Quantum SuperLoader 3A Series Manuale utente

SuperLoader 3A Series

SuperLoader™ 3A Series

Quick Start Guide

The Quantum®SuperLoader™ 3A Series autoloader is an automated

storage and retrieval device with an integrated A-Series tape drive and up

to two tape magazines holding up to eight cartridges each. It has a built-in

FTP server and Web interface.

For more information, see the SuperLoader 3A Series User’s Guide

(PN 81-81643) and the A-Series FTP File Server User’s Guide (PN 81-81800) on

the documentation CD provided with your autoloader.

This quick start guide uses the following conventions:

This document explains how to unpack the SuperLoader 3A Series

autoloader and install it in a standard 19-inch rack.

Choosing a Location

The autoloader is designed to fit in a standard 19-inch rack using either the

long or short brackets (depending on the depth of the rack). The autoloader

uses standard rack mounting hardware.

Note: Notes emphasize important information related to the main

topic.

Caution: Cautions indicate potential hazards to equipment and are

included to prevent damage to equipment.

Warning: Warnings indicate potential hazards to personal safety and

are included to prevent injury.

Note: It is recommended that you review this entire document prior to

beginning the installation.

Contents 0

Choosing a Location.......................... 1

Preparing for the Installation........... 2

Providing Necessary Tools ............. 2

Taking ESD Precautions ................. 3

Preparing for Rack Mounting ........ 3

Unpacking the Autoloader................ 4

Checking Accessories ..................... 5

Rack Mounting the Autoloader ........ 6

Autoloader Panel Overviews........... 12

Connecting Ethernet

and Power Cables......................... 13

After the Installation....................... 14

2Preparing for the Installation

SuperLoader™ 3A Series Quick Start Guide

Choose a location that meets the following criteria:

Preparing for the Installation

Before you begin the installation procedure in this section, make the following

preparations as described in this section:

•Providing Necessary Tools

•Taking ESD Precautions

•Preparing for Rack Mounting

Providing Necessary Tools 0Provide the following tools for unpacking and installing the autoloader:

• #2 Phillips screwdriver

• Level

• Antistatic wrist strap

Criteria Description

Rack requirements Standard 19-inch rack

Room temperature 10–35° C (50–95° F)

Power source AC power voltage: 100–127 VAC; 200–240 VAC

Line frequency: 50–60 Hz

Locate the AC outlet near the autoloader. The AC power

cable is the product’s main disconnect device and must be

easily accessible at all times.

Weight 15.5 kg (34 lb.) unloaded

18.6 kg (41 lb.) loaded with 2 magazines, 16 cartridges

Air Quality Minimize sources of particulate contamination. Avoid areas

near frequently used doors and walkways, cooling or exhaust

vents, stacks of supplies that collect dust, printers, and

smoke-filled rooms.

Excessive dust and debris can damage tapes and tape drives.

Humidity 20–80% RH (non-condensing)

Clearance Back: Minimum of 43.2 cm (17 in.)

Front: Minimum of 68.6 cm (27 in.)

Sides: Minimum of 5.08 cm (2 in.)

Preparing for the Installation 3

SuperLoader 3A Series

Taking ESD Precautions 0Some components within the autoloader contain static-sensitive parts. To avoid damaging

these parts while performing installation procedures, always observe the following

precautions:

• Ensure that the work area is free from conditions that could cause electrostatic

discharge (ESD).

• Discharge static electricity from your body by touching a known grounded surface,

such as your computer's metal chassis.

• Keep the autoloader turned off during all installation procedures.

• Use an antistatic wrist strap.

• Keep static-sensitive parts in their original shipping containers until ready for

installation. Look for the ESD sticker to identify static sensitive parts.

• Avoid touching connectors and other components.

Preparing for Rack

Mounting 0The autoloader can be rack mounted by attaching it directly to stationary cabinet rails.

Take the following general safety steps before beginning the rack-mount installation.

1Lower the cabinet feet.

2Extend the cabinet anti-tip device, if available.

3Ensure that the cabinet and all rack mounted equipment have a reliable ground

connection.

4Verify that the total current of all rack mounted components (including the

autoloader) will not exceed the current rating of the power distribution unit or outlet

receptacles.

5Secure the help of at least one other person. At least two people are required to safely

install the autoloader into a rack cabinet.

Note: Dry climates and cold-weather heating environments have lower relative

humidity and are more likely to produce static electricity.

