PL-VCDM0000-005
VCDM
User Manual
1.2
1 of 15
MODEL : VCDM
REV. : 1.2
DATE : 2017. 06. 21
User Manual
PULOON Technology Inc.
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
2 of 15
Revision History
Ver.
DATE
Item
Name
Title
Details
1.0
1.1
1.2
2009.10.30
2010.09.09
2017.06.21
Released
Update Pictures
Removal of cassette
H.J.KIM
Y.J.LEE
Serene Kim
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
3 of 15
Contents
1PREVIEW AND FEATURES..................................................................4
1.1 PREVIEW......................................................... 4
1.2 FEATURES........................................................ 5
2LOADING AND UNLOADING NOTES ..................................................6
2.1 PREPARING NOTES ............................................... 6
2.2 REMOVAL OF CASH CASSETTE AND COLLECTING REJECTED NOTES 8
2.3 NOTE LOADING ................................................... 9
3TROUBLE SHOOTING..........................................................................14
3.1 CLEARING NOTE JAM ............................................. 14
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
4 of 15
1 PREVIEW AND FEATURES
1.1 PREVIEW
VCDM is the cash-dispensing unit and its main function is to dispense the exact number
of banknotes in the cassette by a customer’s request and to transfer to the customer
automatically.
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
5 of 15
1.2 FEATURES
1) To separate notes by friction roller & plate.
2) To prevent from double dispensing case by utlrasonic double detect mechanism
3) To implement mold guides and paths to minimize jam occurrence
4) To maximize convenience in maintenance or clearing by opening guide structure
5) To realize compact and slim size so as to be applied to even small space
6) To speed at a rate of 3.0 notes/sec
7) To have tray for customer easily to take the sprayed notes
8) After power failure, bills on the path are rejected to reject tray when power turns on
again (Auto Reject Function)
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
6 of 15
2 LOADING AND UNLOADING NOTES
2.1 PREPARING NOTES
The number of rejects depends directly on the loading procedure and the quality of the notes.
Store the notes at room temperature for at least eight hours before feeding from cash cassette.
The following procedures are recommended to aid easier note feeding from trays.
Without preparation, feeding problems may occur, such as a higher reject rate or jams in the
cash transport path.
①New, unused notes
Remove the band around each bundle of notes.
Separate the notes from eash other by:
- Striking the bundle hard against the edge of a table or similar object.
- Flipping the rough each bundle of notes in both directions at both ends.
- Using a note counter.
Select notes from the centre of the bundle. The notes in the centre are normally flat, notes in
the ends of the bundle are often cupped.
New notes
(Band wrapped)
Insert direction
②Unacceptable notes
Notes with the following irregularities are liable to cause feeding problems
- Joined by any means
- Having staples or pins
- Sticky surfaces
- Reparied with tape
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
7 of 15
- Torn, with tears exceeding 5mm or with centre edged tears
- Having holes or missing sections
- Crumpled or crisp and crinckled
- Dog-eared, with a folded edge exceeding 5mm
- Limp or moist
- Concave or deformed by prolonged storage
- Having strapping damage
- Combination of new and used notes in the same cassette may cause higher reject rates.
③Used notes
Used Notes must note be limp and should be reasonably clean.
- Remove the band around each bundle of notes.
- Remove foreign objects, e.g. pins, paper clips etc.
- Remove torn or very worn notes.
- Straighten any folded notes.
Dog-eared, strapping damage, center edge tears
Crumped
Concaved (Height: 5 mm or more)
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
8 of 15
2.2 REMOVAL OF CASH CASSETTE AND COLLECTING REJECTED NOTES
The cash cassette can only be removed when the machine is NOT in operation. Please do not
take out the cassette while the machine is running. If the cassette is removed during operation,
it might cause a problem to the dispenser.
①Remove the cash cassette
- Grip the handle and push lock button, and pull cash cassette out.
②Collect rejected notes
- Collect rejected notes from the reject compartment part of the reject tray as shown.
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
9 of 15
2.3 NOTE LOADING
Load only notes of the correct denomination into the VCDM cash cassette.
①Open the cover top and move the pusher plate & the rear pusher
- The pusher plate has to be moved to give space for the notes between the pusher plate and
the feed opening.
DOC NO
MODEL
NAME
REV.
PAGE
PL-VCDM0000-005
VCDM
User Manual
1.2
10 of 15
②Prepare and load the notes
- Slanting pile
: To avoid dispensing problems caused by a slanting pile, put the notes in neat bundles of 100-
200 notes.
: Turn every othe bundle to face the ogher way to make the pile the same height at both sides.
- Bad aligned bundle
: To avoid dispensing problems caused by bad aligning of note bundles, must be aligned the
front side of bundles.
[Warning]
- Notes are sometimes thicker in certain parts. They can also be cupped in the bundle.
- If the notes are turned the same way, the pile will be unequal and the notes will be
difficult to dispense.
