ASSEMBLY INSTRUCTIONS VCU
WIRED REMOTE VERSION
Unpack your unit and remove all packing from the blower and motor
assembly.
Remove both housing access doors.
VERY IMPORTANT NOTE! MAKE SURE THE BLOWER WHEEL SPINS
FREELY.
For 1200/2000 "S" version units skip to Step 8.
From the filter section, remove the wire framed pre-filter and carbon filter.
Locate the two HEPA filter holding strips that also act as a tray for the
carbon filter and pre-filter. Remove the two hex nuts and associated screws
on both holding trays and remove the trays from the housing.
Remove the hex head screws that are in the gasket material on the
BOTTOM (motor) section of your unit. The BOTTOM & TOP (filter)
sections are symmetrical, so they can be rotated 360 degrees so the
discharge can be pointed in four different directions to accommodate
any installation configuration. This allows for best directional location
for the TOP section filter access door. MAKE SURE THE DISCHARGE
DIRECTION IS CORRECT FOR YOUR APPLICATION BEFORE
ASSEMBLING. Align the sections as desired. Place the TOP section on
the BOTTOM section, align the holes and tighten the hex head screws.
Insert HEPA filter. BE CAREFUL TO NOT PUNCTURE THE HEPA MEDIA.
The gasket should be toward the motor unit. Center the gasket over the
knife-edges so that it is even on all four sides. Replace the two HEPA
holding trays.
Remove the wrapping from the carbon filter and slide the carbon filter and
pre-filter back into the trays and replace the access door.
IF YOU ARE USING YOUR SYSTEM AS A STAND ALONE, YOU MAY
SKIP TO ELECTRICAL WIRING SECTION.
Please look at the attached "typical installation" drawings. The inlet duct should be
connected to the main return air duct leading to the heating/cooling system, and the
discharge duct should be connected to the point where the return air duct enters the
heating/cooling fan area.
ALWAYS INSTALL THIS SYSTEM IN A BY-PASS CONFIGURATION.
