Proximus P16-41439 Manuale utente

8 Channel Security Kit

With 8 Night Vision Cameras

P16-41439

User’s Maual

All brand names and trademarks are properties of their

respective owners.

TABLE OF CONTENTS

FCC RADIATION NORM: ................................................................................................................................................. 2

PACKAGE CONTENTS: ................................................................................................................................................... 3

SYSTEM REQUIREMENTS: ............................................................................................................................................ 3

SAFETY INSTRUCTION:.................................................................................................................................................. 4

CHAPTER 1: DVR FEATURES ........................................................................................................................................ 5

CHAPTER 2: LAYOUT...................................................................................................................................................... 6

2.1 FRONT PANEL (PLEASE REFER TO ACTUAL PRODUCT FOR DETAIL) ............................................................................... 6

2.2 REAR PANEL (PLEASE SEE ACTUAL PRODUCT FOR DETAIL) .......................................................................................... 7

2.3 REMOTE CONTROL .................................................................................................................................................... 8

2.4 MOUSE OPERATION................................................................................................................................................... 9

CHAPTER 3: DVR/CAMERA INSTALLATION ............................................................................................................... 10

3.1 CONNECTING THE DVR TO A TV OR MONITOR .......................................................................................................... 10

3.2 CONNECTING THE POWER SUPPLY...........................................................................................................................10

3.3 CONNECTING THE CAMERAS ....................................................................................................................................10

CHAPTER 4: DVR START UP........................................................................................................................................11

4.1 SYSTEM INITIALIZATION............................................................................................................................................11

4.2 MAIN INTERFACE .....................................................................................................................................................11

CHAPTER 5: DVR MENU AND OPTIONS.....................................................................................................................12

5.1 MAIN MENU PREVIEW..............................................................................................................................................13

5.2 MAIN MENU ............................................................................................................................................................14

5.2.1 Playback Functions .......................................................................................................................................14

5.2.2 Record ...........................................................................................................................................................15

5.2.3 Hard Disk Management.................................................................................................................................16

5.2.4 Basic Setups..................................................................................................................................................17

5.2.4.1 Language ................................................................................................................................................................ 17

5.2.4.2 Date/Time................................................................................................................................................................ 17

5.2.4.3 Password ................................................................................................................................................................ 17

5.2.4.4 Display .................................................................................................................................................................... 18

5.2.4.5 Video/Audio............................................................................................................................................................. 18

5.2.5 Advanced Setups ..........................................................................................................................................18

5.2.5.1 Alarm....................................................................................................................................................................... 18

5.2.5.2 Info .......................................................................................................................................................................... 19

5.2.5.3 MD (Motion Detect) ................................................................................................................................................. 19

5.2.5.4 Mobile...................................................................................................................................................................... 19

5.2.5.5 MAINTAIN ............................................................................................................................................................... 20

5.2.5.6 PTZ ......................................................................................................................................................................... 20

5.2.6 Network Setup – Intranet (Internal Access) ..................................................................................................21

User’s Manual

5.2.7 Network Setup – Global Access (Connected Directly to Modem)................................................................. 22

5.2.8 Network Setup – Global Access (Connected through a Router or Firewall)................................................. 24

5.2.9 Port Forwarding............................................................................................................................................. 25

5.2.10 Viewing your DVR over the Internet (UPNP) ..............................................................................................26

5.2.11 Accessing the DVR through Internet Explorer Browser (IE): ......................................................................27

5.2.12 Mobile Phone and Tablet PC Access..........................................................................................................29

5.3 KEYLOCK ................................................................................................................................................................38

5.4 CHANNEL SWITCH ................................................................................................................................................... 38

5.5 VIDEO SEARCH .......................................................................................................................................................38

5.6 PTZ CONTROL ........................................................................................................................................................39

5.6.1 Cruise Setup.................................................................................................................................................. 39

5.7 MUTE .....................................................................................................................................................................39

5.8 MANUAL REC ..........................................................................................................................................................39

5.9 STOP REC ..............................................................................................................................................................40

5.10 ROTATION............................................................................................................................................................. 40

5.11 START CRUISE ......................................................................................................................................................40

5.12 STOP CRUISE........................................................................................................................................................40

5.13 STANDBY ..............................................................................................................................................................40

CHAPTER 6: ACCESSING WITH INTERNET EXPLORER...........................................................................................41

