Operation and Maintenance Manual

Hydraulic Hammers

PRB008

PRB 010

PRB 020

PRB 030

PRB 040(H)

PRB 050

PRB 060

PRB 100

PRB 150

PRB 170

PRB 200

PRB 250

PRB 300

PRB 400

PRB 500

PRB 700

Documents No.: AA099-0018

Revision Date: 2016-12-05

©PRODEM

- 2 -

FOREWORD

WARNING!

It is very important for you to read and understand this manual before operating and to keep

the instructions provided herewith. Never fail to follow the instruction related to safety.

This manual contains instructions and information on safe and correct use of PRODEM hydraulic hammers.

Please read and understand this manual before operation, inspections and maintenance of the hydraulic

hammer.

Keep this manual with your equipment all the time for your quick and easy reference, and read it

regularly.

Do not operate the hydraulic hammer until you have been trained in the use of all operating controls and

understand the hydraulic hammer operation.

Get a replacement manual from PRODEM dealer if you lost it.

If you transfer the hydraulic hammer to the other, do transfer this manual as well.

The figures in this manual are for better understanding and may not correspond exactly to the hydraulic

hammer. For exact shape, refer to the parts list or ask PRODEM.

For the purpose of constant product improvement, some parts of this manual may be changed. If you

found the parts unclear or not corresponding to the hydraulic hammer, call and consult PRODEM dealer

or service center

Important information on safety is described in the safety information chapter of this book. Be

familiarized with the instructions on the safe operation and observe the instructions before and during

operation

Injury, death or damage caused by unauthorized product modifications and operation under unallowed

application will not be responsible by PRODEM. Consult PRODEM for such modifications and

applications.

Use PRODEM genuine parts. PRODEM takes no responsibility for damages caused by use of non-

PRODEM spare parts.

For warranty, we refer you to the warranty conditions provided separately.

We always exert all our efforts for your satisfaction, and promise you quick and constant service.

We thank you for using PRODEM hydraulic hammer and wish you a good luck in every your job,

Jul. 2010

PRODEM

prohibited to use or reproduce its contents in whole or in part without prior written permission.

- 3 -

TABLE OF CONTENTS

FOREWORD............................................................................................................................................................ 2

1. Safety Information................................................................................................................................................ 6

1.1 Basic Safety Information .............................................................................................................................. 7

1.2. Preparation for safe operation..................................................................................................................... 8

1.3. Safety information on safe operating........................................................................................................... 9

1.4. Safety information on maintenance ............................................................................................................. 9

2. Warranty ............................................................................................................................................................ 10

3. Product information............................................................................................................................................ 11

3.1. Configuration of the PRODEM hydraulic hammer ..................................................................................... 11

3.2. Information for ordering and service.......................................................................................................... 12

3.3. Markings and labels .................................................................................................................................. 13

4. Technical specifications...................................................................................................................................... 15

5. Installation.......................................................................................................................................................... 18

5.1. Carrier requirements ................................................................................................................................. 18

5.2. Attaching the mounting adapter................................................................................................................. 19

5.3. Mounting the hydraulic hammer on the carrier .......................................................................................... 19

5.4. Connecting the hydraulic lines of the hammer........................................................................................... 21

5.5. Connection ports of the hammer ............................................................................................................... 22

5.6. Dismounting the hydraulic hammer from the carrier.................................................................................. 23

5.7. Fitting / removing the chisel....................................................................................................................... 23

5.8. Adjusting the pressure-adjusting valve ...................................................................................................... 25

5.9. Adjusting impact rate – 2-speed selection ................................................................................................. 26

5.10. Anti-Blank-Blow (Auto-Stop) function....................................................................................................... 27

5.11. Inspection after installation ...................................................................................................................... 28

6. Operating the hydraulic hammer........................................................................................................................ 29

6.1. Selecting the right chisel ........................................................................................................................... 29

6.2. Correct working methods .......................................................................................................................... 30

7. Maintenance ...................................................................................................................................................... 33

7.1. General Information................................................................................................................................... 33

