ProScan PLEDV2488A Manuale utente

LED TV

PLEDV2488A

INSTRUCTION MANUAL

Contents

1-2

3-4

15-17

18-21

22-26

Getting Started

Front View

Rear View

Remote Control Key Functions

Select input source

Picture menu

Picture Settings

Advanced Picture Settings

SOUND MENU

Sound Settings

Equalizer Settings

CHANNEL MENU

Channel List

Favorite List

Channel Setting

Auto Channel Search

PARENTAL CONTROL

V-CHIP

Caution & Important Safety Precautions

Desktop TV Bracket Installation & Assembly

Main Menu Description 9-10

PC Settings

CHANGE PASSWORD

Canada V-CHIP

TV Rating

Contents

Setup Menu

Closed Caption

Menu Language

Digital CC Style

OTHERS MENU

Blue Back

No Signal Power Off

All Reset

Audio Only

Clock

Help

Specifications

DVD 31-32

Caution

The lightening flash with arrowhead symbol, within an equilateral triangle is

intended to alert the user to the presence of un-insulated "dangerous voltage"

within the products enclosure that may be of sufficient magnitude to constitute a

risk of electric shock to the persons.

The exclamation point within an equilateral triangle is intend to alert the user to

the presence of important operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

Cor rect disposal of this Product

W aste Electrical & Electronic Equipment (WEEE)

Your product is designed and manufactured with high quality materials and

components which can be recycled and reused.

This symbol means that electrical and electronic equipment, at their end-of-life,

should be disposed of separately from your household waste.

Please dispose of this equipment at your local community waste

collection/recycling centre.

In the European Union there are separate collection systems for used electrical

and electronic products. Please help us to conserve the environment we live in!

Important Safety Precautions

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.2

Caution:

These servicing instructions are for use by qualified service personnel only. To reduce the risk of

electric shock do not perform any servicing other than that contained in the operating instructions.

unless you are qualified to do so.

19) Do not place any sources of danger on the apparatus (e.g. liquid filled objects, lighted candles).

20) Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as

recommended by the manufacturer.

Desktop TV Bracket Installation & Assembly

,wall mount is not included in this package.

100MM

4xM4

Desktop TV Bracket Installation & Assembly

Note:Instruction manual for the TV stand assembly.

1．Match the position hole in the middle of the stand poles

to the position holes undter the bottom to the TV unit and

connect the stand base with the TV unit, the position holes

locates between the 2 screws of the stand poles.

stand base

2. Fix the stand and the stand poles with 3 pieces of

BM4*10 screws

screws

BM4 *10(3 PCS)

Getting Started

Getting started

Front view

Indicator on(Red) Standby mode

Indicator on(Green) Power on mode

(IR) Infrared Receiver: Receives IR signals from the remote control.

(Power on/Standby) LED Indicator: Press to turn on and off

VOL

SOURCE External signal input selection

item selected.

and confirm the

The functions of the buttons on the are as follows:TV

CH+/-:When watching TV: select channels.

MENU:

1.Press Menu.

2.Press SOURCE to enter.

3.Use CH+/- to shift UP/DOWN.

4.Press SOURCE to confirm,then press VOL+/-to adjust.

5.Press SOURCE to confirm

DVD

Insert disc with shiny

side facing the front

of TV.

Getting Started

VIDEO

R F

COAXIAL

Connect to ANT or cable source

POWER SOCKET

HDMI IN Connect to HDMI of DVD or other equipment

PC AUDIO IN PC audio input

VGA IN VGA signal from computer output

YPBPR Connect to the composite terminal of your DVD/VCR

ANT 75 Ω

EARPHONE

For Upgrade Use.

AV INPUT

Earphone output

DC 12V 4A

COAXIAL Digital Audio Output

(Left Side)

(Back Side)

Name Function Description

Service Port

Remote Control Key Functions

Universal remote code

This is the code for remote control of

PLEDV2488A,if you want to change to a

universal remote control,you can edit

this code into your universal remote control.

(1)Open the battery compartment cover

on the back side

(2)Insert two 1.5V batteries of AAA type

with correct polarity

(3)Close the battery compartment cover

on the back side

Universal Remote Control code:007F

(Universal Remote control is not included)

MENU SOURCE

ENTER

EXIT

SLEEP

P.MOD E S.MODE

DISPLAY

MTS / MP3PROG

ZOOM

D.MENU D.TITLE

ANGLE

EPG

D.DISP

REV FWD PREV

FAV-

GOTO

AUDIO SUBTITLE

FAV FAV+

PROG STEP REPEAT A-B

D.setup

D.Menu D.Title Goto D.Disp

PROG STEP REPEAT A-B

Zoom Angle Subtitle

Audio

D.TITLE:

A-B During the playback,press this button to repeat

playback of a specific section on a disc.

SLEEP: Select amount of time before TV turn

off

automatically.

S.MODE: Press to cycle through the different sound settings

P.MODE: Press to cycle through the different picture settings

D.DISP:

D.MENU:

DVD

Press "-" to enter a program number for multiple program

channel, such as 2-1 etc.

GOTO:

STEP：Play for single frame image

ZOOM In DVD source adjust DVD picture size

MTS / MP3PROG:

Press to select the audio mode,you can select stereo,Mono,

or SAP(second audio program)./When playing mp3 disc,

press MP3 PROG and add the favorite music to playlist,

press PROG two times to see the programmed playlist.

CH +/- : Press to scan through or to select a channel.

V +/-: Press to increase / decrease the sound level.

EPG:

D.Setup:
