QNAP Turbo NAS

TS-1685 Hardware User Manual

Thank you for choosing QNAP products! This user manual provides description of the

hardware of the Turbo NAS and relevant guideline of certain functions. Please read carefully

and strictly adhere to the instructions of the manual.

This user manual is applicable to the following Turbo NAS models:

TS-1685

NOTE

•The “Turbo NAS” is hereafter referred to as “NAS”.

•The product you purchased may not support certain functions dedicated to specific

models.

•All features, functionality, and other product specifications are subject to change

without prior notice or obligation.

•Information presented is subject to change without notice.

•No part of this publication may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, mechanical, electronic, photocopying,

recording, or otherwise, without prior written permission of QNAP Systems, Inc.

•QNAP and the QNAP logo are registered trademarks of QNAP Systems, Inc. Other

products and company names mentioned herein may be the trademarks of their

respective companies.

DISCLAIMER

In no event shall QNAP Systems, Inc. (QNAP) liability exceed the price paid for the product

from direct, indirect, special, incidental, or consequential damages resulting from the use

of the product, its accompanying software, or its documentation. QNAP makes no warranty

or representation, expressed, implied, or statutory, with respect to its products or the

contents or use of this documentation and all accompanying software, and specifically

disclaims its quality, performance, merchantability, or fitness for any particular purpose.

QNAP reserves the right to revise or update its products, software, or documentation

without obligation to notify any individual or entity.

Note:

Back up your system periodically to avoid any potential data loss. QNAP disclaims any

responsibility of all sorts of data loss or recovery.

Should you return any components of the NAS package for refund or maintenance,

make sure they are carefully packed for shipping. Any form of damages due to

improper packaging will not be compensated.

Regulatory Notice

FCC Class B Notice

The TS-1685 complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

•Consult the dealer or an experienced radio/television technician for help.

Modifications: Any modifications made to this device that are not approved by QNAP

Systems, Inc. may void the authority granted to the user by the FCC to operate this

equipment.

CE NOTICE

The TS-1685 series complies with CE compliance classes B.

RESTRICTED ACCESS LOCATION

This equipment must be only located where both of the following apply:

Only authorized and knowledgeable personnel can access the equipment

Access to the equipment is restricted through the use of lock and key or other means of

security and this access is controlled by those in charge of the location.

Symbols in this document

Warning

This icon indicates the instructions must be strictly followed. Failure

to do so could result in injury to human body or death.

Caution

This icon indicates the action may lead to disk clearance or loss OR

failure to follow the instructions could result in data damage, disk

damage, or product damage.

Table of Contents

Table of Contents ...............................................................................................7

Safety Warnings.................................................................................................8

Chapter 1. Product Overview...........................................................................9

1.1 HARDWARE SPECIFICATION.............................................................................9

1.2 ORDERING INFORMATION ............................................................................. 10

1.3 COMPONENTS........................................................................................... 12

Chapter 2. Basic Operations ..........................................................................15

2.1 POWER BUTTON......................................................................................... 15

2.2 RESET BUTTON.......................................................................................... 15

2.3 USB ONE TOUCH COPY ............................................................................... 16

2.4 LED...................................................................................................... 17

2.5 BEEP ALARM ............................................................................................ 19

Chapter 3. Upgrade Memory on QNAP Turbo NAS (RAM Module Installation)20

Chapter 4. Expansion Card Installation .........................................................25

Chapter 5. Install and Hot-swap Drives.........................................................29

5.1 DRIVE BAY NUMBERING.................................................................................... 29

5.2 INSTALLING DRIVES ........................................................................................ 29

5.3 RAID RECOVERY -HOT-SWAPPING DRIVES ............................................................ 34

5.4 RAID RECOVERY -ACCIDENTAL REMOVAL OF A HEALTHY DRIVE .................................... 35

Chapter 6. Using the LCD Panel .....................................................................37

Technical Support ............................................................................................42

GNU GENERAL PUBLIC LICENSE .......................................................................43

Safety Warnings

1. The NAS can operate normally in temperatures of 0ºC - 40ºC (32ºF - 104ºF) and

relative humidity of 5% - 95%. Please make sure the environment is well-ventilated.

2. The power cord and devices connected to the NAS must provide correct supply voltage

(100W, 90–264V).

3. Do not place the NAS in direct sunlight or near chemicals. Make sure the temperature

and humidity of the environment are in optimized level.

4. Unplug the power cord and all connected cables before cleaning. Wipe the NAS with a

dry towel. Do not use chemical or aerosol to clean the NAS.

5. Do not place any objects on the NAS for the server’s normal operation and to avoid

overheat.

6. Use the flat head screws in the product package to lock the hard disks in the NAS when

installing hard disks for proper operation.

