QuietFlo 30085 Manuale utente

Replacement Filter Information

Pre-Filter

30901

HEPA Filter

30936

Model

30085

M o d e l 3 0 0 8 5

H E P A A I R P U R I F I E R S Y S T E M

IMPORTANT SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USING THIS AIR

PURIFIER AND SAVE THESE IMPORTANT

INSTRUCTIONS

1. This Air Puriﬁer is designed for use on a ﬂat, level surface and may not

work properly on an uneven surface. ALWAYS place this Air Puriﬁer on

a ﬁrm, level surface. ALWAYS place the Air Puriﬁer at least six (6) inches

away from walls and heat sources such as stoves, radiators, or heaters.

2. Place the Air Puriﬁer in an area that is out of the reach of children.

3. Before using the Air Puriﬁer, extend the cord and inspect for any signs of

damage. DO NOT use the product if the cord has been damaged.

4. This product has a polarized plug (one blade is wider than the other) as a

safety feature. This plug will ﬁt into a polarized outlet only one way. If the

plug does not ﬁt fully into the outlet, reverse the plug. If it still does not

ﬁt, contact a qualiﬁed electrician. DO NOT attempt to defeat or override

this safety feature.

5. ALWAYS UNPLUG the Air Puriﬁer when it is not in operation, while the

ﬁlter is being changed, and while it is being cleaned.

6. DO NOT tilt or move the Air Puriﬁer while it is in operation. Shut off and

unplug before moving.

7. DO NOT immerse the Air Puriﬁer in water as permanent damage will oc-

cur. Refer to and follow the CLEANING AND FILTER REPLACEMENT

instructions.

Introduction

Thank you for purchasing the Quietﬂo™ Air Puriﬁcation System from Hunter Fan

Company. You have purchased our latest development in portable Air Puriﬁcation

Systems. This system has been developed to improve the quality of the air you

breathe.

Our Quietﬂo™ Air Puriﬁcation System out performs other air puriﬁcation systems

by quickly and effectively removing dust, smoke, and pollen particles as small as

.3 microns in size. Room air is pulled in through the front grill and cleaned across

the Quietﬂo™ ﬁlter. Clean air is then released out the top grill in order to avoid

stirring up settled particles.

Using Your Air Puriﬁer

1. Take the air puriﬁer out of the box and remove the clear plastic protective bag.

Place the unit on a ﬁrm level ﬂoor.

2. Before turning on the air puriﬁer, you need to conﬁrm that the ﬁlters are ﬁrmly

in place and have not become loose during shipping. To check the ﬁlters, open

the front grill by placing your ﬁngers under the handle and pulling the front grill

towards you. The front grill will rest open at about 45º. You can remove the

front grill by placing your ﬁngers under the handle and pulling the front grill

towards you and then up.

3. Before turning the Air Puriﬁer ‘on’, you need to open the front grill.

To release the front grill, press the buttons on the side until the front grill slides

easily over the buttons.

4. The carbon pre-ﬁlter is mounted inside the front grill with hook tape. Conﬁrm

that it properly covers the grill vents. You may notice a few black particles

coming off the pre-ﬁlter. Those particles are part of the odor-removing activated

carbon and will be collected on the ﬁlter during use.

5. Place the front grill back onto the unit. First, line up the tabs on the bottom

of the grill with the openings on the puriﬁer base and then push the top of the

grill forward until it is closed. NOTE: This unit will not operate unless the

grill is in the correct position.

6. Plug the unit into a 120V electrical outlet.

Operating Your Air Puriﬁer

On/Speed Control: Rotate the Speed Control knob to set the desired speed. A set-

ting of zero (0) indicates that the unit is off, one (1) is low speed, two (2) is medium

speed, and three (3) is high speed. The fan speed can be adjusted at any time.

Filter Change Calendar: The ﬁlter counter is designed to optimize the perfor-

mance of the air purifer by reminding you when to change the Quietﬂo™ Filter

and pre-ﬁlter. See Figure 1.

Quietﬂo Filter Calendar: The Quietﬂo™ Filter

indicator is located at the top of the calendar ring. To

set the Quietﬂo Filter counter, rotate the calendar ring

to align the month that you installed the ﬁlter with

the top indicator. Since the ﬁlter is designed for 6

months use, the two indicators will serve as reminders

to change the ﬁlter every 6 months.

Pre-ﬁlter Calendar: The inner knob of the ﬁlter

counter is the pre-ﬁlter counter. To use, align the

knob with the month that you installed the pre-ﬁlter.

The replace symbol on the inner knob points to the

month in which you should install a new pre-ﬁlter. The pre-ﬁlter is designed for

three months of usage.

Figure 1 - Calendar Knob

Cleaning And Filter Replacement

1. Clean the outside of the unit with a soft, damp cloth. The front grill can be

removed and cleaned in soapy water. See Figures 2 and 3.

