IN-600/700 Mailing System
Series LAN Conversion
2/5
© 2022 Quadient, Inc.
Contents
Introduction ................................................................................................................................................3
Instructions: ..............................................................................................................................................3
Manual Configuration of LAN ....................................................................................................................4
Instructions: ..............................................................................................................................................4
LAN with Proxy Configuration of LAN........................................................................................................5
With auto IP address (DHCP) ON ..............................................................................................................5
With manual IP address (DHCP) OFF ........................................................................................................5
3/5
© 2022 Quadient, Inc.
Introduction
The purpose of this document is to provide instruction on converting an IN-600/700 series
Mailing System that currently uses a Modem device connectivity to a LAN (Local Area Network).
To complete this process, you will need a LAN cable
Instructions:
1. Power off the Base
2. Unplug the Modem device
3. Plug the LAN cable into the LAN port
4. Power up the Base
5. Select the Menu button
6. Select Supervisor
7. Enter PIN Code, 09430
8. Select Communication Settings
9. Select Internet (LAN)
10. Select Internet LAN Settings
11. Select Auto by pressing OK twice
12. Select the OK at Half
13. Press the OK button when the MAC address is displayed
14. Press OK at Proxy OFF
15. Perform a Power Cycle to the Base
16. Select the Menu button
17. Select Online Services
18. Select Generic Call
19. Select the OK button
4/5
© 2022 Quadient, Inc.
Manual Configuration of LAN
If your Mailing System cannot connect through your LAN using the default LAN connection
settings, it may be necessary to manually configure the settings. Contact your network
administrator for the following required information:
- Machine IP Address
- Subnet Mask
- Default Gateway IP Address
- Preferred DNS IP Address
- Alternate DNS IP Address
- Proxy URL
- Proxy Port Number
- Proxy Login Name
- Proxy Login Password
Instructions:
1. Power up the Base
2. Select the Menu button
3. Select Supervisor
4. Enter PIN Code, 09430
5. Select Communication Settings
6. Select the Type of Connection
7. Select Internet LAN Settings
8. Select Manual and press OK
9. Enter the IP address and press OK
10. Enter the Subnet Mask and press OK
11. Enter the Gateway and press OK
12. Enter the 1st DNS and press OK
13. Enter the 2nd DNS and press OK
14. Press OK when the MAC address is displayed
15. Press OK at Proxy OFF
16. Depress Power Button twice, one second in-between
5/5
© 2022 Quadient, Inc.
LAN with Proxy Configuration of LAN
If your network requires or Proxy to connect the following instructions will be needed
With auto IP address (DHCP) ON
The starting point is on page 3 step 14
Select Proxy ON and Press OK
1. Enter Proxy URL and press OK
2. Enter Proxy Port and press OK
3. Enter the Proxy domain name and Press OK
4. Enter the proxy username and press OK
5. Enter Proxy Password and Press OK
6. When the Communication screen is displayed Perform Power Cycle to the Base
With manual IP address (DHCP) OFF
The starting point of page 4 step 15
Select Proxy ON and Press OK
1. Enter Proxy URL and press OK
2. Enter Proxy Port and press OK
3. Enter the Proxy domain name and Press OK
4. Enter the proxy username and press OK
5. Enter Proxy Password and Press OK
6. When the Communication screen is displayed Perform Power Cycle to the Base
Congratulations Your mailing system is ready to connect through LAN!
With a successful connection, you are now able to add funds and communicate through your network.
For more information, please visit
kb.quadient.us
