann, genau wie andere kabellosen Systeme, bestimmten
Störungen unterliegen. Störungen können verursacht werden durch Handys, Bluetooth,
Headsets, Navigationssysteme und anderen elektrischen Geräten.
Reparatur
Dieses Kamera-System darf nicht geöffnet werden! Bei jeglichem Versuch einer
Reparatur erlischt die Garantie.
ZUBEHÖR
1. Monitor mit Befestigungsarm 2. Kamera mit Befestigungsplatte
3. Sender 4. nstallations- Material 5. 12V Kabel für Monitor
6. Netzkabel für Sender
10
MONTAGE
Diese Bedie u gsa leitu g ist icht für alle Fahrzeuge a zuwe de . Sie ist ei
ge ereller Leitfade für die meiste Fahrzeuge. Bei fahrzeugspezifische Frage
we de Sie sich bitte a Ihre Fahrzeughersteller.
Mo tage der Kamera
Es gibt verschiedene Möglichkeiten, die Kamera an der Rückseite hres Fahrzeuges zu
befestigen. die Gebräuchlichste ist, die Kamera nahe dem Nummernschild zu befestigen.
Sie können die mitgelieferte Montageplatte hinter dem Nummernschild befestigen. Auf
diese Montageplatte können Sie nun die Kamera montieren.
Die Kamera ist vertikal schwenkbar, bitte stellen Sie diese nach den Gegebenheiten ein.
Bei manchen Fahrzeugen ist es leider nicht möglich, die Kamera nahe dem
Nummernschild zu befestigen. Suchen Sie sich eine andere Stelle am Heck hres Autos
und befestigen Sie die Kamera mit den mitgelieferten Schrauben und Muttern.
1. Nehmen Sie das Nummerschild aus der Halterung und lösen Sie dannach die
Schrauben des Nummernschildhalter und nehmen dieses ab..
2. Positionieren Sie die Befestigungsplatte mit der Kamera hinter dem
Nummernschildhalter und befestigen Sie die Befestigungsplatte und den
Nummernschildhalter am Fahrzeug.
Indice
Lingue:
Altri manuali pro user Macchina fotografica digitale
pro user
pro user APR035X2 Manuale utente
pro user
pro user RPC3600 Manuale utente
pro user
pro user DRC4311 Manuale utente
pro user
pro user DRC4310Solar Manuale utente
pro user
pro user DRC4340 Manuale utente
pro user
pro user APR043DC Manuale utente
pro user
pro user APR043 Manuale utente
pro user
pro user DRC4340 Manuale utente
pro user
pro user DRC7010 Manuale utente
pro user
pro user DRC5040 Manuale utente