7.2. Care and maintenance schedule............................................................................................................... 34

7.3. Hydraulic oil............................................................................................................................................... 34

7.4. Grease ...................................................................................................................................................... 36

7.5. Gas............................................................................................................................................................ 37

7.5.1. Checking and charging the gas in the back-head................................................................................... 37

7.5.2. Checking and charging the gas in the accumulator................................................................................ 39

7.6. Chisel, wear bushings and chisel pins....................................................................................................... 40

7.7. Bracket and Adapter..............................................................................................................................- 43 -

7.8. Screw tightening....................................................................................................................................- 43 -

7.9. Replacing the through bolts...................................................................................................................- 45 -

7.10. Checking the bottom of the piston.......................................................................................................- 45 -

- 4 -

7.11. Storage of the hammer ........................................................................................................................- 46 -

8. Troubleshooting .............................................................................................................................................- 47 -

* Specifications and features presented in this document are subject to change without notice.

- 5 -

Blank page

- 6 -

1. Safety Information

This manual describes the correct use of the product and basic safety instructions. Important instructions in

this manual are marked with this symbol . When you see this symbol in this manual or stickers on the

product, you must be alert to the possibility of personal injury or death. Be sure to observe the instruction in

the safety message.

The safety messages in this manual do not describe all the possibilities that could cause personal injury,

death or damage to the product. These safety messages are intended to provide basic instructions for safe

operation and service.

Although this manual does not cover all the possible situations, it is the operator’s responsibility to observe

the safety instructions and regulations.

Remember! Safety is up to you.

Safety Alert Symbol

The Safety Alert Symbol represents that

ATTENTION

is involved.

If you see the mark in this manual or on the products, never fail to read and

observe the instructions for safe operation.

Signal Words

The words “DANGER”, “WARNING”, “CAUTION” and “IMPORTANT” appeared with the above Safety Alert

Symbol indicate degree of risk of hazards or unsafe practices. All four degrees of risk indicate that safety is

involved. Observe precautions indicated whenever you see the Safety Alert Symbol, no matter which

signal word appears next to the “Exclamation Point” symbol.

DANGER!

Indicates imminent hazard of a situation that, if not avoided, is very likely to cause

death or extremely serious injury. It may also be used to alert against product that

may exploded or detonate if handled or treated carelessly.

WARNING!

Indicates potential of a hazardous situation that, if not avoided, could result in serious

injury or death. It may also be used to alert against a highly unsafe practice.

CAUTION!

Indicates potential of a hazardous situation that, if not avoided, could result in minor

or moderate injury. It may also be used to alert against a general unsafe practice.

IMPORTANT!

Indicates potential of damages that, if not avoided, could caused to the product or

shorten the product life.

- 7 -

1.1 Basic Safety Information

WARNING!

The following instructions are those that should ALWAYS be observed in operation of

construction equipment.

Know yourself

Operators and service personnel must wear appropriate safety

equipment, including hearing protection, respirator, hardhat, safety

shoes, eye protection, heavy gloves etc, as required.

Note: The wearing of loose clothing or any accessories such as neckties

scarves, untied shoe laces, rings, wrist watches or long hair could cause

personal injury or death.

Always use the proper tools for inspection or maintenance work, which

must only be carried out after ensuring that the equipment has been

stopped completely, and it is placed suitably in a safe place.

Figure 1

Know your equipment

Before installation or operation of the hammer, the operator and

maintenance personnel must read and understand the safety messages

operation manual and service instructions.

Only the operator who has been trained and qualified to operate the

carrier and hammer should do so. Be skilled and knowledgeable in all

operational and technical aspects of the carrier and hammer.

Figure 2

Know the work site

Before operating the hammer, check the area of work site for any

unusual conditions that could be dangerous,

and prepare the appropriate

warnings for safe work

ing. Be careful, particularly when working in the

vicinity of electric power lines, gas pipes or other buried services.

Pay particular attention to other workers, bystanders and other

machinery that may pass by near to the work site. Immediately stop

operation of the hammer if personnel enter the danger area.

