Rad Power Bikes RadRover Manuale utente

Welcome

Thank you for purchasing the RadRover from Rad Power BikesTM.

We take pride in bringing you a quality product that will offer years of enjoyment. Please read and understand this

manual fully before assembling and riding your bike.

If you have questions after reading this manual, please reference the Rad Power Bikes Help Center, contact us by

email, and/or give us a call on the phone.

We are here to help!

Rad Power Bikes Help Center: www.radpowerbikes.com/help.

Email: [email protected]

Phone: 1-800-939-0310 x 2

Thanks for Riding RAD!

Using This Manual

This manual contains details of the product, its equipment, and information on operation, maintenance, and other helpful tips for

owners. Read it carefully and familiarize yourself with the RadRover before using it to ensure safe use and prevent accidents. Be

sure to retain this manual as your convenient RadRover information source. An electronic copy of the latest

version of this manual is available in the Help Center at www.radpowerbikes.com/help.

This manual contains many warnings and cautions concerning the safe operation and consequences if

proper setup, operation, and maintenance are not performed. All information in this manual should be

carefully reviewed and if you have any questions you should contact Rad Power Bikes immediately. The

notes, warnings, and cautions contained within the manual and marked by the triangular Caution Symbol at the right of this page

should also be given special care. Users should also pay special attention to information marked in this manual beginning with

NOTICE.

Because it is impossible to anticipate every situation or condition which can occur while riding, this manual makes no

representations about the safe use of bikes under all conditions. There are risks associated with the use of any bike which cannot

be predicted or avoided, and which are the sole responsibility of the rider. You should keep this manual, along with any other

documents that were included with your bike, for future reference, however all content in this manual is subject to change or

withdrawal without notice. Visit http://www.radpowerbikes.com/help to download the latest version. Rad Power Bikes makes

every effort to ensure accuracy of its documentation and assumes no responsibility of liability if any errors or inaccuracies appear

within. Assembly and first adjustment of your bike from Rad Power Bikes requires special tools and skills and it is recommended

that this should be done by a certified, reputable bike mechanic if possible.

Table of Contents

Using this Manual....................................................................................................................................................................1

General Info ............................................................................................................................................................................3

Assembly Instructions..............................................................................................................................................................7

Battery Charging....................................................................................................................................................................15

Operation..............................................................................................................................................................................19

Maintenance.........................................................................................................................................................................33

Troubleshooting....................................................................................................................................................................38

Warnings and Safety..............................................................................................................................................................40

Warranty...............................................................................................................................................................................44

Links to Assembly Video and Online Resources.......................................................................................................................46

General Info

Assembly and Fit

Correct assembly and fit are essential elements of ensuring your bicycling safety, performance, and comfort. Even if you have the

experience, skill, and tools to complete these essential steps before your first ride, Rad Power Bikes recommends having a

certified, reputable bike mechanic check your work.

NOTICE: If you do not have the experience, skill, and tools to complete assembly and fit, Rad Power Bikes highly recommends having a certified, reputable

bike mechanic complete these procedures as well as any future adjustments or tuning.

NOTICE: A critical aspect of assembling your bike by Rad Power Bikes is securing the front wheel and checking the tightness of the rear wheel axle nuts. All

bikes by Rad Power Bikes use a quick release front wheel mounting mechanism and the rear wheel is bolted on. Both wheels need to be properly secured

before operating your bike.

Mandatory Equipment and Use Locations

Before all rides, ensure you have all required and recommended safety equipment and are following all laws pertaining to using

an electric bike in your region. For example, these laws may specify the need for mandatory equipment, use of hand signals, and

where you can ride.

Changing Components or Attaching Accessories

The use of non-original components or spare parts can jeopardize the safety of your RadRover, void your warranty and, in some

cases, cause your RadRover to not conform with laws pertaining to your bike.

The replacement of original components or installation of third-party accessories or accessories from Rad Power Bikes not

explicitly recommended for your bike model, is at your own risk. Using aftermarket accessories or components that have not

been tested by Rad Power Bikes for safety and compatibility may void your warranty, create an unsafe riding condition,

damage your bike by Rad Power Bikes, or result in serious injury and/or death.

Safety Check Before Each Ride

Always check the condition of your bike before you ride in addition to having regular maintenance performed. If you are unsure

of how to conduct a complete check of the condition of your bike before every ride, you should consult a certified, reputable bike

mechanic for assistance. See the Pre-Ride Safety Checklist for more information.

Electrical System

The electrical system on your RadRover offers various levels of power assistance and lighting for different operating conditions

and user preferences. It is critical that you familiarize yourself with all aspects of your RadRover’s electrical system and check to

see that it is working correctly before every ride. The front and rear brake levers contain safety power cutoff switches, which

disable the hub motor’s assistance when applied, and both levers should be checked for correct operation. The throttle should

provide smooth acceleration when gradually applied. If the throttle, brake lever cutoff switches, pedal assistance, or lighting is

not functioning normally, intermittent, or not working, please discontinue using your RadRover immediately and contact the Rad

Power Bikes Technical Support team for assistance.

