Precautions for Safety
Failure to follow the instructions below may cause a loss of life or serious physical injury.
1. Please remove any objects that can interrupt ventilation around the product.
2. Please turn o-• the power of the product immediately if it fails to operate properly.
3. Carefully wire the product according to each product’s speci¿cation.
4. Please be careful in preventing chemicals such as thinner, benzene, etc. in contact with the surface of the product.
5. Do not apply excessive force/impact to the product.
6. Failure to follow any of the instructions above may cause malfunction or damage to the product, ¿re, and electric shock.
Precautions for Correct Use
Failure to follow the proper instructions may cause damage to property, the product, or malfunction of the
product that would void the warranty.
1. During wiring or maintenance, please completely turn o-• the power of the product. (Failure to follow this may lead to an electric shock.)
2. Do not install the product in locations that subjects it to excessive dust or water other than the conditions designated by the IP protection
ratings indicated for each product. (Failure to follow these instructions may cause a ¿re to the product, electric shock, physical injury,
malfunction or damage to the product.)
3. Do not alter or repair this product. If maintenance or repair service is required, please contact your local Qlight contact point. (Failure to
follow these instructions may lead to ¿re, electric shock, or product damage.)
4. Please apply the correct voltage to the product. (Failure to follow these instructions may lead to ¿re, electric shock, or product damage.)
5. When the product is applied to a condition that may impact lives or property, please make sure to have a double safety device. (Failure to
follow this may cause damage to property, ¿re, electric shock and loss of life.)
Thank you for purchasing Qlight’s products. Please read this user manual carefully
prior to installation and operation to ensure safe and correct use.
Warning Light Bars for Emergency Vehicle Set
QLV-SET
• Protection rating : IP56(QLV only)
• Ambient operating temperature : -30°C to +50°C
QLV-1150 - 12 - B/R - SAMP - HORN
[Model number] [Voltage] [Color]] [Ampli¿er] [Horn]
| | | | |
• QLV-1250
• QLV-1150
• QLV-885
• 12- DC12V
• B/R -
Blue
-
Red
• R/R -
Red
-
Red
• A/A -
Amber
-
Amber
• G/G -
Green
-
Green
• SAMP
- SAMP-100
included
• HORN
- SM-100ND
included
Model
number
LED Module
number
VoltageCurrent Volume Certi¿cateWeight Color
QLV-1250-SET
24EA
DC12V
20A
Max.
135dB
20.31kg
B(Blue-Red)
R(Red-Red)
A(Amber-Amber)
G(Green-Green)
QLV-1150-SET
22EA
19A
19.42kg
QLV-885-SET
18EA
17A
16.77kg
Please scan the QR code for more
detailed product information.
www.qlight.com
Product Specications
Ordering Specications
