PROAIM RS274 Manuale utente

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

SnapRig Professional Kit (RS274)

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

1 x Top Plates

2 x 12" 15mm Aluminium Rods

Dovetail Plate

15mm Baseplate with

Quick Release Plate

15mm Road Clamp Adapter

1x L-Type Allen Keys (Sizes: 4mm)

SnapRig Kit Setup

 Loosen the knob of the Fluid head

(Not Included).

 Then remove the quick-release plate by

pushing the push-pin knob on the back of the

uid head (Not Included).

 Properly ghten the knob of the Fluid head

(Not Included).

 Press the push-pin buon of the uid head

and then slide and isert the dovetail plate.

 Now aach the quick-release plate by

aligning it with the dovetail plate, and then

secure the assembly using the bold with a

screw driver.

Baseplate with Quick Release Plate

 Loosen the knob of the baseplate with

quick– release Plate.

 Push the pin axed to the dovetail plate, as

shown in the image.

 Loosen both the knobs of the baseplate.

 Baseplate has now been properly aached to

the dovetail plate.

 Then slide and insert the baseplate and

secure it by ghtening its knob.

 Then insert the Aluminum rod into the

baseplate.

YOUR PROAIM SNAPRIG PROFESSIONAL KIT

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

 Similarly, follow the same procedure for

aaching another Aluminum Rod to

Baseplate.

NOTE: The baseplate mounts securely to an

ARRI-standard dovetail plate, with safety

latches on each end to secure your gear. It

easily aaches to a tripod or uid head via

1/4"-20 and 3/8"-16 mounng threads on the

dovetail plate.

 Now push the press buon of the baseplate

and remove the quick-release plate. Aach

the quick-release plate to the base of the

camera. Mount the FX6 camera

(Not Included) by sliding it over the baseplate.

 The camera mounts onto the quick-release

plate that further mounts the camera onto

the 15mm LWS baseplate.

Compable Camera :

Sony FX6 cinema camera

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