Figure 3

- 8 -

Know the rules

Everybody who operates or maintains the equipment should know the

meaning of the rules and laws in terms of handling the equipment. Use

the hammer in accordance with all regulations regarding construction

practice and public safety.

For emergency use, keep the fire extinguisher and the first-aid case in

the operator’s cab.

Figure 4

1.2. Pre aration for safe o eration

Some prior checks and scheduled maintenance must be performed on installing a new hydraulic hammer.

The hydraulic hammer should only be mounted on a carrier with sufficient load capacity.

In case of using a quick coupler (hitch), determine the total weight including the quick coupler.

Carriers below this weight class will not provide the required degree of stability and could even fall over

during hammer use, causing personnel injury or machine damage. Carriers above this weight class may

apply excessively high mechanical loads to the hammer.

Make sure the hammer is compatible and match in capacity with carrier hydraulic systems.

To protect the operator from injury due to flying rock splinters, the operator’s cab should be equipped

with a protective shield or splinter guard. For information on the cab protector, consult carrier

manufacturer or PRODEM dealer.

Mounting the hydraulic hammer requires the presence of an assistant, who must be instructed by the

carrier driver. The carrier driver and assistant should agree beforehand on clear hand signals.

To avoid equipment damage, follow the carrier maintenance schedule before operating the hammer.

Check the hammer for wear, getting loose, breakage or crack. Do not operate in case any damages or

failure is found.

Recommended carrier weight (in tonne) for hammer models:

Hammer Model Carrier class

(Standard) Hammer Model Carrier class

(Standard)

PRB008

~ 1.

PRB

12 ~ 16

PRB010

0.7 ~

1.2

PRB170

~ 2

PRB

1.0 ~ 2.0

PRB

~ 2

PRB

1.5 ~ 3.0

PRB

20 ~ 26

PRB

0(H)

2.5 ~ 4.5

PRB

26 ~ 32

PRB

4.0 ~ 6.0

PRB

32 ~ 40

PRB

6.0 ~ 8.0

PRB

40 ~ 60

PRB100

8.0 ~ 12

PRB7

0 ~

110

- 9 -

1.3. Safety information on safe o erating

Always operate the hammer from the operator’s seat in the carrier cab, and also close the splinter guard

on the driver’s cab during hammer operations.

The hydraulic hammer must not be used for disallowed applications. Refer to Section “6.2. Correct

working methods” of this manual for instructions on how to handle the hydraulic hammer, and

applications for which the hydraulic hammer is unsuitable and must not be used.

Stop the operation if an abnormal noise or vibration is detected during the operation. Check the carrier

and hammer.

Never use the hammer in or underwater unless compressed air is supplied to the hammer. Refer to

Section “6.2. Correct working methods for details”.

1.4. Safety information on maintenance

Always follow the instructions described in this manual when performing maintenance work on the hammer.

Pay careful attention to all relevant safety regulations. Most accidents occur when the instructions are

not observed.

Maintenance work should be performed with the carrier completely stopped, the stop valves shut off.

The carrier must be on firm and flat ground with all the control levers switched off.

Use only the lifting points provided and sufficiently strong lifting equipment when lifting the hammer.

Do not start maintenance on the hammer until it has cooled because the hammer is heated up during

operation. Some components, for example, chisel (tool), valve, piston or hydraulic connection parts

become very hot.

The hydraulic oil may be very hot and may cause severe scald. Before disconnecting hydraulic lines,

bleed all hydraulic pressure in the lines. And, always relieve tank pressure of the carrier.

Oil spouted out from the crack or small hole on hydraulic system can penetrate the skin and cause

serious injury. Therefore, be sure that all the connections are tight and pipes and hoses are in good

condition. Use a sheet of cardboard or wood to search for suspected oil leaks.

To avoid an explosion and equipment damage, use only pure nitrogen gas (99.8% or over) in the gas

chamber of the back-head and accumulator.