6.1 LOG-IN....................................................................................................................................................................41

6.2 MAIN INTERFACE OF NET-VIEWER ............................................................................................................................ 42

6.2.1 Menu column .................................................................................................................................................42

6.2.1.1 Live ......................................................................................................................................................................... 42

6.2.1.2 Playback.................................................................................................................................................................. 42

6.2.1.3. Setup...................................................................................................................................................................... 43

6.2.2 Play Control ...................................................................................................................................................45

6.2.3 Remote Backup .............................................................................................................................................46

User’s Manual

FCC RADIATION NORM:

FCC

This equipment has been tested and found to comply with limits for Class B digital device pursuant

to Part 15 of Federal Communications Commission (FCC) rules.

FCC Compliance Statement

These limits are designed to provide reasonable protection against frequency interference in

residential installation. This equipment generates, uses, and can radiate radio frequency energy,

and if not installed or used in accordance with the instructions, may cause harmful interference to

radio communication. However, there is no guarantee that interference will not occur in television

reception, which can be determined by turning the equipment off and on. The user is encouraged to

try and correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna

Increase the separation between the equipment and the receiver

Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected to.

CAUTION!

The Federal Communications Commission warns the user that changes or modifications to the unit

not expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

User’s Manual

PACKAGE CONTENTS:

Your new Security Camera and DVR Kit will ship with the following items.

- 8-Channel H.264 DVR with 500GB Pre-Installed Hard Drive

- 8 Day & Night Cameras

- 8 Metal Stands for Cameras

- 8 Mounting Hardware for Cameras

- 8 60ft/18.3m BNC Camera Cables

- Remote Control (with batteries)

- USB Mouse

- 6 ft./1.8m Ethernet Cable

- 6 ft/1.8m BNC to RCA Cable

- DC12V DVR Power Adapter

- 2 DC12V Camera Power Adapter

- User Manual

- Software CD

SYSTEM REQUIREMENTS:

Please be sure the computer that you install the included software with complies with the following

specifications:

- IBM PCs or 100% Compatibles

- Windows®XP, Vista, 7

- Internet Explorer 7 or Newer Web Browser Software

- CD-ROM Drive (for software installation)

User’s Manual

SAFETY INSTRUCTION:

1. Use proper power source.

Do not use this product with a power source that applies more than specified voltage

(100-240V AC).

2. Never insert any metal into the DVR or any openings.

Putting metal into the DVR case can cause danger of electric shock.

3. Do not operate in wet or dusty area.

Avoid places like a damp basement or dusty hallway.

4. Do not expose this product to rain or use near water.

If this product accidentally gets wet, unplug it and contact technical support immediately.

5. Keep product surfaces clean and dry.

To clean the outside case of the DVR, use a lightly dampened cloth (no solvents). Do not

use any cleaning solutions or cleaner.

6. Provide proper ventilation.

Use in well ventilated area to avoid overheating of the device.

7. Do not attempt to remove the top cover.

If any abnormal operation is observed, unplug it immediately and contact technical support.

Warning: You may be subjected to severe electrical shock if you remove the cover of the

DVR.

8. Handle DVR box carefully.

If you accidentally drop your DVR on any hard surface, it may cause a malfunction. If the

DVR doesn’t work properly due to physical damage, contact an authorized dealer for repair

or exchange.

9. Recommended to use with UPS (Uninterruptable Power Supply)

Connecting your DVR and cameras to a UPS allows continue operation even during power

outages. The duration of power out usage time depends on types of UPS used.

10.Make sure there is good air circulation around the unit.

This DVR system uses a hard drive for video storage, which generates heat during

operation. Do not block air holes/vents (bottom, upper, sides and back) of the DVR that

reduce the generated heat while the system is running. Install or place this product in a well

ventilated area.

