Quoizel MBH8409PN Istruzioni per il montaggio

Package Contents

1of2

BCrossbar Assembly

Figure 3

STEP 2 Install Crossbar Assembly-

A. Pass the supply wires through the Crossbar Assembly (B). Attach

the Crossbar Assembly (B) to the Outlet Box with the head of the

Green Ground Screw facing you. Secure it with Outlet Box Screws

(not included). Tighten until snug

Note: Use the Alternate Shorter Mounting Screw (C) if your

installation requires a shorter mounting screw.

STEP 3 Test Fit the Backplate to the Crossbar Assembly-

A. Remove the mounting balls from the Crossbar Assembly (B). Place

the backplate and Fixture Body (A) onto the Crossbar Assembly (B)

and secure with mounting balls. Note: The backplate and Fixture

Body (A) should be snug against the wall and held tight with the

mounting balls. If it is not, adjust the length of the mounting screws

or alternate short mounting screws on the Crossbar Assembly (B)

by unscrewing the preassembled hex nut and lock washer and then

screwing the mounting screws or alternate short mounting screws

in or out of the crossbar until the correct length is achieved. Once

AFixture Body

Pleasegoto forproductcleaningtips.Gotothe selection.

Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.

(3)B10CandelabraBaseBulbs60WMaximum

30-45minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare

present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement

parts.

www.quoizel.com Care + Maintenance

ToolsRequired:

LightSource:

EstimatedAssemblyTime:

Preparation:

Fixturecanonlybemountedinthedirectionindicatedonpage2.

Warnings and Cautions

Assembly Instruction Sheet #IS-MBH8409PN_R1

For Style MBH8409PN

6 CORPORATE PARKWAY

GOOSE CREEK SC 29445

www quoizel com

Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.

These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly

recommend that a licensed, professional electrician perform the installation.

Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal.

Alternate

Mounting

screw

Mounting Screw

or Alternate Short

Mounting Screw

Supply Wires with

Ground Wire

Outlet Box Screws

(not included)

Outlet Box

Figure 2

Hex Nut and

Lock Washer

Mounting Ball

Mounting Screw

or Alternate Short

Mounting Screw Backplate

2017 QuoizelInc.

Thank you for purchasing a Quoizel product.

Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184

or visit us on-line at www.quoizel.com

RevisedDate:2017-8-03

Figure 1

Fixture Hood

Cage

Tab

Glass Shade

Lock Screw

the backplate and

Fixture Body (A) is

secure, remove the

mounting ball and

Fixture Body (A) and

proceed to Step 4.

STEP 1 Instal Shade-

A Remove the Styrofoam from

inside of the shade.

B. Place Glass Shade into the Cage, secure by place the Tab into the

Cage press on the Glass Shade.

C. Align the label “A” on the bottom of the fixture hood to the label “A”

on the top edge of the cage. Place the fixture hood onto the top

edge of the cage and secure with lock screws. Hand tighten until

snug with screwdrivers.

Unscrew the Lock Screw, remove the Cage, the Glass Shade and

the Tab from the Fixture Body ( ).

Label “A”

2of2

STEP 4 - Wire Connections

A. Use standard wire connectors (not included) to make all wire

connections. Twist connectors until wires are tightly joined together.

Wrap each connection with approved electrical tape and carefully

stuff all the connected wires into the Outlet Box.

Figure 4

White wire

from outlet box White wire

from fixture

Black wire from

outlet box (or Red)

Black wire

from fixture

Bare, or Green

Ground wire

from outlet box

Ground wire

from fixture

Bare, or Green

Ground wire

from outlet box

Ground wire

from fixture

Green Ground Screw

on the Crossbar

STEP 5 Install the Fixture Body-

A. Position the backplate and Fixture Body (A) onto the Crossbar

Assembly (B). Place the holes in the backplate over the mounting

screws. Secure the backplate and Fixture Body (A) by using the

mounting balls and hand tighten the mounting balls until snug.

Figure 5

STEP 6 -Install the Bulb and Apply Silicone Sealer

A. Insert the bulb onto socket and screw snugly into place.

B. Make sure the exterior wall surface and fixture backplate are free of

dirt before applying caulk. Using exterior grade caulk, caulk over

Socket

Bulb (not

Supplied)

Figure 6

Exterior

Grade Caulk

Backplate

Exterior

Grade

Caulk

top of backplate and down

both sides. Do not caulk the

bottom of the fixture

backplate to ensure proper

moisture drainage.

Your fixture is now

assembled and ready to

use. Enjoy!

NOTE: ALL DIMENSIONS ARE ROUNDED

UP TO THE NEAREST 1/4"

Fixture can

only be

mounted in

the direction

indicated

2017 QuoizelInc.

Thank you for purchasing a Quoizel product.

Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184

or visit us on-line at www.quoizel.com

RevisedDate:2017-8-03

Mounting Ball

Mounting Screw

or Alternate Short

Mounting Screw Backplate

8”

5.5”

10” 9” Dia.

14.5”

MBH8409PN

FINISH: PALLADIAN BRONZE
