Radial®Shuttle™500 User Guide
Table of Contents ......................................................Page
Feature Set .................................................................... 1
Overview ........................................................................ 2
Getting Started ............................................................... 3
Using the Loops ............................................................. 4
Omniport ........................................................................ 6
Patching External Sources............................................. 8
Specifications ................................................................. 9
Block Diagram................................................................ 9
Warranty........................................................... Back cover
Congratulations and thank you for your purchase of the Radial Shuttle 500 module. The
Shuttle is a simple yet highly effective tool that will help you efficiently route signals in and
out of your Workhorse or 500 series rack. In fact, it is probably one of those devices that you
will soon come to say: “I wonder how I could have lived without it?”
To help you get there, we have written this short manual. Please take a few minutes to read
it through so that you can take full advantage of the features that are built in. Hopefully,
we have addressed all of your concerns. If however you do not find all of the answers and
wisdom as you drop your bucket into the deep well of recording knowledge, visit the FAQ
page on our web site. This is where we post questions from users like you along with helpful
hints. If you do not find what you are looking for, then send us an email at info@radialeng.
com. We will do our very best to answer your question in short order.
Get ready to plug in, out and in between!
