USER MANUAL
www.pslocks.com
ENGLISH - 2
DEUTSCH - 15
TEN
www.pslocks.com | PS GmbH, Melisau 1255, 6863 Egg, Austria
2
TEN Manual
Congratulations on your purchase of a PS lock. PS locks
are developed, designed and produced in Austria by
PS GmbH.
PS locks are easy to install, simple to program and useful
in many indoor applications.
Since 1986, PS GmbH has been recognized as a reliable
supplier and wholesaler of furniture components.
With a brand new owned building, the whole produc-
tion and development moved back to Austria in the
year 2012.
ABOUT PS GMBH
PS GmbH, Melisau 1255, 6863 Egg, Austria | www.pslocks.com
ELECTRONIC LOCKS, MADE IN AUSTRIA
3
ENGLI SH
QUALITY
5-YEAR WARRANTY
PS products are built to the high-
est standard in Austria using
mainly European components
due to this quality and assur-
ance PS can offer a 5 Year
Warranty.
With this 5-year warranty, products will be repaired or
replaced free of charge.
The PS 5-year warranty covers the repair or replacement
of the product once returned to the manufacturer in
Austria. This excludes 3rd party damage and transporta-
tion costs.
PS strives to provide custom-
ers with high-quality products,
excellent customer service as
well as fast lead times.
We furthered that commit-
ment when PS GmbH be-
came ISO 9001 certified on
Sept. 15th, 2015.
With our ISO certified quality management, PS will con-
tinue to do our very best, every day, to ensure you are
confident in our services and get exactly what you
need.
www.pslocks.com | PS GmbH, Melisau 1255, 6863 Egg, Austria
4
TEN Manual
TEN COMBINATION LOCK
THE PACKAGE INCLUDES:
The keypad
The locking device
Lock assembly with ejector/pusher mechanisms
Battery with a life-span of around 5 years
The keypad is fastened directly to the lock under-
neath. The 7 cm long cable enables easy installation.
The built-in lithium battery has a life-span of around
5 years, depending on the frequency of openings. The
battery is checked during the opening process and
when the battery is running low the lock will remain
open, an alarm will go off and the lock cannot be
used again.
The electronic combination lock TEN is suitable for use
in many places such as:
Fitness centers
Clubs
Department stores (safes)
PS GmbH, Melisau 1255, 6863 Egg, Austria | www.pslocks.com
ELECTRONIC LOCKS, MADE IN AUSTRIA
5
ENGLI SH
Battery alert:
The keypad checks the battery power during the
opening process. In case of a low battery the lock will
stay open and the red LED lights for 60 seconds. After
a replacement the last code is still active.
Screws:
The attached screws are designed for 19 mm wood
panels. For any other dimension, please calculate
the length of the screw with:
Thickness of the panel + 24 mm.
TEN GENERAL INSTRUCTIONS
TEN “PUBLIC” INSTRUCTIONS
How to lock:
Choose any open locker, close the door until the
locking device is inside the lock, insert your 4-digit
code and press ✔. The lock will close now.
Open a lock:
Enter the same code again and the lock will open.
Red LED lights:
In case of a red LED flash by setting the code, it is
supposed that one digit has been pressed twice.
After the red flash, the 4-digit code can be used
completely again.
www.pslocks.com | PS GmbH, Melisau 1255, 6863 Egg, Austria
6
TEN Manual
Master code:
(default 000000)
To open the lock and reset the used code please
press ✔for 3 seconds until the green LED flashes.
Enter now 000000 and the lock will open and is avail-
able for a new code.
Change the master codes:
(for example from 000000 to 123456):
The lock has to be unlocked and the locking device
has to be in the lock (door closed).
Press ✔✔ 000000 ✔✔ 123456 ✔✔ 123456
Two green LED signals will confirm the successful
change of the code.
Wrong trial:
After three failed trials the lock will go into a standby
mode for 60 seconds.
Emergency opening with master code:
If you forgot your 4-digit code and the lock is locked,
a caretaker, for example, can open a locker using
the master code. An emergency opening will cause
the previously entered code to be deleted.
PS GmbH, Melisau 1255, 6863 Egg, Austria | www.pslocks.com
ELECTRONIC LOCKS, MADE IN AUSTRIA
7
ENGLI SH
APPLICATIONS
www.pslocks.com | PS GmbH, Melisau 1255, 6863 Egg, Austria
8
TEN Manual
Keypad Door Lock
PS GmbH, Melisau 1255, 6863 Egg, Austria | www.pslocks.com
ELECTRONIC LOCKS, MADE IN AUSTRIA
9
ENGLI SH
www.pslocks.com | PS GmbH, Melisau 1255, 6863 Egg, Austria
10
TEN Manual
INSTALLATION WITH THE “LATCH74”
The locking part "latch74" unites the 3-dimensional ad-
justment with an elegant design.
With a 90° mounting possibility, the "latch74" is
used for swing doors and drawers.
The integrated ejector with a force of 5,4N opens
the door automatically as soon as the lock is un-
locked. Hinges with locking function can cancel
this function.
Thanks to the elegant cover, the mechanism is
protected against dirt and can also be cleaned
easily.
The assembly and the fine adjustment of the lock-
ing part are simple and can be done in a very
short time with standard screwdrivers.
Carbon-reinforced material as well as high flexibil-
ity due to the adjustability in height, depth and to
the side mark the locking part.
Ideally, the locking bolt is located exactly in the
middle after assembly.
The integrated rated breaking point of 35 kg pro-
tects the furniture in case of forced opening.