User’s Manual

CHAPTER 1: DVR FEATURES

Other Features：

•H.264 compression

•Real time recording on 8 channels

•USB Backup to flash drive

•Triplex operation: view, record, playback simultaneously

•Security Certified Hard Drive pre-installed

•Easy control with USB mouse

•Instant viewing using Windows®Mobile™, Symbian®S60 Version 3 & 5, iPhone®,

Blackberry® OS 5, and Android®

•Internet Remote Functions*: View, Search & Playback, Backup and Setup

•Email alerts with JPEG attachment

•Microsoft Windows®XP, Vista, and 7 compatible

User’s Manual

CHAPTER 2: LAYOUT

2.1 Front Panel (Please refer to actual product for detail)

Item Buttons / Indicators Marks Functions

1 Standby Select which single channel to display

2 Hard Disk LED HDD Lights up or blink if HDD error occurs

3 Recording LED REC Lights up or blink when recording

4 Alarm LED ALM Lights up or blink when an alarm is triggered

5 HDD FULL LED FULL Lights up when Hard Disk Drive is full

6 Network Access LED 100M Lights up when DVR is being accessed via Ethernet

7 LINK LED LINK Lights up with Ethernet cable is connected and

working properly

8 Power LED POWER Lights up when powered on

9 Menu/Exit MENU/

EXIT Press to open main menu or to go back to previous

menu screen

10 Channel Select 1-5 Select to display channel 1 thru 5.

Move up

Move Left

OK/PTZ Press to enter selected option or open PTZ menu in

main display screen

Move Right

11 Navigation Buttons

Move Down

12 USB Data Port Connect USB device (Flash Drive, Hard Drive)

13 USB Mouse Port Connect USB Mouse

14 IR Receiver Remote control signal receiver

15 Rewind 6 / Press to display channel 6 or rewind backward when

playing a video clip during playback

16 Stop/Step 7/

Press to display channel 7 or press once to stop

playing, press once more to go to next frame during

play back

17 Play 8 /Press to display channel 8 or press to continue to play

a video clip during playback

18 Slow Motion 9 / Press to display all channels or press to select

reduced speed playing during playback

19 Fast Forward Press to fast forward video clip

2 3 4 5 6 7 8 9

10 11 12

15 16 17 18 19

User’s Manual

2.2 Rear Panel (Please see actual product for detail)

Item Physical

ports

Connection method

1 Power Switch Switch the DVR ON or OFF

2 Power Port Connect to DC 12V power supply

3 Ethernet Port Connect intranet, internet (RJ45 interface)

4 VGA Connect to monitors with VGA input port

5 Audio input 4 Channel (RCA interface for Channel 1~8)

6 Audio Outputs Audio Signal Outputs to amplifier or audio equipments

(RCA interface)

7 Video outputs Connect to monitor inputs ( BNC interface)

8 Video inputs Connect CH1-8 ( BNC interface)

9 PTZ Pan Tilt Zoom Output to PTZ enabled camera

5 6

User’s Manual

2.3 Remote Control

The remote control is the secondary input device for navigating the system’s interface.

To use the remote control:

STANDBY Press to put DVR in Standby mode (all

recording will stop).

LOCK

Press to login DVR if password is set or

activate lock

1-4 Channel Select 1-4

5-9,0 Digit Key 5-9 and 0

ALL Display all Channels – Quad View

Menu Open main menu

PTZ Open PTZ Control menu

EXIT Press to go back to previous or exit menu

UP

Down

OK Select

Left

Right

+ Press to increase volume or option in menus

- Press to increase volume or option in menus

●Record

■Stop

EXTRA (No Function)

Rewind

Play

Forward

Press to select reduced speed playing.

Press once to stop playing, press once more

to go to next frame

Audio Press to enable audio

Mute Enable or disable sound

Indice

Altri manuali Proximus Telecamera di sicurezza

Proximus

Proximus P16-41438 Manuale utente

Manuali Telecamera di sicurezza popolari di altre marche

Okina USA

Okina USA SIR36-870VF650LP Manuale utente

Divio

Divio NDR155PA Manuale utente

Canon

Canon VB-C500D Manuale utente

Easy Access

Easy Access EasyGuard Manuale utente

Vivotek

Vivotek FD9389-EHV-v2 Manuale utente

TUYA

TUYA COSMO W2 Manuale utente

Eusso

Eusso UNC7500-IR Guida all'installazione

urmet domus

urmet domus 1096/204 Manuale utente

VC VC20 series Manuale utente

Axis

Axis Q1614 Manuale utente

ieGeek

ieGeek DD201 Manuale utente

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuale utente

Vicon

Vicon V662-D-1 Istruzioni operative

Grundig

Grundig GCH-K0274P Manuale utente

Lorex

Lorex VANTAGE LBC7032 Manuale utente

4xem

4xem WPT Manuale utente

Samsung

Samsung SCV-3082 Manuale utente

Vitek

Vitek VTC-C544 Manuale utente