Note: An anti-tip device may be extendable legs or similar equipment used to

stabilize the cabinet. This anti-tip equipment is to help avoid over-

balancing the cabinet when installing or removing equipment.

Warning: Failure to take these safety steps may result in personal injury or

equipment damage.

4Unpacking the Autoloader

SuperLoader™ 3A Series Quick Start Guide

Unpacking the Autoloader

Before you begin, clear a desk or table so that you can unpack the autoloader.

The SuperLoader 3A Series Quick Start Guide

has all the necessary information to unpack

and inspect your autoloader correctly.

You also need to select an open 2U computer rack location near the server that will host

the autoloader.

Carefully unpack and inspect your new SuperLoader 3A Series autoloader by doing the

following:

1Inspect the shipping box for damage. If you notice any damage, report it to the

shipping company immediately.

2Open the shipping box and remove the accessories package. Set the accessories

package aside for now.

3Lift the autoloader and padding out of the box and place it on the work surface, top

facing up. Do not set the autoloader on either end or sides.

4Carefully remove the shipping padding from the left and right sides of the

autoloader. Then remove the bag from the autoloader.

5Remove the foam insert from the magazine bay of the autoloader. Save the packing

materials in case you need to move or ship the autoloader in the future.

Caution: Do not remove the top cover of the autoloader during the installation

process. Removing the top cover could result in damage to the

autoloader.

Caution: If the room in which you are working differs from the temperature in

which the autoloader was shipped or stored by 15° C (30° F) or more, let

the autoloader acclimate to the surrounding environment for at least 12

hours before removing it from the shipping carton.

Caution: If your unit was ordered as a one-magazine autoloader, be sure to remove

the plastic shipping insert from the magazine bay before connecting or

operating your autoloader. Insert either a magazine or a magazine blank

into the bay. The autoloader will not function without both magazine bays

equipped with either a magazine or a magazine blank.

Note: If the cover must be taken off, there are 26 screws that need to be removed.

Unpacking the Autoloader 5

SuperLoader 3A Series

Checking Accessories 0The following accessories are shipped with the SuperLoader 3A Series autoloader:

• SuperLoader 3A Series Quick Start Guide

•Ethernetcable

• Hardware to rack mount the autoloader (see figure 1)

• Four autoloader brackets (two long and two short to accommodate different rack

depths)

• Two support brackets

• Two sets (decimal and metric) of four support bracket 10-32 x 1/4 inch button

head screws (two per support bracket)

•TORX

®L-Key drivers (T8 and T10)

•Powercable

• Documentation CD containing all of the documentation in Adobe®Portable

Document Format (PDF)

•Barcodelabels

You will also need the following parts that were shipped with your rack:

• Eight clip nuts

• Eight rack screws

Figure 1 Rack Mount

Hardware

Short autoloader

brackets (72-A225-A)

Support brackets

(74-60605-01)

Long autoloader

brackets (72-A226-A)

Support bracket screws

72-A348-A (4) or 90-60227-50 (4)

6Rack Mounting the Autoloader

SuperLoader™ 3A Series Quick Start Guide

Rack Mounting the Autoloader

This section provides the steps for attaching the autoloader directly to the stationary rails

of a rack. Refer to table 1 for information on common rack hole types.

Table 1 Rack Hole Types

1Install two clip nuts, 1.75 in. (44.45 mm) apart, onto each of the four rails of the rack,

making sure that you install each pair of clip nuts at exactly the same level (see

figure 2).

Figure Description

Square rack holes are the most

common type of rack holes.

They can accept either cage

nuts which mount from the back

of the rail or clip nuts which clip

on from the side of the rack rail.

Through holes require clip nuts

to accept mounting hardware.

Threaded holes require neither

cage or clip nuts to accept

mounting hardware.

Note: The rails within the rack have a hole pattern that repeats throughout the rail.

Cage nut

Clip nut

Rack Mounting the Autoloader 7

SuperLoader 3A Series

Figure 2 Installing Two Clip

Nuts

2Select the long or short autoloader brackets (depending on the depth of the rack), and

then attach them to the rear of the autoloader (see figure 3). Use the long autoloader

brackets (72-A226-A) when the distance from the front mounting rail to the rear

mounting rail is less than 30.25 in. (76.84 cm). Otherwise, use the short autoloader

brackets (72-A225-A).

Outer covers

of the rack

Rail

Clip nut

1.75 in

(44.45 mm)

Clip nut

8Rack Mounting the Autoloader

SuperLoader™ 3A Series Quick Start Guide

Figure 3 Attaching Autoloader

Brackets

3Using rack screws, attach a support bracket to the clip nuts on each rear rail (see

figure 4.)