Only the proper tools should be used for maintenance. Use of improper tools may cause personal injury,

or damage to the hammer.

Oily, greasy ground may be very slippery. Collect any oil and grease, and dispose it correctly for safety

and environment.

Keep personnel away from the hammer while servicing the chisel, gas chambers or hydraulic system.

Unauthorized alteration on the hammer may cause the hammer serious troubles or reduce hammer life

and performance. These cases cannot be guaranteed by PRODEM.

- 10 -

2. Warranty

The warranty period for PRODEM hydraulic hammers is provided as below.

Base warranty

PRODEM’s products to be well-made, durable and of good material are warranted for twelve (12)

months from the date of delivery of such new products to the actual and original buyer, but no more than

eighteen (18) months from the date of shipment from PRODEM’s factory for the failure by the reason of

defective material or poor workmanship, except wear and sealing items such as stipulated in the ‘Limited

Warranty’.

Limited warranty

1. Sealing parts

Sealing parts such as seals, O-rings and diaphragms installed in new products are warranted for six (6)

months from the date of delivery to actual and original buyer, but no more than twelve (12) months

from shipping date from PRODEM’s factory.

2. Wear parts

Wear items listed herein below are warranted for three (3) months from the date of delivery to actual

and original buyer, but no more than eighteen (18) months from shipping date from PRODEM’s factory.

chisel, tooth, bush, pin, ring, plug, fitting, fastener, rubber, hose, wearing plate, damper, polyurethane

form, shim

3. Through bolts

Through bolts are warranted for six (6) months from the date of delivery to actual and original buyer,

but no more than eighteen (18) months from shipping date from PRODEM’s factory.

4. Spare parts

Spare parts other than those indicated as wearing parts or consumable parts will be warranted for

three (3) months after the date of delivery to the actual or original buyer, but within eighteen (18)

months from the shipping date from PRODEM’s factory. PRODEM adopt whichever period comes first

out of two conditions.

5. Multi-shift work

PRODEM guarantee the defect and failure caused by PRODEM’s fault under the normal condition of

work which means that customer should comply with maintenance schedule, precautions and 8 hours

(day shift) working a day. In case that the breaker is operated with multi-shift (day and night shift)

working, the warranty period will be cut by half.





Exclusion of warranty

PRODEM does not take responsibility for the results of use not recommended in this manual and

specifically for:

1. Problems caused by incorrect operation or using to non-recommended application

2. Problems caused by improper handling or storage

3. Problems caused by improper maintenance

4. Problems caused by using non-genuine parts

These exclusions apply to damage to the hammer, the carrier, and associated equipment and personnel

injury.

For further information, refer to the “Warranty & service guide line” provided by PRODEM.

PRODEM reserve the right to modify the design or change the specifications without prior notice for the

improvement of performance or quality.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali PRODEM Utensili elettrici

PRODEM

PRODEM PDS Series Manuale di istruzioni

Manuali Utensili elettrici popolari di altre marche

AEG

AEG OMNI-JS Manuale utente

SIP

SIP 01533 Manuale utente

Ribimex

Ribimex PRS499 Manuale utente

3M Fiber Optic Connector Crimp Tool Manuale utente

Ryobi

Ryobi P524 Manuale utente

ROJEK

ROJEK FSN 300A Manuale utente

Kemper

Kemper 1740PRO Manuale utente

WABCO

WABCO OptiTire Manuale utente

EINHELL

EINHELL TE-MS 18/210 Li Manuale utente

Orgapack

Orgapack OR-T 85 Guida rapida

TOUGHCUT

TOUGHCUT Diamond 400 Manuale utente

Yaros

Yaros PB-3603 Manuale utente

Fein

Fein BSS 2.0 E Guida all'installazione

Baileigh Industrial

Baileigh Industrial SS-2725 Manuale utente

Milwaukee

Milwaukee 2674-20 Manuale utente

Fein

Fein BLs 1.6 Manuale utente

Princess

Princess Electric Multi Sharpener Manuale utente

FOREDOM

FOREDOM K.1050 Manuale
