Duodos 50, 100, PPS/PVT/PT
Air-driven double diaphragm pump
Assembly and operating instructions
A2740
EN
Original operating instructions (2006/42/EC)Part number 981451 BA DUO 016 06/20 EN
Please carefully read these operating instructions before use. · Do not discard.
The operator shall be liable for any damage caused by installation or operating errors.
The latest version of the operating instructions are available on our homepage.
In order to make it easier to read, this document uses the male
form in grammatical structures but with an implied neutral sense.
The document is always aimed equally at women, men and
gender-neutral persons. We kindly ask readers for their under‐
standing in this simplification of the text.
Please read the supplementary information in its entirety.
Information
This provides important information relating to the
correct operation of the unit or is intended to make
your work easier.
Warning information
Warning information includes detailed descriptions of the haz‐
ardous situation, see
Ä Chapter 2.1 ‘Labelling of Warning Informa‐
tion’ on page 5
.
The following symbols are used to highlight instructions, links, lists,
results and other elements in this document:
Tab. 1: More symbols
Symbol Description
Action, step by step.
⇨Outcome of an action.
Links to elements or sections of these instructions or other applicable documents.
nList without set order.
[Button]
Display element (e.g. indicators).
Operating element (e.g. button, switch).
‘Display/GUI’
Screen elements (e.g. buttons, assignment of function keys).
CODE Presentation of software elements and/or texts.
General non-discriminatory approach
Supplementary information
Supplemental directives
2
Table of contents
1 Function and identification.................................................... 4
1.1 Function........................................................................ 4
1.2 Identification.................................................................. 4
2 Safety and responsibility....................................................... 5
2.1 Labelling of Warning Information.................................. 5
2.2 User qualification.......................................................... 7
2.3 Intended use................................................................. 8
2.4 Duodos general safety notes........................................ 8
3 Transport and storage......................................................... 11
3.1 Transport.................................................................... 11
3.2 Storage....................................................................... 11
4 Assembly............................................................................ 12
4.1 Installation environment.............................................. 12
4.1.1 Securing the double diaphragm pump..................... 14
4.2 Ambient conditions..................................................... 14
4.3 Design of the suction side........................................... 14
4.4 Compressed air supply............................................... 15
5 Checking tightening torque prior to commissioning............ 16
6 Operation of the double diaphragm pump.......................... 17
7 Commissioning................................................................... 18
7.1 Checks prior to commissioning................................... 18
7.2 Priming........................................................................ 19
7.3 Interrupting operation.................................................. 19
8 Maintenance of the double diaphragm pump...................... 20
8.1 Troubleshooting.......................................................... 20
8.2 Maintenance of the diaphragm................................... 23
8.3 Maintenance of the slide rod....................................... 25
8.4 Maintenance of the ball valves................................... 26
9 Disposal of used parts........................................................ 28
10 Technical drawing............................................................... 29
10.1 Exploded drawings and parts lists for Duodos 50..... 30
10.2 Exploded drawings and parts lists for Duodos 100... 32
11 Technical data..................................................................... 34
11.1 Performance curves.................................................. 35
12 Declaration of Conformity................................................... 37
13 Index................................................................................... 38
Table of contents
3
1 Function and identification
1.1 Function
The Duodos is an air-driven double diaphragm pump.
The Duodos is run-dry safe and self-priming.
The pump capacity of the double diaphragm pump can be con‐
trolled by changing the pressure in the air supply. The air control is
designed for oil-free operation. The Duodos is ideally suited for the
transport of liquid chemicals.
The Duodos double diaphragm pump transports liquids up to a
delivery height of 7 m. As the pump capacity depends greatly on
the back pressure, always observe the performance curve.
Check the compatibility of the material when selecting the double
diaphragm pump. Also consider the density, viscosity, solids con‐
tent and temperature of the liquid being pumped.
Permissible values for the medium
Temperature of the medium
–
PP version: 10 ... 80 °C
–
PVDF version: -13 ... 93 °C
Viscosity of the medium: max. 200 mPas
Solids: < 3 mm
1.2 Identification
Type Housing Diaphragm Pump capacity in l/min Order number
50 PPS PP Santoprene®0 ... 50 1103384
50 PVT PVDF Teflon®0 ... 50 1103382
50 PT PP Teflon®0 ... 50 On request
100 PPS PP Santoprene®0 ... 100 1103383
100 PVT PVDF Teflon®0 ... 100 1103380
Function and identification
4
2 Safety and responsibility
2.1 Labelling of Warning Information
These operating instructions provide information on the technical
data and functions of the product. These operating instructions pro‐
vide detailed warning information and are provided as clear step-
by-step instructions.
