FastStor®1 Quick Installation Guide

Advanced Digital Information Corporation

The information contained in this document is subject to change without notice.

This document contains proprietary information which is protected by copyright. All rights

are reserved. No part of this document may be reproduced, modified, distributed, or

translated to another language without prior written consent of ADIC.

ADIC USA

11431 Willows Road NE

Redmond, Washington

98052-4952

Tel.: 1-800-336-1233

Fax: 1-425-881-2296

This document may describe designs for which patents are pending, or have been granted.

By publishing this information, ADIC conveys no license under any patent or any other right.

ADIC shall not be liable for errors contained herein or for incidental or consequential

damages (including lost profits) in connection with the furnishing, performance or use of this

material whether based on warranty, contract, or other legal theory. ADIC makes no

representation or warranty with respect to the contents of this document and specifically

disclaims any implied warranties of merchantability or fitness for any particular purpose.

Further, ADIC reserves the right to revise or change this document without obligation on the

part of ADIC to notify any person or organization of such revision of change.

Every effort has been made to acknowledge trademarks and their owners. All trademarks

within this document are the property of their respective owners. Trademarked names are

used solely for identification or exemplary purposes, and any omissions are unintentional.

ADIC is a registered trademark and of Advanced Digital Information Corporation.

Published: October 2005 Document Number: 6-01497-01 Rev A

FastStor 1 Quick Installation Guide i

Table of Contents

Introduction......................................................................................1

Step 1. Unpacking the FastStor 1....................................................2

Step 2. Installing the FastStor 1 in a Rack.......................................2

Step 3. Connecting Power Cable.....................................................7

Step 4. Removing the Transport Lock..............................................8

Step 5. Running Power-On Selftest.................................................8

Step 6. Setting the SCSI Address....................................................9

Step 7. Connecting the SCSI Bus Cable..........................................9

Step 8. Connecting the Ethernet Connector...................................11

Step 9. Restarting Your System.....................................................11

Step 10. BCR: Labeling cartridges.................................................11

Advanced Digital Information Corporation FastStor 1

ii FastStor 1 Quick Installation Guide

FastStor 1 Quick Installation Guide 1

Introduction

This guide is designed to enable quick installation of the ADIC FastStor 1

autoloader. For additional product and operation details, please refer to the ADIC

FastStor 1 Installation and User Manual.

The following steps summarize FastStor 1 installation:

•Unpack the FastStor 1

•Install the FastStor 1 in a rack

•Connect the power cable to the FastStor 1

•Turn on the FastStor 1

•Remove the transport lock by following the instructions displayed on the front

panel

•Select the appropriate SCSI IDs and unit options

•Connect the SCSI interface cable, and optionally the Ethernet cable

•Install the backup application software and configure it for use with the

FastStor 1

•Load cartridges into the removable magazines

In order to complete full installation of the FastStor 1, the following additional

materials are required:

•Simple hand tools (small Phillips screwdriver)

•SCSI Host adapter card with 68-pin wide HD or VHDC connector

•Tape application software that is verified with the FastStor 1

•Up to 8 pieces of the appropriate cartridge type to “stock” the FastStor 1 to full

capacity.

Advanced Digital Information Corporation FastStor 1

2 FastStor 1 Quick Installation Guide

Front Panel of the FastStor 1

Magazine

front

bezel

LED

indicators Standby

switch LCD

display Control

buttons Magazine

front bezel

Figure 1. The FastStor 1's front side

Step 1. Unpacking the FastStor 1

Carefully unpack the unit from the shipping container. Save the container and

packing materials in case you need to transport the FastStor 1 in the future. The

packaging is specifically designed for the loader to ensure it is not damaged during

transportation.

Review the contents of the shipping container to be sure all parts were included in

the shipment. A standard package for the FastStor 1 consists of the following items:

•A factory-assembled FastStor 1 unit containing two cartridge magazines.

•A Standard Accessory Kit containing:

-1 Warranty/Registration Card

-Rack-Mount Hardware Kit

-2 Line Power Cords: one for USA/Japan and one for European

power outlets

-1 VHDCI SCSI Interface Cable

-1 VHDCI LVD/SE SCSI Terminator

-1 Ethernet cable

-Tool for Emergency Magazine Release

-Media barcode label kit (contains media labels and cleaning

cartridge labels)

There may be variations of this list.

Note: The FastStor 1 is not shipped with tape cartridges.

