PSC QuickScan 1000 Istruzioni operative
P
ROGRAMMING
G
UIDE
H
ANDHELD
L
ASER
S
CANNER
PSC Scanning, Inc.
959 Terry Street
Eugene, Oregon 97402-9120
Telephone: (541) 683-5700
Toll Free: (800) 547-2507
Fax: (541) 686-1702
PSC and the PSC logo are registered trademarks of PSC INC.
Thismanualandtheproceduresdescribedinitarecopyrighted,withallrightsreserved. Under
copyrightlaw,thismanualmaynotbecopiedinwholeorpartwithoutpriorwrittenconsentfrom
PSCScanning,Inc.Thesameproprietaryandcopyrightnoticemustappearonanypermitted
copiesasappearsontheoriginal. Thisexceptiondoesnotpermitcopies tobemadeforothers,
whetherornotsold. Underthelaw,copyingincludestranslatingintoanotherlanguageorformat
includingelectronicmedia.
Disclaimer
Reasonable measures have been taken to ensure that all information contained in this
manual is complete and accurate. However, PSC Scanning, Inc. reserves the right to
changeanyspecificationatanytimewithoutpriornotice.
IBM®is a registered trademark of International Business Machines Corporation, NCR®is a
registeredtrademarkofNCRCorporation,andSNI®isaregistered trademarkofSiemensNixdorf
InformationSystems.Theirinclusioninthismanualisforthecustomer'sinformationandconvenience
only,andconstitutesneitheranendorsementnorarecommendationforthesecompanies'products
orservices.
R44-2018 i
Contents
Introduction
Understandingthe Basics .......................................................................... 1
IntegratingPeripherals WithHostSystems................................................. 1
ChangingInterfaces .................................................................................. 2
CustomizingYourScanner Operation ........................................................ 4
ProgrammingOverview..................................................................................... 5
WhatIsProgramming Mode?.................................................................... 5
How To Program Using Bar Codes............................................................ 5
TheProgramming Session ........................................................................ 6
ScannerResponseWhenIn Programming Mode...................................... 6
IfYou Makea Mistake... ............................................................................. 7
ReturntoFactory Settings ......................................................................... 7
Where To Go From Here........................................................................... 8
InterfaceSelection
IBM IBM 4683/84 • 4693/94 Port 5B Interface Selection ................................... 9
IBM 4683/84 • 4693/94 Port 9A, 9B, 9C, 9E I/F Selection........................ 10
IBM4682/92Port EInterfaceSelection ................................................... 11
WandEmulation
WandEmulation InterfaceSelection ........................................................ 12
RS-232
PSC RS-232InterfaceSelection............................................................. 14
SNI RS-232 Interface Selection .............................................................. 14
RS-232Communication Parameters ....................................................... 14
Hardware Control ................................................................................... 17
Software Control ..................................................................................... 18
IntercharacterDelay................................................................................ 20
KeyboardWedge
PCKeyboard Wedge InterfaceSelection................................................. 21
Connect to a Laptop/No Keyboard Attached........................................... 23
CapsLock ............................................................................................... 24
Country Mode ......................................................................................... 25
Country Mode — continued .................................................................... 26
IntercharacterDelay................................................................................ 27
ii
QuickScan™1000
ProgrammingGuide
OCIAPSCOCIA InterfaceSelection ................................................................. 29
NCR OCIA Eight Bit (short format) Interface Selection ............................ 29
NCR OCIA Nine Bit (long format) Interface Selection .............................. 29
SNIOCIA Interface Selection .................................................................. 29
OCIAOptions .......................................................................................... 30
LabelTransmitFormat Configuration Items
Prefix& Suffix .......................................................................................... 31
ASCII Character Set ............................................................................... 37
Symbologies
SymbologyOptionsOverview .......................................................................... 46
UniversalSymbologySelection ................................................................ 47
SymbologySelection ....................................................................................... 48
UPC/EANOptions ........................................................................................... 51
UPC/EAN Expansion ............................................................................... 52
UPC/EANAdd-Ons ................................................................................. 53
C128andCustom Add-Ons .................................................................... 53
Price/WeightCheckDigit ......................................................................... 54
Code39 Options ............................................................................................. 57
Code128 Options ........................................................................................... 61
Interleaved 2 of 5 ............................................................................................ 62
CheckDigit andVariable LengthLabel Selections .................................... 63
Standard 2 of 5 ............................................................................................... 66
CheckDigit andVariable LengthLabel Selections .................................... 67
Setting Standard 2 of 5 Fixed and Minimum Label Lengths ..................... 68
Codabar Options ............................................................................................. 71
CodabarCheckDigit &Variable Length ................................................... 72
Codabar Start/Stop Character ................................................................ 73
Codabar Fixed Length............................................................................. 74
MSI/PlesseyOptions........................................................................................ 76
MSI/PlesseyCheckDigit .......................................................................... 76
MSI/PlesseyFixedLength ....................................................................... 77
General Features ............................................................................................ 79
GoodReadBeeper Settings.................................................................... 79
ReadVerification...................................................................................... 81
Debug Mode ........................................................................................... 84
LaserTimeout ......................................................................................... 85
DoubleReadTimeout ............................................................................. 86
Appendix A Additional Information
HostProgramming .......................................................................................... 87
CreatingMultiFunction Labels ......................................................................... 87
Need More Information? ................................................................................. 87
Appendix B Sample Bar Codes
SampleBarCodes .......................................................................................... 88
R44-2018 iii
NOTES
iv
QuickScan™1000
ProgrammingGuide
R44-2018 1
GENERAL
INFORMATION
Introduction
This manual contains instructions for changing interfaces and bar codes for customiz-
ingthescanner'soperation. SincetheQuickScan™1000scanner contains software
enhancementsand characteristics that set it apart from other scanners,it is recom-
mended that this guide be used as the sole source of programming labels and
information(exceptforotherQuickScan 1000 product-specificpublications).
