ProLinx homeTro JF-H-40DA Manuale utente
Foldable Treadmill
User Manual
Please put the red safety key on the digital panel before turning on,
otherwise the treadmill will display E07 problem.
English
German
Italian
Spanish
French
02-15
16-29
30-43
44-57
58-71
CONTENTS
FITSHOW Installation Procedure
Scan the QR code on the right
http://tshow.com/qr
Start Using FITSHOW
Jump to the App Store to download and install Open the App, allow permission
based on the system prompt
Login to the App, please use the mobile number or email to register for the new
user
Please ll in the correct email or mobile phone number to make sure you can
retrieve your password and username via them.
Attentions
2US/UK
CATALOG
Product Brief Introduction
Safety Precautions & Warning Instructions
Main Parameters & Conguration List
Installation Instructions
Remote Control Function Description
Fitness Advice & Guidelines
Product Manual
Product Maintenance
Common Troubleshooting Methods
03
04
06
07
09
10
11
13
15
3US/UK
Product Brief Introduction
Product Model: JF-H-40DA
Mobile Phone
Bracket
Non-slip Mat Sidebar
Security Lock
Left Upright Tube
Calorie Distance
LED Digital Display
Acrylic
Time
Speed
Motor Upper Cover Protection
Cap of Upright
Tube
Running Belt Rearfoot
Pad Foot Guard
Forefoot Pad
Motor Lower Cove
Left Handrail Tube
Right Handrail Tube
Dashboard Components
Right Upright Tube
4US/UK
Safety Precautions & Warning Instructions
Please read the instructions carefully before use and pay attention to the following
safety precautions:
Prohibited!
·
The treadmill is suitable to be placed indoors to avoid moisture, do not splash water on the
treadmill, and do not place any foreign objects.
· Before exercising, please wear suitable sportswear and sports shoes. It is strictly forbidden
to exercise on the treadmill without wearing shoes, and it is best to stretch the whole body
before exercise.
·
The power plug must be grounded reliably, and the socket must have a dedicated loop to avoid
sharing it with other electrical equipment.
· Kids should stay away from the machine to avoid accidents.
·
Should avoid long-time overload operation, otherwise, it will cause damage to the motor and
controller, accelerate the aging of the bearing, running belt, and running board. Do the maintenance
of this machine regularly.
·
Reduce indoor dust, maintain a certain indoor humidity, and avoid strong static electricity,
otherwise, it may interfere with the normal operation of the electronic watch and controller.
· Please turn o the power of the treadmill after exercise.
· Please keep indoor air circulation when using the treadmill.
·
Please clip the safety lock cable clip to the garment liner during exercise, so as to stop the
machine safely and quickly in an emergency.
·
If you feel unwell or have abnormalities during use, please stop exercising immediately and
consult a doctor.
·
After using silicone oil, it must be placed out of the reach of children to avoid serious con-
sequences by accidental ingestion.
· Do not use the product in a state where the outside of the product is cracked, damaged, or peeled
off (the internal structure is exposed), or when the welding part is peeled off. In order to avoid
accidents or injuries.
· Do not jump up and down during exercise. Otherwise, you may fall and get injured.
·
Do not use or store the machine in wet places such as outdoors, near bathrooms, and places
exposed to water droplets.
· Do not use or store it in places exposed to direct sunlight, high-temperature places such as around
stoves, or on heating appliances such as electric heating carpets. Otherwise, it may cause electric
leakage or re.
·
Do not use it when the power cord or power plug is damaged or the jack of the socket is loose.
Otherwise, it may cause electric shock, short circuit, or re.
·
Do not damage or forcibly bend or twist the power cord. At the same time, don't place heavy
objects on it, and don't let the line be pinched. So as not to cause re or electric shock.
5US/UK
·
Do not use this machine by two or more people at the same time, and please be careful not to
let people around you get close to the machine during use. Otherwise, it may cause accidents or
injuries due to falling.
·
Do not use it if you cannot express your consciousness or operate it yourself. In order to avoid
accidents or injuries.
· Avoid contact with water and liquids! Do not expose the main body or operating parts to water or
liquids. Otherwise, it may cause electric shock or re.
· People who do not usually exercise should not do vigorous exercise suddenly.
· Do not use this product after eating, feeling tired, just after exercise, or when your physical strength
is abnormal. Otherwise, it may harm your health.
· This product is suitable for family use, not suitable for schools, gymnasiums, and other places with
a large number of people. Otherwise, there is a risk of injury.
· Do not use it while eating or doing other activities.
·
Do not use it after drinking alcohol or when you feel that your behavior has become dull. So as not
to cause an accident or injury.
·
Do not put hard objects in your clothing pockets. Please take off valuables such as watches,
bracelets, mobile phones, and sharp objects such as keys and knives before use to avoid damage to
the items or cause physical injury.
·
Before use, please check whether foreign objects such as needles, trash, or water are attached to
the power plug. So as not to cause electric shock, short circuit, or re.
·
Do not use it with wet hands! Do not unplug or insert the power plug with wet hands. So as not to
cause electric shock or injury.
· Pull out the power plug! When not in use, pull out the power plug from the socket. In order to avoid
the deterioration of the insulation due to dust and moisture, which may lead to electric leakage and
res.
6US/UK
Main Parameters & Conguration List
The main technical parameters
Serial
number Parameter name Description
1 Rated voltage US: 120V/60Hz; UK: 220-240V/50-60Hz
2Motor specication 81 #/4800rpm
3 Control method Acrylic touch type, Meter touch type,
Remote controller, APP
4 Display method LED, APP
5 Product unfolded size 1265*645*115mm (L.*W.*H.)
6 Speed range 0.6-8.7mph(1-14 km/h)
7 Running belt size 1000*400mm (L.*W.)
8 Product N.W./G.W. N.W.: 27kg; G.W.: 32kg
9 Package size 1430*750*150mm (L.*W.*H.)
10 FCC ID 2A48IJF-H-40DF
Packing materials list
Serial
number Name Quantity（PCS）Serial
number Name Quantity（PCS）
1 Main engine 1
2 Accessory package 1
Accessories package list
Serial
number Name Quantity（PCS）Serial
number Name Quantity（PCS）
1 L-type wrench (6#) 1 4 Remote control
(Flatbed style) 1
2 Security lock 1 5 Mobile phone bracket 1
3 Product manual 1 6 Power cord 1
Accessories package list
7US/UK
Installation Instructions
Product Erection Instructions
Take the product out of the box, remove the
outer PE bag, and place it on at ground.
Turn the left and right armrests clockwise
to level.
Grasp the upright pipe with your hands
and rotate it in the direction of the arrow.
After reaching the designated position,
tighten the screw assembly of the joint
in a clockwise direction until the upright
pipe does not shake. (The same method
on the other side)
Insert the power plug into the US: 120V/60Hz; UK: 220-240V/50-60Hz socket and turn the
power switch to the symbol position. After the light is on, you can start using the product.
Take out the mobile phone holder and
safety lock from the accessory bag, align
the phone holder with the rectangular slot
at the back of the instrument and inserted
and fastened. Place the safety lock in the
center of the yellow position.
Security Lock
1
4
3
2
5
8US/UK
The slotted screwdriver
insertion position
Note: Product Fuse Specication 100V-230V/15A, Φ5*20mm
1. As shown in step 1 on the left, pull out the power plug from the power socket. Use a at-blade
screw- driver to remove the safety socket from the power socket.
2. As shown in step 2 on the left, take out the fuse in the direction shown in the gure to replace
it, and insert it again.
The way to replace the fuse when the treadmill fails.
6
6