Front Grill

Pre-ﬁlter

Quietﬂo™Filter

Buttons for

opening the

front grill

Figure 2

Figure 3

Buttons for

opening the

front grill

2. At least every 90 days, open the front grill, remove the carbon pre-ﬁlter, and

replace it. This is necessary to maintain proper odor-removing and overall

ﬁltration performance. If necessary, it can be changed more often. Mark the

new ﬁlter installation sticker included with the new carbon pre-ﬁlter. Be sure

to remove any plastic wrapping that may be on the new ﬁlter before you place

it into the Air Puriﬁer.

How The QuietﬂoTM System Works

The above is an illustration of how the Quietﬂo™ air puriﬁcation system works.

Dust and other irritants are pulled into the air puriﬁcation system and cleaned

through the Quietﬂo™ Filter. Clean, puriﬁed air is then released into the room.

Dust & Irritants Pollen & Allergens Odors Bacteria Pet Hair & Dander

Carbon

Pre-Filter

True HEPA Filter

99.97% – .3 Microns

Replacement Filters:

To obtain a replacement ﬁlter for your Air Puriﬁer, call 1-800-4Hunter for your

nearest retailer or Hunter Customer Service at 901-248-2222. Please be prepared

to tell the operator the model number of your Air Puriﬁer and the model number

of the ﬁlter you need to replace.

Hunter Air Puriﬁer Model No.: ....................... 30085

Pre-Filter Replacement Model No.: ................30901

HEPA Filter Replacement Model No.: ............ 30936

Continued

Hunter Fan Company

Quietﬂo™ Air Puriﬁcation System

5 YEAR LIMITED WARRANTY

The Hunter Fan Company makes the following limited warranty to the original

residential user or consumer purchaser of the Quietﬂo™Air Puriﬁcation System:

If any part of your Quietﬂo™ Air Puriﬁcation System (“Air Puriﬁer”) motor fails

during the ﬁrst ﬁve (5) years from the date of installation to you due to a defect in

material or workmanship, we will provide a replacement Air Puriﬁer free of charge.

Installation is deemed to occur at the date if purchase.

If the Air Puriﬁer cord or front grill fails any time within one (1) year after instal-

lation due to a defect in material or workmanship, we will replace or, at our option,

repair the unit free of charge at our nearest service centre or at our Service Depart-

ment in Memphis, Tennessee. You will be responsible for all parts and labour costs

after this one-year period.

USE OF A NON-HUNTER FILTER WILL INVALIDATE THIS WARRANTY.

IF THE ORIGINAL RESIDENTIAL USER OR CONSUMER PURCHASER

CEASES TO OWN THE AIR PURIFIER, THIS WARRANTY AND ANY IM-

PLIED WARRANTYWHICH THEN REMAINS IN EFFECT, INCLUDING BUT

NOT LIMITED TOANY IMPLIED WARRANTY OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE, ARE VOIDED.

NO WARRANTY, EXPRESSED OR IMPLIED , INCLUDINGANYWARRANTY

OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS

MADE IN RESPECT TO THE FILTER MATERIAL OR CARBON FILTER.

THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES.

THE DURATION OF ANY IMPLIED WARRANTY INCLUDING BUT NOT

LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE, IN RESPECT TO THE MOTOR

IS EXPRESSLY LIMITED TO THE PERIOD OF THE EXPRESS WARRANTY

SET FORTH ABOVE.

This warranty is voided if the air puriﬁer is not purchased and used in the USA

or Canada.

This warranty excludes and does not cover defects, malfunctions or failures of the

Air Puriﬁer which were caused by repairs by persons not authorized by us, use of

parts or accessories not authorized by us, mishandling, modiﬁcations, or damage

to the Air Puriﬁer while in your possession, or unreasonable use, including failure

to provide reasonable and necessary maintenance. This warranty does not cover

Air Puriﬁers used in commercial applications. There are no express or implied

warranties as to commercial purchasers or users.

Hunter Fan Company • 2500 Frisco Avenue

Memphis, Tennessee 38114 • http://www.hunterfan.com

To obtain service, contact the nearest Hunter authorized service centre or the

Hunter Fan Company Service Department, 2500 Frisco Avenue, Memphis, Ten-

nessee 38114, 901-248-2222. For the name of our nearest authorized Hunter Fan

Company Service Centre, write to the Hunter Fan Company at the preceding ad-

dress. You will be responsible for insurance and freight or other transportation to

our factory service center. We will return the Air Puriﬁer freight prepaid. The Air

Puriﬁer should be properly packaged to avoid damage in transit since we will not

be responsible for any such damage. Proof of purchase is required when requesting

warranty service. The purchaser must present sales receipt or other document that

establishes proof of purchase.