The warning information and notes are categorised according to
the following scheme. A number of different symbols are used to
denote different situations. The symbols shown here serve only as
examples.
DANGER!
Nature and source of the danger
Consequence: Fatal or very serious injuries.
Measure to be taken to avoid this danger.
Description of hazard
– Denotes an immediate threatening danger. If
the situation is disregarded, it will result in fatal
or very serious injuries.
WARNING!
Nature and source of the danger
Possible consequence: Fatal or very serious inju‐
ries.
Measure to be taken to avoid this danger.
– Denotes a possibly hazardous situation. If the
situation is disregarded, it could result in fatal
or very serious injuries.
CAUTION!
Nature and source of the danger
Possible consequence: Slight or minor injuries.
Material damage.
Measure to be taken to avoid this danger.
– Denotes a possibly hazardous situation. If the
situation is disregarded, it could result in slight
or minor injuries. May also be used as a
warning about material damage.
NOTICE!
Nature and source of the danger
Damage to the product or its surroundings.
Measure to be taken to avoid this danger.
– Denotes a possibly damaging situation. If the
situation is disregarded, the product or an
object in its vicinity could be damaged.
Introduction
Safety and responsibility
5
Type of information
Hints on use and additional information.
Source of the information. Additional measures.
–
Denotes hints on use and other useful informa‐
tion. It does not indicate a hazardous or dam‐
aging situation.
Safety and responsibility
6
2.2 User qualification
WARNING!
Danger of injury with inadequately qualified per‐
sonnel
The operator of the system / equipment is respon‐
sible for ensuring that the qualifications are ful‐
filled.
If inadequately qualified personnel work on the unit
or loiter in the hazard zone of the unit, this could
result in dangers that could cause serious injuries
and material damage.
– All work on the unit should therefore only be
conducted by qualified personnel.
– Unqualified personnel should be kept away
from the hazard zone.
The pertinent accident prevention regulations, as
well as all other generally acknowledged safety
regulations, must be adhered to.
Training Definition
Instructed personnel An instructed person is deemed to be a person who has been instructed and,
if required, trained in the tasks assigned to him and possible dangers that
could result from improper behaviour, as well as having been instructed in the
required protective equipment and protective measures.
Trained user A trained user is a person who fulfils the requirements made of an instructed
person and who has also received additional training specific to the system
from the manufacturer or another authorised distribution partner.
Trained, qualified per‐
sonnel
A trained, qualified employee is deemed to be a person who is able to assess
the tasks assigned to him and recognize possible hazards based on his
training, knowledge and experience, as well as knowledge of pertinent regula‐
tions. A trained, qualified employee must be able to perform the tasks
assigned to him independently with the assistance of drawing documentation
and parts lists. The assessment of a person's technical training can also be
based on several years of work in the relevant field.
Electrical technician An electrical technician is able to complete work on electrical systems and rec‐
ognise and avoid possible dangers independently based on his technical
training and experience as well as knowledge of pertinent standards and regu‐
lations. An electrical technician must be able to perform the tasks assigned to
him independently with the assistance of drawing documentation, parts lists,
terminal and circuit diagrams. The electrical technician must be specifically
trained for the working environment in which the electrical technician is
employed and be conversant with the relevant standards and regulations.
Service The Service department refers to service technicians, who have received
proven training and have been authorised by the manufacturer to work on the
system.
Safety and responsibility
7
2.3 Intended use
CAUTION!
Intended use
Possible consequences if the instructions are not
observed: Minor injuries and material damage
– The pump is intended for liquids transport
– The pump is not intended for the transport of
gaseous or solid media
– Only use the pump in accordance with the
technical data and specifications outlined in the
operating instructions.
– The pump is not designed for use in areas at
risk from explosion
– Only switch the device on if it has been prop‐
erly fastened to the ground or its holding fix‐
ture.
2.4 Duodos general safety notes
WARNING!
Danger from hazardous substances!
Possible consequence: Fatal or very serious inju‐
ries.
Please ensure when handling hazardous sub‐
stances that you have read the latest safety data
sheets provided by the manufacture of the haz‐
ardous substance. The actions required are
described in the safety data sheet. Check the
safety data sheet regularly and replace, if neces‐
sary, as the hazard potential of a substance can be
re-evaluated at any time based on new findings.
The system operator is responsible for ensuring
that these safety data sheets are available and that
they are kept up to date, as well as for producing
an associated hazard assessment for the worksta‐
tions affected.
Safety and responsibility
8
WARNING!