Brakes

Ensure brakes are working correctly, all braking system components are free from damage, and properly secured. When you fully

squeeze the brake levers, ensure neither the front or rear brake levers touch the handlebar. Take your bike to a certified,

reputable bike mechanic to have the brakes repaired if you find a problem.

Tires and Wheels

Your wheels should always spin straight and must be repaired or replaced if they wobble side to side or up and down when

spinning. If your wheels become untrue or spokes loosen, do not attempt to true or tighten unless you have adequate knowledge,

tools and experience. It is recommended that a certified, reputable bike mechanic performs all wheel tuning and truing

operations on your bike from Rad Power Bikes. Ensure your tires and inner tubes are in good working condition without any

visual damage and have the correct amount of air pressure. Always replace tires and inner tubes with punctures, cuts or damage

before you ride. Tires without the correct amount of air pressure can reduce performance, increase tire and component wear,

and make riding your bike unsafe.

Quick Release Levers

Quick release levers are located throughout the RadRover for securing the seat post and the front wheel to the bike. These

provide convenience to the user since they allow the front wheel to be removed and the seat post to be adjusted without tools.

Since quick release levers can be loosened during transportation, or accidentally between or during rides, it is important that you

regularly check to ensure these components are properly secured.

Accessories, Straps, and Hardware

Ensure all hardware is secured and all approved accessories are properly attached per the specific component manufacturer’s

instructions. It is good practice to look over all hardware, straps, and accessories before each ride and if you do discover

something is wrong or find something you are not sure about, please have it checked by a certified, reputable bike mechanic.

Suspension, Handlebar, Grips, and Seat Adjustments

The suspension fork on your RadRover will affect the handling of the bike so you MUST understand how it works before use. The

suspension fork should be properly adjusted for your weight and terrain. Check to ensure the handlebar, handlebar stem, and

seat post are properly fastened, aligned, and fitted to the user. Ensure all hardware securing the handlebars and seat are properly

tightened including all quick release levers. Loose, worn, or damaged handlebar grips should be replaced before you ride.

Battery Charged, Secured, and Unplugged

Ensure the battery is fully charged and operating properly. The battery gauge on the LCD display and battery mounted charge

status indicator should read similarly. The battery MUST be locked onto the frame battery mount properly before use. Ensure the

battery charger is unplugged from the battery, outlet, and stored in a safe location before you ride.

Fully Assembled RadRover

Assembly Instructions

NOTICE: The following assembly steps are only a general guide to assist in the assembly of your bike from Rad Power Bikes and is not a

complete or comprehensive manual of all aspects of assembly, maintenance, and repair. We recommend you consult a certified, reputable

bike mechanic to assist in the assembly, repair, and maintenance of your bike.

Step 1: Unpack bike from the carton and carefully set out all contents of the box. Remove packaging material protecting the bike

frame and components. Please recycle packaging materials especially cardboard and foam (all #6 EPS foam). Ensure all pieces are

included in the package including:

•RadRover

•Manual(s)

•Assembly Toolkit

•Front Wheel

•Charger

•Pedals (marked left and right)

•Quick Release (in fork protector plate)

•Headlight

•Keys (two, identical)

If there are any missing parts, please contact Rad Power Bikes.

Step 2: Install handlebar onto stem as shown in the assembly video for the RadRover located

in the Help Center at www.radpowerbikes.com/help. Be sure to center the handlebar and

ensure stem clamp faceplate bolts are secured to the recommended torque value.

Step 3: Install front wheel. For detailed instructions please view the RadRover Assembly video

and Quick Release Installation video found in the Help Center at

www.radpowerbikes.com/help. Ensure front wheel and quick release are properly secured

before moving on to the next step. When properly installed, the front wheel should be fully

seated in the dropouts of the front fork, and the quick release lever should be fully and properly

secured as shown in the assembly and instructional videos.

Step 4: Inflate tires to desired PSI. Recommended pressure is 20 PSI (1.38 Bar) for the front and rear tires of the RadRover.

Recommended tire pressure is indicated on the tire sidewall. Do not overinflate or underinflate tires.

Step 5: Install the pedals. Locate the pedal marked with an

“L” at the pedal axle end and notches on the outside of the

pedal axle (1, at right). The pedal marked “L” with notches

goes on the crank on the left side of the bike (which is the

same as a rider’s left side when riding). The left pedal is

reverse threaded and tightens counterclockwise. Carefully

thread the pedals by hand slowly. Do not cross thread or

damage the threads.

Tighten securely using a pedal wrench to avoid damage caused by wider wrenches, as shown in assembly video.

The right pedal is threaded so that it is tightened by turning clockwise, has an “R” stamped into the pedal axle end, and a

smooth exterior on the outside of the pedal axle (2, above). Carefully thread the right pedal onto the crank on the right side of

the bike (the side with the drivetrain gears) slowly and by hand. Do not cross thread or damage the threads. Tighten securely

using a pedal wrench to avoid damage caused by wider wrenches.

Step 6: Set desired seat height. Adjust the seat post up or down to a comfortable height,

while ensuring the seat post is inserted into the frame past the minimum insertion point.

Ensure the seat post clamp opening is centered over the gap in the seat tube and secure all

hardware and the quick release lever to lock the seat post in place so it cannot move. Do not

overtighten.
