PROAIM P-BMMT-01 Manuale utente
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Monitor Mount for C-Stands & Light Stands
Payload: 30kg / 65lb (P-BMMT-01)
Assembly Manua l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Monitor Mount for C-Stands & Light Stands
2
Monitor Mount Setup
• Aach the Monitor Mount on the 75mm
Monitor (Not included) by aligning their
threads and inserng screws.
• The Monitor mount is completely aached to
the monitor, as shown in the image.
• Loosen the ratchet knob and mount it on the
baby pin stand.
• Aer mounng the ratchet knob, ghten the
knob to secure the monitor.
• Loosen the ratchet knob of the Monitor
Mount.
• The Monitor mount is completely secure.
• Aer inserng all screws, secure them using
the Allen key.
3
• Again, loosen the ratchet knob and move the
monitor (Not included) at a panning angle to
set it at the desired angle, as shown in the
image.
NOTE: With easy adjustments, the mount pans
270° and lts ±45° facilitang smoot workow.
Both the lng and panning axes secured via
independent ratchet knobs.
YOUR PROAIM MONITOR MOUNT FOR C-STANDS & LIGHT STANDS
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
NOTE: The Smart mount perfectly t
75x75mm and 100x100mm monitors.
• Loosen the ratchet knob and lt the monitor
(Not Included) to the desired angle, as shown
in the image.
4
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
