Setting up your PumpSpy Sump Pump Smart Outlet is very
easy and only takes a few minutes.You should setup your outlet at a
convenient location in your home and move it to your sump pump
later. Don’t worry, the Smart Outlet will remember your settings when
you unplug it.
STEP 1: Download and Install the PumpSpy App
from Google Play.
STEP 2: Open the app and create a new PumpSpy Account.
• After entering your info, press Done.
• Press the home button on your Android device.
STEP 3: Plug in the PumpSpy Smart Outlet.
• Plug the Smart Outlet into any AC outlet.
• The LED ring will light up and turn yellow (setup mode).
• If the LED ring is not yellow, gently press and hold the button with the PumpSpy
logo. The unit will turn yellow/enter setup mode after 3 seconds.
STEP 4: Connect to the PumpSpy Smart Outlet
• On your Android device, open Device Settings.
• Select WiFi.
• Connect to the WiFi network named “PumpSpy.”
• Press the home button on your Android device.
STEP 5: Setup the PumpSpy Smart Outlet
• Open the PumpSpy app.
• Select your WiFi network from the list of available networks.
• Enter the password for the selected WiFi network.
• A Success message will be displayed. Press OK.
• The LED ring will turn green. A Green ring means the outlet is connected to
PumpSpy and is ready for use.
• Continue the setup process on the app by entering the
location of the Smart Outlet.
STEP 6: Enter Alert Contacts
• On the PumpSpy App, select Contacts.
• Following the onscreen prompts, enter cell phone numbers and/or email
addresses that should receive PumpSpy alerts.
STEP 7: ConnectYour Sump Pump to the Smart Outlet
(Refer to Owner’s Manual)
STEP 8: Install the High Water Sensor (Refer to Owner’s Manual)
1. 2.
3.
5.
7. 8.
6.
PumpSpy
RED LED
Cannot connect to Internet,
or problem detected with your
sump pump
WATCHING YOUR SUMP PUMP SYSTEM 24/7
4.
SMART OUTLET SETUP INSTRUCTIONS
