Connect the power supply plug to the FM modulator DC+12V
input, see the picture (NOTE! The center is positive power source).
Connect the stereo audio plug to the FM modulator stereo audio
signal input, see the picture.
Turning the power switch to "ON" position, and the power
indicator will show red light.
Select the channel switch, CH A is FM88.7MHz, CH B is FM89.1
MHz. (You can either select no interference or select superior
receiving band)
Turning the FM radio's tuner to the same as channel selected of
FM modulator, then can receive audio signal.
3. Using the FM modulator
Make sure that the power switch is turned to "ON" position.
Make sure that the power supply plug is connected to the FM
modulator DC jack.
Make sure you are providing the power supply with the correct
voltage.
No audio signal
Make sure that the power indicator is normal working, if not,
see the "power indicator light not indicate"
Make sure that the stereo audio plug is connected to the FM
modulator audio phone jack.
Change the stereo audio wire.
4. Troubleshooting
Power indicator light not indicate
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved
by the party responsible for compliance could void
the use's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
FCC ID: QTQOOMRU201
FM MODULATOR WIRELESS
2 CH USER'S GUIDE
FM MODULATOR WIRELESS
2CH USER'S GUIDE
MODEL NUMBER: PLMD1