Tighten the screws just enough to hold the support brackets firmly against the rail

while still allowing the support bracket to be slightly shifted by hand. This shifting

will help facilitate the engagement of autoloader brackets as the autoloader is

installed in the rack. You will fully tighten the screws in step 8.

Note: Be sure to attach the support brackets correctly; the side of the bracket with

only two holes should be secured to the rail.

Autoloader

Autoloader bracket

Screws (10-32 x 1/4 only)

Rack Mounting the Autoloader 9

SuperLoader 3A Series

Figure 4 Attaching Support

Brackets

4With the help of a second installer, insert the autoloader into the rack so that the

autoloader brackets slide into corresponding support brackets on the rear rails and

the tabs at the front of the autoloader align flush with the clip nuts on the front rails

(see figure 5).

Caution: Do not release the front end of the autoloader until it can be secured to

the rack.

Support bracket

Rack screws

Clip nuts

Rear rail in rack

Outer cover of rack

10 Rack Mounting the Autoloader

SuperLoader™ 3A Series Quick Start Guide

Figure 5 Sliding Autoloader

into Rack

5While the other installer holds the front end of the autoloader, secure the front end of

the autoloader to the rack using four rack screws (two per tab) as shown in figure 6.

Tighten the screws just enough to secure the autoloader to the front rails.

Figure 6 Front Alignment

6Install four screws (two per side) to secure the support brackets to the autoloader

brackets (see figure 7).

Support bracket

Autoloader bracket

Front rail

Rack screws

Tab (one per side)

Autoloader

(front)

Altri manuali per SuperLoader 3A Series

Indice

Altri manuali Quantum Magazzinaggio

Quantum

Quantum LTO3 A-Series Manuale utente

Quantum

Quantum DXi4510 Manuale dell'operatore

Quantum

Quantum Fireball Plus AS Manuale utente

Quantum

Quantum SNC 5100 Manuale di istruzioni

Quantum

Quantum DXi V-Series Manuale utente

Quantum

Quantum StorNext M660 Istruzioni per l'installazione

Quantum

Quantum Tape Drive A-Series Manuale utente

Quantum

Quantum SuperLoader 3A Series Manuale del proprietario

Quantum

Quantum StorNext QD6000 Manuale utente

Quantum

Quantum DLT 1 Manuale utente

Quantum

Quantum DXi4700 Manuale di installazione e funzionamento

Quantum

Quantum DLTtape DLT1 Manuale utente

Quantum

Quantum PX720 Manuale utente

Quantum

Quantum DLTtape DLT 4000 Manuale utente

Quantum

Quantum Scalar 50 Manuale utente

Quantum

Quantum Scalar i500 Manuale utente

Quantum

Quantum DLTtape SDLT 220 Manuale utente

Quantum

Quantum DXi6900 Guida rapida

Quantum

Quantum ValueLoader DLT VS160 Manuale del proprietario

Quantum

Quantum StorNext QM1200 Manuale utente

Quantum

Quantum ATL 7100 Manuale

Quantum

Quantum Bigfoot 1.2AT Manuale utente

Quantum

Quantum DXi4700 Manuale di installazione e funzionamento

Quantum

Quantum Internal Storage System Travan 40 GB Manuale utente

Manuali Magazzinaggio popolari di altre marche

QNAP

QNAP TS 32PXU Series Manuale utente

LaCie

LaCie RUGGED RAID Manuale utente

Freecom

Freecom CLS DOCK Manuale utente

PNY

PNY Attache P-FD64MBATT3 Manuale utente

HP StorageWorks MSL2024 Manuale utente

OLT

OLT 6x6 Maximizer Manuale utente

Transcend

Transcend JetFlash 160 Manuale utente

LaCie

LaCie RUGGED MINI Manuale utente

Thunderbolt

Thunderbolt 600 Manuale utente

Panasonic

Panasonic LB-DH8 series Manuale

Intel

Intel RAID High Availability Manuale utente

LaCie

LaCie 12big Thunderbolt 3 Manuale utente

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuale utente

Panasonic

Panasonic LKM-F931-1 Manuale utente

Tabernus

Tabernus Enterprise Erase E2400 Manuale utente

Rocstor

Rocstor COMMANDER 3F series Manuale utente

HP P9000 Manuale utente

Western Digital

Western Digital Ultrastar Data60 Manuale utente
