PROAIM P-MTCL-STD-BLK Manuale utente

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Mitchell Heavy-duty Camera Tripod Stand

with Spreader (P-MTCL-STD-BLK)

Assembly Manua l

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

Mitchell Heavy-Duty

Camera Tripod

Stand with Spreader Bag Packing

Mitchell Tripod Stand with Spreader Setup

• Take out the Spreader and spread it on oor

and open the legs (as per your requirement)

of spreader with the help of provided knob.

• Now mount the Mitchell Tripod Stand on

Spreader, lock it in place with the rubber

grips

• Remove the uid head (Not Included) by

loosening the Castle ring and then mount it

on top of a Mitchell Tripod Stand.

• Posion the height of the Mitchell tripod

Stand by loosening all three adjustment

knobs, sliding the tripod up to the desired

height and re-ghten the knobs securely.

• Then, spread the Mid-Level Spreader of the

tripod according to your requirements.

Similarly, use all three adjustment boom

knobs aer spread the legs of stand make

sure all knobs ghten properly to secure your

setups.

• Aer mounng the uid head (Not Included)

on the Mitchell Tripod Stand, ghten the

Castle ring from the boom as shown in the

image.

• Remove the Fluid head top plate

(Not Included), by pushing the Push pin of the

uid head then aach the plate to the

boom, matching the camera's threads.

• Aer aaching the Fluid head plate

(Not Included), ghten it properly using a

screwdriver. Then mount the camera

(Not Included) onto the uid head by sliding.

• Now setup is ready to use.

• Secure the Camera with the help of the

locking knob of the uid head.

YOUR PROAIM MITCHELL HEAVY-DUTY CAMERA

TRIPOD STAND WITH SPREADER

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.