7. Do not place the NAS near any liquid.

8. Do not place the NAS on any uneven surface to avoid falling off and damage.

9. Make sure the voltage is correct in the location where the NAS is installed. Contact the

distributor or the local power supply company for the information.

10. Do not place any object on the power cord.

11. Do not attempt to repair the NAS in any occasions. Improper disassembly of the

product may expose the users to electric shock or other risks. For any enquiries,

please contact the distributor.

12. The NAS should only be installed in the server room and maintained by the authorized

server manager or IT administrator. The server room is locked by key or keycard

access and only certified staff is allowed to enter the server room.

Warning:

Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the manufacturer. Dispose of used batteries

according to the manufacturer’s instructions.

Do NOT touch the fan inside the system to avoid serious injuries.

Chapter 1. Product Overview

Caution: Any unauthorized modifications performed on QNAP products will result in

the warranty being voided. QNAP is not responsible for any form of damage or loss of data

caused by such modifications. Unauthorized modifications include, but are not limited to,

changes made to the default system firmware, installation of unofficial third party

applications, and changes to the hardware performed by unauthorized technicians.

1.1 Hardware Specification

TS-1685

CPU Intel® Xeon® Processor D-1521 quad-core 2.4 GHz

Intel® Xeon® Processor D-1531 6-core 2.2 GHz

System memory

16GB non-ECC RAM (8GB UDIMM*2)

32GB non-ECC RAM (16GB UDIMM*2)

64GB non-ECC RAM (16GB UDIMM*4)

64GB ECC RAM (16GB RDIMM*4)

128GB ECC RAM (32GB RDIMM*4)

Flash memory 512 MB (USB DOM)

CPU replaceable No

Memory replaceable Yes

Memory slots 4 x Long-DIMM slots

3.5" drive slots 12 x SATA 6 Gb/s (3.5-inch HDD, 2.5-inch HDD& SSD)

2.5" drive slots 4 x SATA 6 Gb/s (2.5-inch SSD)

M.2 SSD slots 6 x M.2 2242/2260/2280/22110 SATA 6 Gb/s

PCIe slots

Slot 1: PCIe Gen.3 x8

Slot 2: PCIe Gen.2 x4

Slot 3: PCIe Gen.3 x8

10 GbE LAN ports 2 x 10GBASE-T

GbE LAN ports 4

LED panel Mono-LCD display with backlight

Enter and Select buttons for configuration

USB ports Front: 1 x USB 3.0 port

Rear: 2 x USB 3.0 port

Audio outputs 1 x built-in speaker

1 x 3.5mm Line-out jack

Note: Only one of the

above audio output ports can work at a time.

If a speaker is connected, the sound will output through the

speaker.

LED indicators Status, USB One Touch Copy, HDD 1-12, SSD 1-4, M.2 SSD 1-6

Buttons Power, USB One Touch Copy, Reset

IR sensor QNAP RM-IR004 remote control (MCE compatible)

Security Kensington security slot

Form factor Tower

Power Supply 100-240V~, 3-1.5A, 60-50Hz, 250W PSU

100-240V~, 3-1.5A, 60-50Hz, 550W PSU

System fans 3 x 9.2cm system fan (12V DC)

CPU fans 2 x 9cm fan

1.2 Ordering Information

NAS SKUs

TS-1685-D1521-8G Intel® Xeon® Processor D-1521, 8GB non-ECC RAM

(4GB UDIMM*2), 250W PSU

TS-1685-D1521-16G Intel® Xeon® Processor D-1521, 16GB non-ECC RAM

(8GB UDIMM*2), 250W PSU

TS-1685-D1521-16G-550W Intel® Xeon® Processor D-1521, 16GB non-ECC RAM

(8GB UDIMM*2), 550W PSU

TS-1685-D1521-32G Intel® Xeon® Processor D-1521, 32GB non-ECC RAM

(16GB UDIMM*2), 250W PSU

TS-1685-D1521-32G-550W Intel® Xeon® Processor D-1521, 32GB non-ECC RAM

(16GB UDIMM*2), 550W PSU

TS-1685-D1531-16G Intel® Xeon® Processor D-1531, 16GB non-ECC RAM

(8GB UDIMM*2), 250W PSU

TS-1685-D1531-32G Intel® Xeon® Processor D-1531, 32GB non-ECC RAM

(16GB UDIMM*2), 250W PSU

TS-1685-D1531-32G-550W Intel® Xeon® Processor D-1531, 32GB non-ECC RAM

(16GB UDIMM*2), 550W PSU

TS-1685-D1531-64G Intel® Xeon® Processor D-1531, 64GB non-ECC RAM

(16GB UDIMM*4), 250W PSU

TS-1685-D1531-64GR Intel® Xeon® Processor D-1531, 64GB ECC RAM (16GB

RDIMM*4), 250W PSU

TS-1685-D1531-128GR Intel® Xeon® Processor D-

1531, 128GB ECC RAM (32GB
