PROAIM P-PTBH-01 Manuale utente

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

PhotoBooth Studio Kit - Camera

Plaorm (P-PTBH-01)

Assembly Manua l

22" Telescoping Arm

Vesa Studio Monitor

Mount for Stand

Arculang Arm

Camera Plaorm

Cold Shoe Mount

(Baby Stud Adapter with

1/4″ 20 female thread on

one side and 3/8″ female

thread

on the other side)

 Mount the monitor mount on the C-stand and

ghten it using the back knob.

Note: Monitor Mount is the best way to mount

your LCD monitor on a C-stand, light-stand, or

other stands with 5/8" baby pins/studs.

 The images show that you can move the

monitor mount up and down up to 90° using

the side knob.

 Set the monitor mount at the desired posion

and secure it properly using the knob. Loosen

the knob to remove the monitor mount.

Mount it on the stand via the 2nd mounng

point.

Note: Monitor Mount has two side mounng

opons to change the direcon of the monitor.

 Change the direcon according to your

requirements and ghten the knob from the

2nd side to secure the monitor mount.

Monitor Mount Setup

 Screw together the LCD and the monitor

mount and secure them properly using an

Allen key, as shown in the image.

Note: The monitor is mounted via four screws.

Once secured, you can lt the monitor to any

viewing posion by the provided knob.

Note: You can mount your at-panel monitor up

to 32" (diagonally measured).

 Loosen the knob of the arculang arm, and

open the arm completely. Align and insert the

arm into the thread on the monitor mount.

Note: The arculang arm is movable and helps

move the camera's direcon.

 Once the arculang arm is inserted, secure it

correctly with the help of the knob, as shown

in the image.

 Mount the camera plaorm on the arculang

arm and secure it using the center knob.

Note: Robust Camera Plaorm allows you to

safely mount a camera to the arculang arm,

as shown in the image.

Arculang Arm Setup

Note: Camera Plaorm has 1/4 "-20 & 3/8 "-16

threaded camera studs and two 5/8" receivers

to mount compable accessories of your choice.

Camera Plaorm Setup

 To change the camera's movement, loosen the

knob of the arculang arm, set the direcon,

and ghten the knob back.

 Loosen the knob of the cold shoe mount, and

extend it completely.

Note: Cold Shoe Mount Baby Stud Adapter has

1/4″ 20 female thread on one side and 3/8″ fe-

male thread on the other side.

 Insert the 22" telescoping arm into the

monitor mount and secure it with the help of

the knob.

Note: You can use the Proaim 20" Telescoping

Arm for everything from overhead lighng to

stand extension.

Note: Twist the knob, and the aluminum arm

telescopes from 11.5" to 20" in length. Each end

has a 5/8" stud topped with 3/8" threads for

receiver or screw-in mounng opons.

 Aer extending the length of the telescoping

form, secure it through the knob.

22” Telescoping Arm Setup

Cold Shoe Mount Setup

 Images showing dierent arm movements.

 Mount the cold shoe mount on the telescopic

arm and secure it with the knob.

 Image showing Monitor Mount, Arculang

Arm, Camera Plaorm, 22" Telescoping Arm &

Cold Shoe Mount assembled adequately.

 Insert the umbrella into the clamp and secure

it correctly with the knob.

Note: This umbrella has been specially designed

for the photobooth setup.

 Image showing umbrella assembled

adequately.

 Slide the ash onto the cold shoe mount and

ghten it with the help of a bolt.

Note: With the Photobooth Kit, you can aach

a camera on the camera plaorm, a display on

the monitor mount, a ash on the cold shoe

mount, and an umbrella o qn the clamp.

 Image showing a praccally complete booth

with a camera, display, ash, and umbrella.

YOUR PROAIM PHOTOBOOTH STUDIO KIT - CAMERA PLATFORM

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