Hazardous media / contamination of persons and
equipment
Possible consequence: Fatal or very serious inju‐
ries. material damage
– Ensure the device is resistant to the media
being conveyed
– Always observe the safety data sheets for the
media to be conveyed. The system operator
must ensure that these safety data sheets are
available and that they are kept up-to-date
– The safety data sheets for the media being
conveyed are always decisive for initiating
counter measures in the event of leakage to
the media being conveyed
– Observe the general restrictions in relation to
viscosity limits, chemical resistance and den‐
sity
WARNING!
Service life of the diaphragm
Possible consequence: Fatal or very serious inju‐
ries
The service life of the diaphragm cannot be pre‐
cisely specified. For this reason, the possibility of
fracture and subsequent leakage of liquids must be
taken into account.
In addition, you must prevent particles from the
defective diaphragm reaching the media being
conveyed. This can be achieved e.g. by filtration, a
hose rupture alarm or other means suitable for the
respective process.
CAUTION!
Compressed air
Before working on the double diaphragm pump,
close the compressed air lines and vent the double
diaphragm pump.
Before undertaking any maintenance and repair
work, close off the compressed air supply, dis‐
charge the compressed air and detach the air
supply line from the double diaphragm pump. The
line to the discharge side of the double diaphragm
pump may be under pressure and must likewise be
vented.
CAUTION!
Hot surface
When conveying hot liquids, the pump can likewise
become hot. Hot surfaces may then be present on
the pump. Bear this in mind and take suitable
measures to reduce any hazards.
Safety and responsibility
9
Maximum pump sound pressure level 91 dB
Depending on the operating conditions, the max‐
imum sound pressure level of the device can reach
88 dB ± 3 dB. Bear this in mind and take suitable
measures to reduce any impact caused by this
sound pressure level. The type and implementa‐
tion of suitable measures depends on the local cir‐
cumstances and is the responsibility of the system
operator.
Check the fastening elements are correctly seated.
Before commissioning the double diaphragm
pump, you must check that all fastening elements
with sealing rings are correctly seated. The seals
may ‘creep’ , so that the fastening elements come
loose over time.
In the event of a diaphragm rupture
In the event of a diaphragm rupture, the pumped
medium can enter the air system of the double dia‐
phragm pump and from there into the atmosphere.
If the pumped medium is a dangerous, harmful or
toxic substance, the air outlet must be routed to a
suitable area where safe disposal is possible.
Operation in the open air and outdoors
–
Take suitable measures to protect the device
from environmental influences when operating
outside such as:
–
UV rays
–
Humidity
–
Frost, etc.
Safety and responsibility
10
Questo manuale è adatto per i seguenti modelli
5
Indice
Altri manuali ProMinent Pompa dell'acqua
ProMinent
ProMinent delta Istruzioni operative
ProMinent
ProMinent DULCO flex Control DFYa Schema elettrico
ProMinent
ProMinent Makro/ 5 HK Manuale utente
ProMinent
ProMinent gamma/ X GMXa Manuale utente
ProMinent
ProMinent EXtronic EXBa Manuale utente
ProMinent
ProMinent Sigma 2 S2Cb Manuale utente
ProMinent
ProMinent gamma/l Manuale
ProMinent
ProMinent Sigma/ 2 Control S2Cb Manuale utente
ProMinent
ProMinent DULCOflex DFDa Manuale utente
ProMinent
ProMinent gamma/ X Istruzioni operative
ProMinent
ProMinent concept plus Manuale utente
ProMinent
ProMinent Dulco flex DFBa Series Manuale utente
ProMinent
ProMinent Makro/ 5 M5Ka Manuale utente
ProMinent
ProMinent Sigma 3 S3Ba Manuale utente
ProMinent
ProMinent DULCO flex DFCa Manuale utente
ProMinent
ProMinent DULCO flex Control - DFXa Manuale utente
ProMinent
ProMinent DULCO Trans 50/1200 PP Manuale utente
ProMinent
ProMinent Sigma 2 S2Ca Manuale utente
ProMinent
ProMinent Sigma2 S2Cb Manuale utente
ProMinent
ProMinent Makro TZ Manuale utente
Manuali Pompa dell'acqua popolari di altre marche
Sykes AmeriPumps
Sykes AmeriPumps GP100M Guida alla risoluzione dei problemi
DUROMAX
DUROMAX XP WX Series Manuale utente
BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 Manuale utente
Franklin Electric
Franklin Electric IPS Manuale utente
Xylem
Xylem e-1532 Series Manuale utente
Milton Roy
Milton Roy PRIMEROYAL Manuale utente