Step 2. Installing the FastStor 1 in a Rack

The FastStor 1 is designed for use in a 19” rack system using 1U of rack space.

The length of the power cord and the SCSI cable may restrict the placement.

FastStor 1 Quick Installation Guide 3

Attention: The FastStor 1 is designed to operate in a horizontal position. Do not

attempt to operate the FastStor 1 in any position other than horizontally. Also make

sure that:

•The airflow around the front and back of the FastStor 1 is not obstructed.

•There is a minimum of 60cm free space in front of the unit to allow the

operator to safely remove the magazines.

•The display and operator controls are easily accessed.

•The FastStor 1 is situated away from the floor and in a clean environment

with temperatures within specifications.

The Rack Mounting Kit includes the following items:

•Rail Left Assembly

•Rail Right Assembly

•Screw M6x12 (4 pieces)

•Screw M5x8 (2 pieces)

•Screw M4x12 (4 pieces)

•Nut M4 Hex (4 pieces)

•Washer to M6 (4 pieces)

•Washer to M4 (4 pieces)

Recommended mounting tools:

•Folding rule or tape measure

•Phillips #2 screwdriver

•7 mm open-end wrench

Note: The rails are mounted to the loader during transportation. Before mounting

the rails into the rack, dismount the rails from the loader and remove the spacers

between the rails and the loader.

Advanced Digital Information Corporation FastStor 1

4 FastStor 1 Quick Installation Guide

Figure 2. Rack Mounting kit

Installing the Rack Mounting Kit

•Determine the proper position of the rails in the rack.

Caution: Consider rack stability when deciding where to place the FastStor 1.

Hazardous conditions can result from uneven mechanical rack loading.

FastStor 1 uses 1U of vertical rack

space. The rails must be installed in a

full U position. The bottom of the rails

must be aligned with the bottom of a

U. See Figure 3.

Figure 3. Rack mount rail

Rail Right Assembly

Rail Left Assembly

Front

Back

FastStor 1 Quick Installation Guide 5

Installing the “Rail Left Assembly”

1. Measure the length between the rear rack mount rails and the front rack

mount rails. If the measurement is shorter than the FastStor 1, move the two

sets of screws M4x12, washers and nuts shown in Figure 4.

2. Adjust the “Rail Left Assembly” to fit the measurement in step 1.

3. Use a 7 mm open-end wrench together with the screwdriver to tighten the

two M4x12 screws to fix the rail length. Note: Using more than two screws

will increase the stability of the Rack Mounting Kit.

4. Place the “Rail Left Assembly” on the left side of the rack, between the rear

rack mount rail and the front rack mount rail.

5. Mount the “Rail Left Assembly” at the desired height using one M6x12 screw

in front (upper hole in rail only) and two M6x12 screws at the back. See

Figure 5.

Installing the “Rail Right Assembly”

Follow the instruction for left side only using the “Rail Right Assembly” on the right

side of the rack.

Figure 4. Mounting the Rack mounting kit to a rack

Step 5

(Screw

M6x12) Step 1

Rear Rack

Mount Rail

Use these holes

if rack depth is

equal to or

longer than the

FastStor 1

Step 1

Use these holes

if rack depth is

shorter than the

FastStor 1

Front Rack Mount Rail

Step 5

(Screw M6x12)

Step 2

Step 3

(Screw M4x12,

nut and washer)

Advanced Digital Information Corporation FastStor 1

6 FastStor 1 Quick Installation Guide

Figure 5 shows step 5 in the description:

Rack mounting kit mounted in rack with

one screw M6x12 in upper hole on both

left and right sides.

On the rear side, two screws must be

used on both left and right sides.

A total of six screws are used to install

the rack mounting kit to the rack.

Figure 5. Rack mounting kit

mounted in rack

Mounting the FastStor 1 to the Rack

Make sure all screws in the Rack Mounting Kit are tightened properly before installing the

FastStor 1 in the rack.

Slide the FastStor 1 on the rails from the front of the rack, as shown in Figure 6. Then

secure the FastStor 1 using one M6x12 screw in front of the rack on both left and right sides

(see Figure 7), and one M5x8 on the back of the Rack Mounting Kit on both left and right

sides (see Figure 8).

Figure 6. Slide the FastStor 1 in

from the front.

Figure 7. Fasten the front of the

FastStor 1 to the rack.