The organization of this manual is intended to support a variety of users while
making it quick and easy to find the information you need. Look at the descriptions
that follow to find where to go from here.
Understanding the Basics
If you do not regularly use bar code labels to configure (program) scanners, it will be
very helpful to read the introductory portions of this manual prior to beginning your
programming session. In addition to the information that follows, information of
specific interest to you is titled:
— Integrating Peripherals with Host Systems
— ChangingInterfaces
— Customizing Your Scanner Operation
— ProgrammingOverview
— What is Programming Mode?
— How to Program Using Bar codes
— The Programming Session
— ScannerResponse When in Programming Mode
— If You Make A Mistake
— Where to Go From Here
Integrating Peripherals With Host Systems
It's important to understand that the scanner must contain software and hardware
that supports a specific interface in order to use that interface. The following pages
describeinterfacehardwareandlistsoftwareinterfacegroupsavailableoncurrent
models.
Optimally,you'll wantdetails abouthow yourscanner was configured at thefactory
before attempting to customize any settings. If you don't have that information,
contactyour dealer for factoryconfiguration information.
After determining the changes and/or additions you desire, locate the programming
labels and follow the related instructions in this manual to adjust the scanner. Once
you'vecompletedthesesteps,youcanbeginscanning.
2
QuickScan
™
1000
ProgrammingGuide
Changing Interfaces
Tochangea scanner'sinterface…
HARDWARE
Ifnecessary,replacethescanner'sinterfacecabletomatchthenewhostterminal's
connectionrequirements. Todisconnectthecablefromthe scanner,inserta.050”hex
driver or bent paper clip into the CABLE RELEASE hole, and press down to unlock
thecableconnector. ReferenceFigure1.
NOTE
We recommend that you disconnect power before plugging/
unplugging cables to avoid any possibility of equipment damage.
Figure 1. Disconnecting the Interface Cable
SOFTWARE
1. Verify that your scanner supports the desired interface1. The list below
indicatesinterfaces availableat thetime ofthis writing. Yourscanner comes
equippedfrom thefactory withthe abilityto connectand communicatewith
atleast twomajor interfacetypes, forexample, KeyboardWedge/RS-232
and Keyboard Wedge/Wand Emulation are two common pairings.
Contactyour nearest PSC service depot if you don't knowyour scanner's
interface group, or need to have the scanner altered to change to another I/F
group.
1 Contact your dealer if your desired interface is not listed. Interface group definitions
are subject to change without notice.
R44-2018 3
GENERAL
INFORMATION
RS-232
• PSC RS-232
• SNI RS-232
IBM
• IBM 4683/84, 4693/94 Port 5B
• 4682/92 Port E
• IBM 4683/84, 4693/94 Port 9A, 9B, 9C, 9E
WandEmulation
KeyboardWedge
• I/F Type A — PC/XT w/foreign keyboard
• I/F Type B — AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/
foreignkeyboard
• I/F Type C — PS/2 25 and 30 w/foreign keyboard
• I/F Type D — PC/XT w/US keyboard
• I/F Type E — AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/
USkeyboard
• I/F Type F — PS/2 25 and 30 w/US keyboard
• I/F Type G — IBM 3xxx w/122 keyboard
• I/F Type H — IBM 3xxx w/102 keyboard
• I/F Type I — PS/55 5530T w/104 keyboard
• I/F Type J NEC 9801 keyboard
OCIA
• PSC OCIA
• NCR 8 bit OCIA
• NCR 9 bit OCIA
• SNI OCIA
2. Turn to the appropriate page in this manual and enable the
desired interface or interface sub-type by scanning its program-
ming bar code. These interface/interface sub-type selection bar
codes are located at the beginning of each of these sections of
the manual: IBM, Wand Emulation, RS-232, Keyboard Wedge,
and OCIA. This will enable the software for the new interface
and disable the 'old' interface software. Once enabled, the new
interface becomes the default interface that is active whenever
power is applied to the scanner.
3. Scan a bar code to verify that the scanner communicates
correctly with the host system. Some sample bar codes are
provided on the last pages of this manual. If any changes to the
scanner's factory settings are needed, use the instructions titled,
Customizing Your Scanner Operation.
4
QuickScan
™
1000
ProgrammingGuide
Customizing Your Scanner Operation
Whenenabling a new interface,it may benecessary to modifythe original factory
settings to match your specific host system's communication and symbology
requirements. Check with your system administrator to identify your host system's
specificinterfacerequirementstoensurethattheymatchthenewinterface you've
selected. Also,thescanner's operational features, suchasspeaker volume, can be
customizedto match yourunique requirements.
1. Usethe labels inthis manual to modify the standard configurationto
matchyourspecificinterfacerequirementsoruserpreference.
NOTE
Ensure that your planned modifications are compatible with the
currentinterface. For example,baud rateselections are onlyvalid
in the RS-232 interface. The scanner will sound an error tone (six
rapid beeps) when scanning programming labels for features
invalid to the current interface.
2. Enableany additional symbologies as requiredand exit Programming
Mode.
3. Scana regular barcode label and verify that the scanner and host
communicatecorrectly.
4. Youhavecompleted the factory settings change procedure.
Ifyou experience difficulties, havequestions or requireadditional information, contact
your local distributor using the listings located on the back cover of this guide.
Indice
Altri manuali PSC Scanner
