QUICK START GUIDE

INTELLIGENT ETHERNET ADAPTERS INSTALLATION

Purchasers of OEM products should consult with the OEM for support.

Please feel free to contact your QLogic approved reseller or QLogic

Technical Support at any phase of integration for assistance. QLogic

Technical Support can be reached by the following methods:

Web http://support.qlogic.com

E-mail [email protected]

The QLogic knowledge database contains troubleshooting information

for the QLogic adapters. Access the data base from the QLogic Support

Web page, http://support.qlogic.com. Use the Support Center search

engine to look for specific troubleshooting information.

Quick Start Guide

Overview

This document provides general information about QLogic’s 1-Gigabit Quad Port and 10-Gigabit Dual Port Ethernet

adapter products.

Package Contents

Depending on the product ordered, this package contains one of the following boards:

❑QLE3044-RJ-CK Quad Port 1GbE adapter (copper RJ45)

❑QLE3142-CU-CK Dual Port SFP+ 10GbE adapter (twinax)

❑QLE3142-SR-CK Dual Port SFP+ 10GbE adapter (multi-mode fiber)

❑QLE3142-LR-CK Dual Port SFP+ 10GbE adapter (single-mode fiber)

Handling and Safety

The adapter card contains sensitive electronic components that are susceptible to Electro-Static Discharge (ESD) and

must be handled with care. The following steps can be taken to ensure proper operation of the product:

❑When transporting the product, it should be kept in an anti-static bag to protect against ESD.

❑When inserting or removing the product from the system chassis, the operator should be properly grounded.

❑Devices on the product can generate high temperatures during normal operation. Use caution when handling

the product.

❑For the QLE3142-SR-CK and QLE3142-LR-CK optical products:

❑Use the dust plugs (provided) to keep the high speed optical fiber connectors free from dust and debris

when not in use.

❑Do not use excessive force when connecting or disconnecting the fiber optic cable.

❑When routing the fiber optic cable in the system, never exceed a minimum bend radius of 3”.

WARNING!! Note that the light emitted by the optical laser is outside the visible spectrum. Looking directly into either

the optical cable or the optical port can cause serious eye damage.

Product and Software Installation

For information on installation and configuration, visit

http://driverdownloads.qlogic.com/QLogicDriverDownloads_UI/default.aspx to download the following:

❑Software

❑Driver

❑Firmware

❑Diagnostics and Utilities

❑Documentation

❑Release Notes

❑Readme

❑User’s Guide

Getting Help

Thedocumentationlistintheprevioussection provides all of the informationrequiredtosuccessfullyinstallandconfigure

the QLogic Ethernet adapter. If further assistance is required, visit http://support.qlogic.com for product support.

Cable Specifications (Cable not included)

Table 1. QLE3142-SR-CK/QLE3142-LR-CK

Parameter

QLE3142-SR-CK QLE3142-LR-CK

Unit50m62.5m 9m10m

Wavelength 850 850 1310 1310 nm

Bandwidth (min) 400 160 N/A N/A MHz

Operating Range (max) 300 33 10K 10K m

Table 2. QLE3044-RJ-CK/QLE3142-CU-CK

Product Cable Network Type Cable Length

QLE3044-RJ-CK Cat5 LAN 100 meters

QLE3142-CU-CK Copper direct attach twinax LAN 7 meters (10 meters on

qualified cables)

Optical Fiber Specifications

Table 3. QLE3142-SR-CK Multi-Mode Fiber (MMF) Type

MMF Optical Fiber Core

Diameter Wavelength (nm) Bandwidth (MHz) Distance (meters)

50m850 400 66

850 500 82

850 2000 300

1310 400 100

1310 500 220

62.5m850 160 26

850 200 33

1310 500 220

Certifications

The QLogic Ethernet adapter conforms to the following agency specifications:

❑FCC (US)

❑ICES (Canada)

❑CISPR 22/EN55022 CE (European Union)

❑VCCI (Japan)

❑BSMI (Taiwan)

❑KCC (Korea)

❑C-Tick (Australia/New Zealand)

❑QLogic Ethernet adapter products are RoHS compliant (Lead materials banned by the RoHS directive are either below applicable

thresholds as proposed by the EU, or a pending exemption applies.)

Warranty

Please check the QLogic Web site at http://www.qlogic.com/Support/Pages/warranty.aspx for warranty details.

Laser Safety

FDA Notice

This product complies with DHHS Rules 21CFR Chapter I, Subchapter J. This product has been designed and manufactured according to

IEC60825-1 on the safety label of laser product.

Class 1 Laser Product Caution—Class 1 laser radiation when open

Appareil laser de classe 1 Do not view directly with optical instruments

Produkt der Laser Klasse 1

Luokan 1 Laserlaite Attention—Radiation laser de classe 1

Ne pas regarder directement avec des instruments optiques

Vorsicht—Laserstrahlung der Klasse 1 bei geöffneter Abdeckung

Direktes Ansehen mit optischen Instrumenten vermeiden

Varoitus—Luokan 1 lasersäteilyä, kun laite on auki

Älä katso suoraan laitteeseen käyttämällä optisia instrumenttej

CLASS I LASER

QLogic Corporation. All other brands and product names are trademarks or registered trademarks of their respective

owners. Information supplied by QLogic is believed to be accurate and reliable. QLogic Corporation assumes no

responsibility for any errors in this brochure. QLogic Corporation reserves the right, without notice, to makes changes

in product design or specifications.

*NE0154501-00 B*

NE0154501-00 B
